Infosec X4 2000 RM Plus uninterruptible power supply (UPS) Line-Interactive 2 kVA 1200 W 10 AC outlet(s)

Product Details

Data sheet

Width

440 mm

Height

88 mm

Depth

300 mm

Weight

14.4 kg

Cables included

Input power cable, Output power cable

Manual

Yes

Operating temperature (T-T)

0 - 40 °C

Operating relative humidity (H-H)

0 - 90%

Form factor

Rackmount

USB port

Yes

Battery technology

Sealed Lead Acid (VRLA)

Battery capacity

9 Ah

Battery recharge time

6 h

Output power

1200 W

Input frequency

50/60 Hz

USB 2.0 ports quantity

1

Display type

LCD

Ethernet LAN (RJ-45) ports

2

Input operation voltage (min)

162 V

Power protection features

Overdischarge

Cold start

Yes

AC outlets quantity

10 AC outlet(s)

Output power capacity

2 kVA

Output operation voltage (max)

220 V

Waveform

Pseudo sine

Auto-restart

Yes

AC outlet types

Type F

Input operation voltage (max)

268 V

Battery voltage

12 V

UPS topology

Line-Interactive

Typical backup time at full load

50 min

Automatic Voltage Regulation (AVR)

Yes

Typical backup time at half load

17 min

Output voltage regulation

-10 - 10%

Output frequency

50 Hz

Noise Level

45 dB

Maximum current

16 A

Product colour

Black

USB port type

USB Type-B

Crest factor

3:1

Number of input phases

1

Number of output phases

1
