Features:
Full control with wide rpm range. The Alpine 23 CO features a very wide PWM-controlled speed range. This reduces noise to the minimum while also guaranteeing the highest cooling performance.
Designed for continuous operation. The premium quality of the two ball bearings allows 24/7 continuous operation without compromising performance. Contamination and high temperatures affect this bearing much less than ordinary plain or magnetic bearings. Therefore, the double ball bearing is the perfect choice in working environments where you want to ensure continuous operation with a low failure rate.
Easy and tool-free installation. With the MX-2 already pre-applied, the Alpine 23 CO can be mounted directly. Thanks to the push pins, installation is a breeze. Additional tools are not needed to mount the cooler.
Improved cooling performance through innovative heat sink design. The extra fine cooling fins of the new Alpine are fanned out in a Y-shape. The high thermal conductivity of the aluminum is fully retained in the type of extrusion used. This novel production process makes it possible to produce a high-performance yet very compact radial heat sink. This results in an increase in the surface area of the heat sink, optimization of the airflow, and thus an increase in cooling performance.
Long service life. Excellent results of long-term testing, even in particularly unfavorable conditions, ensure that these products are characterized not only by quality, but also by durability. Therefore, Alpine 23 CO are covered by a 6-year manufacturer's warranty.
Technical data:
Fan speed: 200-2700 RPM.
Connector: 4-Pin.
Thermal paste: MX-2 (pre-applied).
Fan diameter: 90 mm.
Number of fins: x50 Y-shaped.
Bearing: dual ball bearing.
Noise level: 0.3 Sone.
Current: 0.09A.
Dimensions: 98.6mmx121mmx65mm.
Weight: 275.5g.
Heatsink material: aluminum.
Color: black body, black+white cooler.
Compatibility:
AMD AM5.
AMD AM4.
Warranty: 6 years.
