Digitus | Line-Interactive UPS | Line-Interactive UPS DN-170076, 2000VA/1200W 12V/9Ah x2 battery, 4x CEE 7/7, USB, RS232, RJ45,

Product Details

Data sheet

Width

158 mm

Height

198 mm

Depth

380 mm

Weight

10.5 kg

Package height

280 mm

Package width

212 mm

Number of batteries supported

2

Operating temperature (T-T)

0 - 40 °C

Operating relative humidity (H-H)

0 - 95%

Form factor

Tower

USB port

Yes

LED indicators

Yes

Battery capacity

9 Ah

Output power

1200 W

Input frequency

50/60 Hz

USB 2.0 ports quantity

1

Display type

LCD

Ethernet LAN (RJ-45) ports

2

Input operation voltage (min)

162 V

Cold start

Yes

AC outlets quantity

4 AC outlet(s)

Output power capacity

1.5 kVA

Waveform

Pseudo sine

Auto-restart

Yes

AC outlet types

Type E / F

Input operation voltage (max)

290 V

Audible alarm(s)

Yes

Battery voltage

12 V

UPS topology

Line-Interactive

Automatic Voltage Regulation (AVR)

Yes

Surge protection

Yes

Nominal input voltage

230 V

Nominal output voltage

230 V

Output voltage regulation

10%

RS-232 ports

1

Serial interface type

RS-232

Output frequency

50 Hz

Noise Level

40 dB

Serial ports quantity

1

Power plug

Type F

Product colour

Black

Harmonized System (HS) code

85078000

Serial interface

Yes

Package volume

26237.1 cm³

USB port type

USB Type-B

UK Trade Tariff code

85044085

Audible alarm modes

Alarm when on battery, Fault, Low battery alarm, Overload alarm

Power factor

0.6

Surge protection features

Digital Subscriber Line (DSL)

Number of input phases

1

Number of output phases

1

Transfer time (Line Mode to Battery Mode)

2 ms

Battery recharge time (90%)

6 h

Warnings

Do not disassemble the unit housing, there may be a risk of electric shock.
