POWER WALKER

    PowerWalker VFI 3000 TGB Double-conversion (Online) 3 kVA 2700 W 5 AC outlet(s)

    €526.71
    Tax included
    Quantity

    Add to favorites Add to compare

    Product Details

    POWER WALKER
    WLONONWCRFPY6
    8 Items

    Data sheet

    Width
    190 mm
    Height
    328 mm
    Depth
    399 mm
    Weight
    22.2 kg
    Package height
    464 mm
    Package width
    324 mm
    Number of batteries supported
    6
    Cables included
    Input power cable, USB cable
    Manual
    Yes
    Operating temperature (T-T)
    0 - 40 °C
    Operating relative humidity (H-H)
    0 - 95%
    USB port
    Yes
    Battery capacity
    9 Ah
    Battery recharge time
    4 h
    Output power
    2700 W
    Input frequency
    40 - 70 Hz
    Display type
    LCD
    Efficiency
    90%
    Input operation voltage (min)
    176 V
    AC outlets quantity
    5 AC outlet(s)
    Output power capacity
    3 kVA
    Output operation voltage (max)
    240 V
    Waveform
    Sine
    AC outlet types
    C19 coupler
    Input operation voltage (max)
    300 V
    Battery voltage
    12 V
    Output operation voltage (min)
    220 V
    UPS topology
    Double-conversion (Online)
    Typical backup time at full load
    3.9 min
    Typical backup time at half load
    11.7 min
    RS-232 ports
    1
    Noise Level
    50 dB
    Power plug
    C20 coupler
    Product colour
    Black
    Harmonized System (HS) code
    85078000
    Output voltage Total Harmonic Distortion (THD)
    5%
    Power factor
    0.9
    Crest factor
    3:1
    Emergency Power Off (EPO)
    Yes
    Emergency Power Off (EPO) connector
    Yes
    Input current Total Harmonic Distortion (THD)
    5%
    Warnings
    Do not disassemble the unit housing, there may be a risk of electric shock.
