APC Smart-UPS X 1500 Rack/Tower LCD -

Product Details

Reference WLONONWCRDZCX

In stock 2 Items

Data sheet

Cable length

1.83 m

Width

432 mm

Height

89 mm

Depth

490 mm

Weight

24.8 kg

Package depth

620 mm

Package height

246 mm

Package width

589 mm

Package weight

30 kg

Cables included

RS-232, USB cable

Storage relative humidity (H-H)

0 - 95%

Operating temperature (T-T)

0 - 40 °C

Operating relative humidity (H-H)

0 - 95%

Storage temperature (T-T)

-15 - 45 °C

Form factor

Rackmount/Tower

USB port

Yes

LED indicators

Yes

Battery technology

Sealed Lead Acid (VRLA)

Battery life (max)

5 year(s)

Battery capacity

311 VAh

Battery recharge time

3 h

Output power

1200 W

Input frequency

50/60 Hz

Efficiency

98.5%

Input operation voltage (min)

151 V

Cold start

Yes

AC outlets quantity

8 AC outlet(s)

Output power capacity

1.5 kVA

Waveform

Sine

Auto-restart

Yes

AC outlet types

C13 coupler

Input operation voltage (max)

302 V

Audible alarm(s)

Yes

UPS topology

Line-Interactive

Typical backup time at full load

5.8 min

Automatic Voltage Regulation (AVR)

Yes

Automatic battery test

Yes

Typical backup time at half load

17.2 min

Nominal input voltage

230 V

Nominal output voltage

230 V

Output frequency regulation

50/60 Hz

Operating altitude

0 - 3000 m

Quick installation guide

Yes

Noise Level

40 dB

Surge energy rating

645 J

Power plug

C14 coupler

Non-operating altitude

0 - 15000 m

Product colour

Black

Harmonized System (HS) code

85078000

Products per pallet

8 pc(s)

Software CD

Yes

Hot-swap battery

Yes

Compliance certificates

RoHS

Total carbon footprint (kg of CO2e)

1419.64

Audible alarm modes

Low battery alarm, Overload alarm

Number of output IEC jumpers

2

SmartSlot

Yes

Emergency Power Off (EPO)

Yes

Rack capacity

2U

Rack mount kit

Yes
