Prekė detaliau
Charakteristikos
- Width
- 190 mm
- Height
- 328 mm
- Depth
- 399 mm
- Weight
- 22.2 kg
- Package height
- 464 mm
- Package width
- 324 mm
- Number of batteries supported
- 6
- Cables included
- Input power cable, USB cable
- Manual
- Yes
- Operating temperature (T-T)
- 0 - 40 °C
- Operating relative humidity (H-H)
- 0 - 95%
- USB port
- Yes
- Battery capacity
- 9 Ah
- Battery recharge time
- 4 h
- Output power
- 2700 W
- Input frequency
- 40 - 70 Hz
- Display type
- LCD
- Efficiency
- 90%
- Input operation voltage (min)
- 176 V
- AC outlets quantity
- 5 AC outlet(s)
- Output power capacity
- 3 kVA
- Output operation voltage (max)
- 240 V
- Waveform
- Sine
- AC outlet types
- C19 coupler
- Input operation voltage (max)
- 300 V
- Battery voltage
- 12 V
- Output operation voltage (min)
- 220 V
- UPS topology
- Double-conversion (Online)
- Typical backup time at full load
- 3.9 min
- Typical backup time at half load
- 11.7 min
- RS-232 ports
- 1
- Noise Level
- 50 dB
- Power plug
- C20 coupler
- Product colour
- Black
- Harmonized System (HS) code
- 85078000
- Output voltage Total Harmonic Distortion (THD)
- 5%
- Power factor
- 0.9
- Crest factor
- 3:1
- Emergency Power Off (EPO)
- Yes
- Emergency Power Off (EPO) connector
- Yes
- Input current Total Harmonic Distortion (THD)
- 5%
- Warnings
- Do not disassemble the unit housing, there may be a risk of electric shock.
Greitas palyginimas
Prekė |
APC Back-UPS Pro, 1500VA/865W, Tower, 230V, 10x IEC C13 outlets, AVR, LCD, User Replaceable Battery
|
|
UPS Armac Office 3000VA ON-LINE PF1 Dust Free
|
PowerWalker VFI 2000CRM LCD Double-conversion (Online) 2 kVA 1600 W 4 AC outlet(s)
|
Prieinamumas |
|
|
|
|
Kaina |
532,37 €
|
537,16 €
|
537,72 €
|
539,09 €
|
Aprašymas |
Eaton 9E1000IR 9E UPS, 1000 VA, 900 W, Input: C14, Outputs: (4) C13, Rack, 2U | |||
Warranty |
36 month(s) | |||
Net weight |
17.6 kg | |||
Gross weight |
18.6 kg | |||
WEEE tax |
Yes | |||
Packing quantity |
1 pc(s) | |||
Volume (m3) |
0.0172304 m | |||
Tare weight (kg) |
1 kg | |||
Gross depth (mm) |
440 mm | |||
Gross width (mm) |
440 mm | |||
Gross height (mm) |
89 mm | |||
WEE classification |
CL109:6:2017-04-01 | |||
Paper/Pasteboard |
800 g | |||
Embeeded battery |
Yes | |||
TI weight (kg) |
8 kg | |||
Width |
112 mm | 438 mm | ||
Height |
301 mm | 88 mm | ||
Depth |
380 mm | 410 mm | ||
Plastic (No PET) |
200 g | |||
Composition of battery |
CL127:KT:2016-12-09 | |||
Classification of battery |
CL126:NE:2016-12-09 | |||
Type of battery |
Battery | |||
Weight |
12.7 kg | 19 kg | ||
Package depth |
488 mm | |||
Package height |
387 mm | |||
Package width |
238 mm | |||
Package weight |
14.3 kg | |||
Number of batteries supported |
4 | |||
Cables included |
Phone (RJ-11), USB cable | |||
Storage relative humidity (H-H) |
0 - 95% | |||
Manual |
Yes | |||
Operating temperature (T-T) |
0 - 40 °C | 0 - 40 °C | ||
Operating relative humidity (H-H) |
0 - 95% | 20 - 90% | ||
Storage temperature (T-T) |
-15 - 40 °C | |||
Form factor |
Rackmount/Tower | |||
USB port |
Yes | |||
Battery technology |
Sealed Lead Acid (VRLA) | |||
Battery life (max) |
5 year(s) | |||
Battery capacity |
187 VAh | 9 Ah | ||
Palette Qty |
54 pc(s) | |||
Battery recharge time |
8 h | 4 h | ||
Cooling type |
Active | |||
Output power |
865 W | 1600 W | ||
Input frequency |
50/60 Hz | 40/70 Hz | ||
USB 2.0 ports quantity |
1 | |||
Display type |
LCD | LCD | ||
Efficiency |
98.9% | 89% | ||
Input operation voltage (min) |
156 V | 110 V | ||
Cold start |
Yes | |||
AC outlets quantity |
10 AC outlet(s) | 4 AC outlet(s) | ||
Output power capacity |
1.5 kVA | 2 kVA | ||
Output operation voltage (max) |
240 V | |||
Waveform |
Sine | Sine | ||
AC outlet types |
C13 coupler | |||
Input operation voltage (max) |
300 V | 300 V | ||
Audible alarm(s) |
Yes | Yes | ||
Battery voltage |
12 V | |||
Output operation voltage (min) |
220 V | |||
UPS topology |
Line-Interactive | Double-conversion (Online) | ||
Typical backup time at full load |
3.7 min | |||
Warranty card |
Yes | |||
Automatic Voltage Regulation (AVR) |
Yes | |||
Automatic battery test |
Yes | |||
Typical backup time at half load |
12.4 min | |||
Surge protection |
Yes | |||
Nominal input voltage |
230 V | |||
Nominal output voltage |
230 V | |||
Output frequency regulation |
50/60 Hz | 47 / 53 Hz | ||
Output voltage regulation |
1% | |||
RS-232 ports |
1 | |||
Operating altitude |
0 - 9000 m | |||
Noise Level |
45 dB | 50 dB | ||
Surge energy rating |
441 J | |||
Power plug |
C14 coupler | |||
Non-operating altitude |
0 - 15000 m | |||
Product colour |
Black | Black | ||
Harmonized System (HS) code |
85078000 | |||
Sustainability certificates |
ENERGY STAR | |||
Products per pallet |
20 pc(s) | |||
Software CD |
Yes | |||
Products per master (outer) case |
1 pc(s) | |||
Hot-swap battery |
Yes | |||
Producer |
Eaton | |||
Compliance certificates |
RoHS | |||
Audible alarm modes |
Low battery alarm, Overload alarm | |||
Hold time (max) |
12 ms | |||
Hold time (min) |
10 ms | |||
Surge protection features |
Digital Subscriber Line (DSL) | |||
Number of output IEC jumpers |
2 | |||
Replacement battery cartridge |
APCRBC124 | |||
Crest factor |
3:1 | |||
Input power factor |
0.99 | |||
Number of input phases |
1 | |||
