IP network camera 4MP 2K IPC-HDW5442T-ZE
    DAHUA TECHNOLOGY CO., LTD

    IP network camera 4MP 2K IPC-HDW5442T-ZE

    €363.37
    Tax included
    Quantity

    Camera
    Image Sensor 1/1.8”4Megapixel progressive CMOS
    Max. Resolution 2688 (H) × 1520 (V)
    ROM 128 MB
    RAM 1GB
    Scanning System Progressive
    Electronic Shutter Speed Auto/Manual 1/3 s–1/100,000 s
    Min. Illumination 0.003Lux@F1.8
    S/N Ratio >56 dB
    Illumination Distance 40 m (131.2 ft) (IR LED)
    Illuminator On/Off Control Auto/Manual
    Illuminator Number 2 (IR LED)
    Pan/Tilt/Rotation Range Pan: 0°–360°
    Tilt: 0°–78°
    Rotation: 0°–360°
    Lens
    Lens Type Motorized vari-focal
    Mount Type f14
    Focal Length 2.7 mm-12 mm
    Max. Aperture F1.8
    Field of View Horizontal: 114°–47°
    Vertical: 62°–26°
    Diagonal: 136°–54°
    Iris Type Auto
    Close Focus Distance 1.2 m (3.9 ft)
    DORI Distance Lens Detect Observe Recognize Identify
    W 58 m (190.3 ft) 23 m (75.5 ft) 12 m (39.4 ft) 6 m (19.7 ft)
    T 131 m (429.8 ft) 52 m (170.6 ft) 26 m (85.3 ft) 13 m (42.7 ft)
    Smart Event
    IVS Abandoned object; missing object
    Heat Map Yes
    Professional, intelligent
    IVS (Perimeter Protection) Tripwire; intrusion; fast moving (the three functions support the classification and accurate detection of vehicle and human); loitering detection; people gathering; parking detection
    Face Detection Face detection; track; optimization; snapshot; report high quality picture; face enhancement; face exposure; face attribute extract, 6 attributes and 8 expressions: Gender, age, glasses, expressions (anger, calm, happiness, sadness, disgust, surprise, confusion and fear), mask, beard; face matting setting: face, single inch photo; three snapshot methods: real-time snapshot, optimization snapshot, quality priority; face angle filter; optimization time setting
    People Counting Support the counting of enter number, leave number, and pass number, and displaying and outputting yearly/monthly/weekly/daily reports.
    Support the counting of number in area, and 4 rules configuration. Count number of people or stay time and link alarm.
    Support queue management, and 4 rules configuration. Count number of people or stay time and link alarm
    Intelligent Search Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos
    Video
    Video Compression H.265; H.264; H.264H; H.264B; MJPEG (only supported by the sub stream)
    Smart Codec Smart H265+/H264+
    Video Frame Rate Main stream: 2688 × 1520 (1 fps–25/30 fps)
    1920 × 1080 (1 fps–50/60 fps)
    Sub stream: D1 (1 fps–50/60 fps)
    Third stream: 1080p (1 fps–25/30 fps)
    Stream Capability 3 streams
    Resolution 2688 × 1520; 2560 × 1440; 2304 × 1296; 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)
    Bit Rate Control CBR/VBR
    Video Bit Rate H.264: 32 kbps–8192 kbps
    H.265: 19 kbps–8192 kbps
    Day/Night Auto (ICR)/Color/B/W
    BLC Yes
    HLC Yes
    WDR 140 dB
    Scene Self-adaptation Yes
    White Balance Auto/natural/street lamp/outdoor/manual/regional custom
    Gain Control Auto/Manual
    Noise Reduction 3D DNR
    Motion Detection OFF/ON (4 areas, rectangular)
    Region of Interest (RoI) Yes (4 areas)
    Electronic Image Stabilization (EIS) Yes
    Smart Illumination Yes
    Defog Yes
    Image Rotation 0°/90°/180°/270° (Support with 2688 × 1520 resolution and lower)
    Mirror Yes
    Privacy Masking 4 areas
    Audio
    Built-in MIC Yes
    Audio Compression G.711a; G.711Mu; G.726; AAC; G.723
    Alarm
    Alarm Event No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; defocus detection; scene changing; tripwire; intrusion; abandoned object; missing object; fast moving; parking detection; loitering detection; people gathering; audio detection; people counting; face detection; voltage detection; people counting in area; stay alarm; people No. exception detection, queue management
    Network
    Network RJ-45 (10/100 Base-T)
    SDK and API Yes
    Protocol IPv4; IPv6; HTTP; HTTPS; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; 802.1x; SNMP
    Interoperability ONVIF (Profile S/Profile G/Profile T); CGI; Milestone; Genetec; P2P
    User/Host 20 (Total bandwidth: 80 M)
    Storage FTP; SFTP; Micro SD Card (support max. 256 G); Dahua Cloud; NAS
    Browser IE: IE8 and later
    Chrome
    Firefox
    Safari: Safari 12 and later
    Management Software Smart PSS, DSS, DMSS
    Mobile Phone IOS; Android
    Certification
    Certification CE-LVD: EN62368-1
    CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
    FCC: 47 CFR FCC Part 15, Subpart B
    UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07
    Power
    Power Supply 12V DC (±30%)/PoE (802.3af)
    Power Consumption <7.5W
    Environment
    Operating Conditions –30°C to +60°C (–22°F to +140°F)/Less than 95% RH
    Strorage Conditions –40°C to +60°C (–40°F to +140°F)
    Protection Grade IP67
    Structure
    Casing Inner core: Metal
    Cover: Metal
    Decoration ring: Plastic Decoration ring
    Dimensions F122.0 mm × 108.3 mm (F4.8" × 4.3")
    Net Weight 740 g (1.6 lb)
    Gross Weight 910 g (2.0 lb)
