Product Details
Data sheet
- Type
- IP security camera
- Width
- 78.8 mm
- Height
- 78.6 mm
- Connectivity technology
- Wired
- Weight
- 860 g
- Package depth
- 136 mm
- Package height
- 141 mm
- Package width
- 315 mm
- Package weight
- 1.27 kg
- Power source type
- DC, PoE
- Operating temperature (T-T)
- -30 - 60 °C
- Operating relative humidity (H-H)
- 0 - 95%
- Mounting type
- Wall
- Form factor
- Bullet
- Bluetooth
- No
- Bit rate
- 32 Kbps - 16 Mbps
- Noise reduction
- Yes
- Length
- 215.2 mm
- Sensor type
- CMOS
- Wi-Fi
- No
- Compatible memory cards
- microSDHC
- Maximum memory card size
- 256 GB
- Power consumption (max)
- 6 W
- Maximum resolution
- 3840 x 2160 pixels
- Placement supported
- Outdoor
- Card reader integrated
- Yes
- Ethernet LAN (RJ-45) ports
- 1
- Number of languages
- 33
- Housing material
- Metal
- Networking standards
- IEEE 802.3af
- Ethernet LAN
- Yes
- Supported graphics resolutions
- 1920 x 1080 (HD 1080)
- International Protection (IP) code
- IP67
- Ethernet interface type
- Fast Ethernet
- Supported video modes
- 480p
- Video formats supported
- H.265+
- Number of Users
- 32 user(s)
- Reset button
- Yes
- Password protection
- Yes
- Languages support
- Multi
- Frame Rate
- 30 fps
- Product colour
- White
- Tilt angle range
- 0 - 90°
- Fixed focal length
- 2.8 mm
- Web browser
- Yes
- Night vision
- Yes
- Total megapixels
- 8 MP
- Optical sensor size
- 25.4 / 2 mm (1 / 2")
- Pan range
- 0 - 360°
- Lens viewing angle, diagonal
- 124°
- Video compression formats
- H.264
- Angle of rotation
- 360°
- DC output current
- 0.5 A
- DC output voltage
- 12
- Video motion detection
- Yes
- Camera pan control
- Yes
- Camera tilt control
- Yes
- Night vision distance
- 40 m
- Number of lenses
- 1
- Day/night mode
- Yes
- Lens viewing angle, vertical
- 52°
- Noise reduction technology
- 3D noise reduction
- Region of Interest (ROI) encoding
- Yes
- Maximum aperture number
- 1
- Lens viewing angle, horizontal
- 102°
- Number of sensors
- 1
- Wide Dynamic Range (WDR)
- Yes
- Progressive scan
- Yes
- Mirror
- Yes
- Heartbeat
- Yes
- Anti-flicker
- Yes
- Back Light Compensation (BLC)
- Yes
- Video streaming
- Yes
- Active tampering alarm
- Yes
- IP address filtering
- Yes
- Camera shutter speed
- 1/3 - 1/100000 s
- Bit rate control
- Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
- Gain control type
- Auto
- Privacy masking
- Yes
- Highlight Compensation (HLC)
- Yes
- Power consumption (Power over Ethernet (PoE))
- 7.5 W
- HTTPS encryption
- Yes
- Behavior analysis
- Intrusion detection, Line crossing detection, Region entrance detection, Region exiting detection
- Image quality adjustment
- Saturation
Quick Compare
Product |
HIKVISION IP CAMERA DS-2CD2T87G2P-LSU/SL (4MM) (C) | KAMERA IP HIKVISION DS-2DE4215IW-DE(T5) | 4K IP Network Camera 8MP HFW3849T1-AS-PV-S4 3.6mm black | 4K IP Network Camera 8MP HFW3849T1-AS-PV-S4 2.8mm Black |
Availability |
|
|
|
|
Price |
€304.60
|
€306.76
|
€309.73
|
€309.73
|
Description |
||||
Type |
IP security camera | IP security camera | ||
Width |
118.6 mm | |||
Height |
290 mm | |||
Connectivity technology |
Wired | Wired | ||
Weight |
1.42 kg | 2 kg | ||
Power source type |
DC, PoE | DC, PoE | ||
Storage relative humidity (H-H) |
0 - 95% | |||
Manual |
Yes | |||
Operating temperature (T-T) |
-30 - 60 °C | -30 - 65 °C | ||
Operating relative humidity (H-H) |
0 - 95% | 0 - 90% | ||
Storage temperature (T-T) |
-30 - 60 °C | |||
Mounting type |
Ceiling/wall | Ceiling/wall | ||
Form factor |
Bullet | Dome | ||
Built-in microphone |
Yes | |||
Material |
Metal | |||
Bluetooth |
No | No | ||
Sample rate |
48 kHz | |||
Bit rate |
32 Kbps - 16 Mbps | |||
Noise reduction |
Yes | |||
Protection features |
Dust resistant | |||
Length |
305.4 mm | |||
Sensor type |
CMOS | CMOS | ||
Wi-Fi |
No | No | ||
Compatible memory cards |
SDXC | MicroSDXC | ||
Maximum memory card size |
256 GB | 256 GB | ||
Signal-to-Noise Ratio (SNR) |
52 dB | |||
Power consumption (max) |
9.5 W | 24 W | ||
Maximum resolution |
1920 x 1080 pixels | |||
Built-in speaker(s) |
Yes | |||
Placement supported |
Indoor & outdoor | Outdoor | ||
Card reader integrated |
Yes | Yes | ||
Ethernet LAN (RJ-45) ports |
1 | 1 | ||
Number of languages |
33 | |||
Audio output channels |
1 channels | |||
Networking standards |
IEEE 802.3at | |||
Security algorithms |
EAP-MD5 | |||
Ethernet LAN |
Yes | Yes | ||
Focus |
Motorized/Manual | |||
Supported graphics resolutions |
5120 x 1440 | 352 x 288 | ||
Zoom capability |
Yes | |||
Diameter |
10.5 cm | 16.4 cm | ||
International Protection (IP) code |
IP67 | IP66 | ||
Digital zoom |
16x | |||
Auto focus |
Yes | |||
Ethernet interface type |
Fast Ethernet | Fast Ethernet | ||
Optical Zoom |
15x | |||
Number of Users |
32 user(s) | 32 user(s) | ||
Web-based management |
Yes | |||
Quality of Service (QoS) support |
Yes | |||
Supported network protocols |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, WebSocket, WebSockets | |||
Reset button |
Yes | Yes | ||
Password protection |
Yes | Yes | ||
Frame Rate |
20 fps | 30 fps | ||
Product colour |
White | White | ||
Tilt angle range |
0 - 90° | -15 - 90° | ||
Focal length range |
5 - 75 mm | |||
Fixed focal length |
4 mm | |||
Web browser |
Yes | Yes | ||
Voice codecs |
PCM | |||
LED type |
IR | |||
Night vision |
Yes | |||
Total megapixels |
8 MP | 2 MP | ||
Motion sensor |
Yes | Yes | ||
PTZ control |
Yes | |||
Optical sensor size |
25.4 / 1.8 mm (1 / 1.8") | 25.4 / 2.8 mm (1 / 2.8") | ||
White balance |
Indoor | |||
Minimum illumination |
0.0005 lx | |||
Pan range |
0 - 360° | 0 - 360° | ||
Dynamic range |
130 dB | 120 dB | ||
Video compression formats |
M-JPEG | H.264 | ||
Angle of rotation |
360° | |||
Aperture |
F1.0 | |||
DC output voltage |
12 | 12 | ||
Video motion detection |
Yes | |||
Number of cameras |
1 | 1 | ||
Camera pan control |
Yes | Yes | ||
Camera tilt control |
Yes | Yes | ||
Night vision distance |
100 m | |||
Number of lenses |
2 | 1 | ||
Day/night mode |
Yes | Yes | ||
Preset points |
Yes | |||
Infrared (IR) cut-off filter |
Yes | |||
Built-in HDD |
No | |||
Lens viewing angle, vertical |
44° | |||
Noise reduction technology |
3D noise reduction | |||
Region of Interest (ROI) encoding |
Yes | |||
Maximum aperture number |
1.6 | |||
Lens viewing angle, horizontal |
180° | |||
Number of sensors |
2 | 1 | ||
Wide Dynamic Range (WDR) |
Yes | Yes | ||
Progressive scan |
Yes | Yes | ||
Mirror |
Yes | |||
Heartbeat |
Yes | |||
Anti-flicker |
Yes | |||
Digital watermark |
Yes | |||
Back Light Compensation (BLC) |
Yes | Yes | ||
Video streaming |
Yes | |||
Active tampering alarm |
Yes | Yes | ||
Alarm input/output |
Yes | Yes | ||
IP address filtering |
Yes | Yes | ||
Intelligent Video Surveillance (IVS) system features |
Scene change | Face detection | ||
Camera shutter speed |
1/3 - 1/100000 s | 1/30000 s | ||
Bit rate control |
Constant Bit Rate (CBR)/Variable Bit Rate (VBR) | |||
Privacy masking |
Yes | Yes | ||
Highlight Compensation (HLC) |
Yes | Yes | ||
Live view |
Yes | Yes | ||
HTTPS encryption |
Yes | Yes | ||
Image quality adjustment |
Contrast | Brightness | ||
Password reset via email |
Yes | |||
Number of simultaneous live view channels |
6 channels | |||
User access level |
Administrator, Operator, User | Administrator, Operator, User | ||
Built-in light |
Yes | |||
Pan speed |
80 °/sec | |||
Audio input channels |
1 channels | |||
Pixel counter |
Y | |||
Human and vehicle targets classification |
Yes | |||
Tilt speed |
80 °/sec | |||
Pan preset speed |
80 °/sec | |||
PTZ modes |
Auto scan | |||
Alarm output channels |
1 | |||
Alarm input channels |
1 | |||
Preset programs quantity |
300 | |||
