IP network camera 4MP HFW5442E-ZE black
    DAHUA TECHNOLOGY CO., LTD

    IP network camera 4MP HFW5442E-ZE black

    €340.87
    Tax included
    Quantity

    Add to favorites Add to compare
    Camera
    Image Sensor 1/1.8" CMOS
    Max. Resolution 2688 (H) × 1520 (V)
    ROM 128 MB
    RAM 1GB
    Scanning System Progressive
    Electronic Shutter Speed Auto/Manual 1/3 s–1/100,000 s
    Min. Illumination 0.003 lux@F1.8 (Color, 30 IRE)
    0.0003 lux@F1.8 (B/W, 30 IRE)
    0 lux (Illuminator on)
    S/N Ratio >56 dB
    Illumination Distance 60 m (196.85 ft) (IR)
    Illuminator On/Off Control Auto
    Illuminator Number 4 (IR LED)
    Pan/Tilt/Rotation Range Pan: 0°–360°
    Tilt: 0°–90°
    Rotation: 0°–360°
    Lens
    Lens Type Motorized vari-focal
    Lens Mount ?14
    Focal Length 2.7 mm–12 mm
    Max. Aperture F1.8
    Field of View Horizontal: 114°–47°
    Vertical: 62°–26°
    Diagonal: 136°–56°
    Iris Control Auto
    Close Focus Distance 1.2 m (3.94 ft)
    DORI Distance Lens Detect Observe Recognize Identify
    W 57.5 m (188.65 ft) 23.0 m (75.46 ft) 11.5 m (37.73 ft) 5.7 m (18.70 ft)
    T 130.7 m (428.81 ft) 52.3 m (171.59 ft) 26.1 m (85.63 ft) 13.1 m (42.98 ft)
    Smart Event
    IVS Abandoned object; missing object
    Heat Map Yes
    Professional, intelligent
    IVS (Perimeter Protection) Intrusion, tripwire, fast moving (the three functions support the classification and accurate detection of vehicle and human); loitering detection, people gathering, and parking detection
    SMD 3.0 Less false alarm, longer detection distance
    Face Detection Face detection; track; snapshot; snapshot optimization; optimal face snapshot upload; face enhancement; face exposure; face attributes extraction including 6 attributes (gender, age, glasses, expressions, mask, and beard) and 8 expressions (angry, sad, disgusted, scared, surprised, calm, happy, confused); face snapshot set as face or one-inch photo; snapshot strategies (real-time snapshot, quality priority and optimization snapshot); face angle filter; optimization time setting
    People Counting Tripwire people counting and people counting in area; generating and exporting report (day/month/year); queue management; 4 rules can be set for tripwire, people counting in area and queue management
    Smart Search Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos
    Video
    Video Compression H.265; H.264; H.264H; H.264B; MJPEG (Only supported by the sub stream)
    Smart Codec Smart H.265+; Smart H.264+
    AI Coding AI H.265; AI H.264
    Video Frame Rate Main stream: 2688 × 1520@(1 fps–25/30 fps)
    Sub stream: D1@(1 fps–50/60 fps)
    Third stream: 1080p@(1 fps–50/60 fps)
    *The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity.
    Stream Capability 3 streams
    Resolution 2688 × 1520; 2304 × 1296; 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)
    Bit Rate Control CBR/VBR
    Video Bit Rate H.264: 32 kbps–8192 kbps
    H.265: 32 kbps–8192 kbps
    Day/Night Auto(ICR)/Color/B/W
    BLC Yes
    HLC Yes
    WDR 140 dB
    Scene Self-adaptation (SSA) Yes
    White Balance Auto; natural; street lamp; outdoor; manual; regional custom
    Gain Control Auto;Manual
    Noise Reduction 3D NR
    Motion Detection OFF/ON (4 areas, rectangular)
    Region of Interest (RoI) Yes (4 areas)
    Image Stabilization Electronic Image Stabilization (EIS)
    Smart Illumination Yes
    Defog Yes
    Image Rotation 0°/90°/180°/270°
    Mirror Yes
    Privacy Masking 8 areas
    Audio
    Audio Compression PCM; G.711a; G.711Mu; G.726; G.723
    Alarm
    Alarm Event No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; defocus detection; tripwire; intrusion; fast moving; abandoned object; missing object; loitering detection; people gathering; parking detection; scene changing; input error; voltage detection; face detection; people counting in area; stay detection; people counting; people number error detection; queue management; intensity change
    Network
    Network Port RJ-45 (10/100 Enhancement Base-T)
    SDK and API Yes
    Cyber Security Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade
    Network Protocol IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP; Bonjour
    Interoperability ONVIF (Profile S/Profile G/Profile T); CGI; P2P; Milestone
    User/Host 20 (Total bandwidth: 88 M)
    Storage FTP; SFTP; Micro SD card (support max. 256 GB); NAS
    Browser IE: IE8 and later
    Chrome
    Firefox
    Management Software Smart PSS, DSS, DMSS
    Mobile Client iOS; Android
    Certification
    Certifications CE-LVD: EN 62368-1
    CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
    FCC: 47 CFR FCC Part 15, Subpart B
    UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07
    Port
    Audio Input 1 channel (RCA port)
    Audio Output 1 channel (RCA port)
    Alarm Input 2 channels in: 5 mA 3–5 VDC
    Alarm Output 1 channel out: 300 mA 12 VDC
    Power
    Power Supply 12 VDC (±30%); PoE (802.3af); ePoE
    Power Consumption Basic: 3 W (12 VDC); 3.7 W (PoE)
    Max. (max. stream + IR LED + focus): 9.9 W (12 VDC); 10.9 W (PoE)
    Environment
    Operating Temperature –30 °C to +60 °C (–22 °F to +140 °F)
    Operating Humidity ?95%
    Storage Temperature –40 °C to +60 °C (–40 °F to +140 °F)
    Protection IP67
    Structure
    Casing Metal + plastic
    Product Dimensions 273.2 mm × 95 mm × 95 mm (10.76" × 3.74" × 3.74") (L × W × H)
    Net Weight 1110 g (2.45 lb)
    Gross Weight 1510 g (3.33 lb)
