Product Details
Data sheet
- Type
- IP security camera
- Width
- 111 mm
- Height
- 83.7 mm
- Depth
- 111 mm
- Connectivity technology
- Wired
- Weight
- 480 g
- Power source type
- DC, PoE
- Storage relative humidity (H-H)
- 0 - 95%
- Operating temperature (T-T)
- -30 - 60 °C
- Operating relative humidity (H-H)
- 0 - 95%
- Storage temperature (T-T)
- -40 - 60 °C
- Mounting type
- Ceiling/wall
- Form factor
- Turret
- Built-in microphone
- Yes
- Sample rate
- 8 kHz
- Bit rate
- 6 Mbps
- Noise reduction
- Yes
- Sensor type
- CMOS
- Signal-to-Noise Ratio (SNR)
- 52 dB
- Power consumption (max)
- 10.1 W
- Maximum resolution
- 2688 x 1520 pixels
- Built-in speaker(s)
- Yes
- Placement supported
- Indoor & outdoor
- Ethernet LAN (RJ-45) ports
- 1
- DC-in jack
- Yes
- Housing material
- Metal
- Ethernet LAN
- Yes
- Supported graphics resolutions
- 1280 x 720 (HD 720)
- International Protection (IP) code
- IP67
- Ethernet interface type
- Fast Ethernet
- Supported network protocols
- TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS
- Password protection
- Yes
- Frame Rate
- 60 fps
- Product colour
- White
- Tilt angle range
- 0 - 85°
- Focal length range
- 2.8 mm
- Fixed focal length
- 2.8 mm
- LED type
- IR/White
- Night vision
- Yes
- Total megapixels
- 4 MP
- Optical sensor size
- 25.4 / 2.7 mm (1 / 2.7")
- Minimum illumination
- 0.005 lx
- Pan range
- 0 - 360°
- Dynamic range
- 120 dB
- Lens viewing angle, diagonal
- 118°
- Video compression formats
- H.264+
- Number of cameras
- 1
- Camera pan control
- Yes
- Camera tilt control
- Yes
- Night vision distance
- 30 m
- Number of lenses
- 1
- Privacy protection
- Yes
- Day/night mode
- Yes
- Infrared (IR) cut-off filter
- Yes
- Lens viewing angle, vertical
- 54°
- Noise reduction technology
- 3D noise reduction
- Smart IR
- Yes
- Region of Interest (ROI) encoding
- Yes
- Maximum aperture number
- 1.6
- Lens diameter
- 2.8 mm
- Lens viewing angle, horizontal
- 100°
- Infra-red wavelength
- 850 nm
- Wide Dynamic Range (WDR)
- Yes
- Progressive scan
- Yes
- IP address filtering
- Yes
- Camera shutter speed
- 1/3 - 1/10000 s
- Bit rate control
- Constant Bit Rate (CBR), Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
- Number of illumination LEDs
- 4
- Digest authentication
- Yes
- Detect distance
- 64 m
- Observe distance
- 27 m
- Recognize distance
- 13 m
- Identify distance
- 6 m
- Minimum aperture number
- 1.6
- Bit rate range
- 64 - 64 Kbit/s
- Number of Privacy masking areas
- 4
Quick Compare
Product |
IP camera Hikvision DS-2CD1043G2-LIU(2.8mm)
|
DAHUA Camera 1/2.7" 5 Mpx, Smart H.265/H.264, 20 fps @ 5Mpx (2880 × 1620), (2688 × 1520) @25/30 fps, , 2.8mm IPC-HDW1530T-028
|
|
KAMERA IP DAHUA IPC-HDW2249TM-S-IL-0280B
|
Availability |
|
|
|
|
Price |
€94.16
|
€94.17
|
€94.28
|
€94.85
|
Description |
||||
Type |
IP security camera | IP security camera | IP security camera | IP security camera |
Width |
69.1 mm | 74 mm | 121.9 mm | |
Height |
66 mm | 70.1 mm | 260 mm | 99.1 mm |
Depth |
162.1 mm | 131 mm | 121.9 mm | |
Connectivity technology |
Wired | Wired | Wireless | Wired |
Weight |
270 g | 320 g | 800 g | 460 g |
Package depth |
121 mm | 120 mm | ||
Package height |
118 mm | 300 mm | ||
Package width |
216 mm | 185 mm | ||
Package weight |
481 g | 450 g | ||
Power source type |
DC, PoE | DC, PoE | AC | DC, PoE |
Storage relative humidity (H-H) |
0 - 95% | 0 - 95% | ||
Operating temperature (T-T) |
-30 - 60 °C | -40 - 60 °C | -20 - 50 °C | -40 - 60 °C |
Operating relative humidity (H-H) |
0 - 95% | 0 - 95% | 0 - 95% | |
Storage temperature (T-T) |
-30 - 60 °C | -40 - 60 °C | -40 - 60 °C | |
Mounting type |
Ceiling/wall | Ceiling/wall | Ceiling/wall | Wall/ceiling |
Form factor |
Bullet | Bullet | Cube | Tube/dome |
Built-in microphone |
Yes | Yes | Yes | |
LED indicators |
No | |||
Bluetooth |
No | No | No | |
Bit rate |
32 Kbps - 8 Mbps | |||
Noise reduction |
Yes | |||
Mobile operating systems supported |
Android | Android | ||
Protection features |
Dust resistant | |||
Sensor type |
CMOS | CMOS | CMOS | HD CMOS |
Wi-Fi |
No | Yes | No | |
Internal memory |
128 MB | |||
Compatible memory cards |
MicroSD (TransFlash) | |||
Signal-to-Noise Ratio (SNR) |
56 dB | 18.5 dB | 56 dB | |
Power consumption (max) |
5 W | 20 W | 3.8 W | |
Power consumption (typical) |
1.9 W | 1.6 W | ||
Maximum resolution |
2560 x 1440 pixels | 2880 x 1620 pixels | 1920 x 1080 pixels | 1920 x 1080 pixels |
Built-in speaker(s) |
Yes | |||
Placement supported |
Indoor & outdoor | Indoor & outdoor | Outdoor | Outdoor |
Card reader integrated |
Yes | |||
Ethernet LAN (RJ-45) ports |
1 | 1 | ||
Number of languages |
2 | |||
Housing material |
Plastic | Metal | Metal, Plastic | |
Networking standards |
IEEE 802.3af | |||
Security algorithms |
HTTPS | |||
Ethernet LAN |
Yes | Yes | No | |
AC input voltage |
100 - 240 V | |||
Lens type |
Fixed focal length lens | |||
Supported graphics resolutions |
1280 x 720 (HD 720) | 2304 x 1296 | ||
Diameter |
6.53 cm | |||
International Protection (IP) code |
IP67 | IP67 | IP65 | IP67 |
Ethernet interface type |
Fast Ethernet | 10 Megabit Ethernet | ||
Supported video modes |
720p | |||
Motion Detection |
Yes | |||
Colour Temperature |
3200 K | |||
Number of Users |
32 user(s) | |||
Web-based management |
Yes | Yes | ||
Quality of Service (QoS) support |
Yes | |||
Supported network protocols |
IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; SMTP; FTP; DHCP; DNS; DDNS; NTP; Multicast | |||
Password protection |
Yes | |||
Languages support |
Ukrainian | |||
Luminous flux |
1000 lm | |||
Frame Rate |
25 fps | 20 fps | 20 fps | 25 / 30 fps |
Product colour |
White | Black | Black | White |
Tilt angle range |
0 - 90° | |||
Sustainability certificates |
Federal Communications Commission (FCC) | |||
Focal length range |
2.8 mm | 2.8 mm | ||
Fixed focal length |
2.8 mm | |||
Web browser |
Yes | Yes | ||
RAM capacity |
128 MB | |||
LED type |
IR | IR | IR | IR / White light LED |
Night vision |
Yes | Yes | Yes | Yes |
Total megapixels |
4 MP | 2 MP | 2 MP | |
4G LTE |
No | |||
Motion sensor |
Yes | |||
Optical sensor size |
25.4 / 3 mm (1 / 3") | 25.4 / 2.7 mm (1 / 2.7") | 25.4 / 2.9 mm (1 / 2.9") | 25.4 / 2.8 mm (1 / 2.8") |
White balance |
Natural | |||
Field of view (FOV) angle |
106° | 120° | ||
Minimum illumination |
0.03 lx | 0.002 lx | ||
Pan range |
0 - 360° | 0 - 360° | 0 - 120° | |
Dynamic range |
120 dB | 4.38 dB | ||
Lens viewing angle, diagonal |
114° | 125° | ||
Video compression formats |
H.264 | H.264+ | H.264H | |
Angle of rotation |
360° | 360° | ||
DC output current |
0.4 A | |||
DC output voltage |
12 | 12 | ||
Video motion detection |
Yes | Yes | ||
Operating frequency |
2412 - 2472 Mhz | |||
Number of cameras |
1 | 1 | 1 | 1 |
Night vision distance |
30 m | 30 m | 10 m | 30 m |
Number of lenses |
1 | 1 | 1 | |
Privacy protection |
Yes | |||
Day/night mode |
Yes | Yes | ||
Built-in HDD |
No | No | ||
Camera shutter type |
Electronic | |||
Lens viewing angle, vertical |
54° | 56° | 56° | |
Noise reduction technology |
3D noise reduction | 3D noise reduction | ||
Smart IR |
Yes | |||
Digital Wide Dynamic Range (DWDR) |
Yes | |||
Region of Interest (ROI) encoding |
Yes | Yes | ||
Maximum aperture number |
1.6 | 2 | 1.6 | |
Lens diameter |
3.2 mm | |||
Lens viewing angle, horizontal |
98° | 106° | 107° | |
Number of sensors |
1 | 1 | ||
Infra-red wavelength |
850 nm | |||
Wide Dynamic Range (WDR) |
Yes | 120 dB | ||
Viewing angle, diagonal |
127° | |||
Progressive scan |
Yes | Yes | Yes | |
Mirror |
Yes | Yes | ||
Heartbeat |
Yes | |||
Digital watermark |
Yes | |||
Back Light Compensation (BLC) |
Yes | Yes | ||
Video streaming |
Yes | Yes | Yes | |
Active tampering alarm |
Yes | |||
ROM capacity |
16 MB | 128 MB | ||
Camera shutter speed |
1/3 - 1/100000 s | 1/3 s–1/100000 s | 1/3 - 1/100000 s | |
Adjustment shutter speed |
Auto/Manual | Auto/Manual | ||
Bit rate control |
Constant Bit Rate (CBR)/Variable Bit Rate (VBR) | Constant Bit Rate (CBR), Variable Bit Rate (VBR) | ||
Gain control type |
Auto/Manual | |||
Privacy masking |
Yes | Yes | ||
Highlight Compensation (HLC) |
Yes | Yes | ||
Number of illumination LEDs |
1 | 1 / 1 | ||
Live view |
Yes | |||
Motion detection |
Yes | |||
People detection |
Yes | |||
Two-way talk |
N | |||
People detection |
Yes | |||
Power consumption (Power over Ethernet (PoE)) |
6.5 W | 2.3 W | 4.4 W | |
Image quality adjustment |
Saturation | |||
Lens mount interface |
M12 | |||
Built-in loudspeaker |
No | |||
Digest authentication |
Yes | |||
Password reset via email |
Yes | |||
Number of simultaneous live view channels |
6 channels | |||
User access level |
Administrator, Operator, User | |||
Horizontal rotation angle |
0 - 360° | |||
Vertical rotation angle |
0 - 78° | |||
Built-in light |
Yes | |||
Management software |
Smart PSS; DSS; DMSS | |||
Closest focusing distance |
0.8 m | 0.7 m | ||
Detect distance |
63 m | 56 m | ||
Observe distance |
25 m | 22.4 m | ||
Recognize distance |
12 m | 11.2 m | ||
Identify distance |
6 m | 5.6 m | ||
Tilt speed |
90 °/sec | |||
Audio codecs |
G.711a; G.711Mu; G.726; PCM | PCM, G.711a G.711Mu, G.726 | ||
Smartphone/tablet remote support |
Yes | |||
Number of Privacy masking areas |
4 | |||
Warnings |
The product contains electronic components; do not dispose of with the normal household waste. | |||
