IP network camera 4MP HDW3441T-ZAS
    DAHUA TECHNOLOGY CO., LTD

    IP network camera 4MP HDW3441T-ZAS

    €218.02
    Tax included
    Quantity

    Add to favorites Add to compare
    Features:

    • 4MP, 1/3” CMOS image sensor, low illuminance, high image definition
    • Outputs max. 4MP (2688 × 1520)@30 fps
    • H.265 codec, high compression rate, low bit rate
    • Built-in IR LED, max. IR distance: 40 m
    • ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments
    • Rotation mode, WDR, 3D DNR, HLC, BLC, digital watermarking, applicable to various monitoring scenes
    • Intelligent detection: Intrusion, tripwire
    • Abnormality detection: Motion detection, video tampering, scene changing, audio detection, no SD card, SD card full, SD card error, net work disconnection, IP conflict, illegal access, voltage detection
    • Supports max. 256 G Micro SD card, built-in Mic
    • 12V DC/POE power support
    • IP67 protection
    • SMD

    Technical Specifications:

    Camera
    • Image Sensor 1/3” 4Megapixel progressive CMOS
    • Effective Pixels 2688 (H) ×1520 (V)
    • ROM 128 MB
    • RAM 512 MB
    • Scanning System Progressive
    • Electronic Shutter Speed Auto/Manual 1/3 s–1/100000 s
    • Min. Illumination 0.005 Lux@F1.5
    • IR Distance 40 m (131.2 ft)
    • IR On/Off Control Auto/Manual
    • IR LEDs Number 2 (IR LEDs)
    • Pan/Tilt/Rotation Range Horizontal: 0°–360°; vertical: 0°–78°; rotation: 0°–360°
    Lens
    • Lens Type Motorized vari-focal
    • Mount Type f14
    • Focal Length 2.7 mm–13.5 mm
    • Max. Aperture F1.5
    Field of View
    • Horizontal: 104°–27°
    • Vertical: 55° –15°
    • Diagonal: 124° –31°
    • Iris Type Fixed aperture
    • Close Focus Distance 0.8 m (2.6 ft)
    Professional, Intelligent
    • Perimeter Protection Tripwire; intrusion (Recognition of human and vehicle)
    • Intelligent Search: Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos
    Video
    • Video Compression H.265; H.264; H.264H; H.264B; MJPEG
    • Smart Codec Yes
    Video Frame Rate
    • Main stream (2688 × 1520@1–25/30 fps) sub stream (704 × 576@1–25 fps/704 × 480@1–30 fps) third stream (1280 × 720@1–25/30 fps)
    • Stream Capability 3 streams
    • Resolution: 4M (2688 × 1520); 3M (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)
    • Bit Rate Control CBR/VBR
    • Video Bit Rate H.264: 3 Kbps–8192 Kbps H.265: 3 Kbps–8192 Kbps
    • Day/Night Auto(ICR)/Color/B/W
    • BLC Yes
    • HLC Yes
    • WDR 120 dB
    • White Balance Auto/natural/street lamp/outdoor/manual/regional custom
    • Gain Control Auto/Manual
    • Noise Reduction 3D DNR
    • Motion Detection OFF/ON (4 areas, rectangular)
    • Region of Interest(RoI) Yes (4 areas)
    • Smart IR Yes
    • Image Rotation 0°/90°/180°/270° (Support 90°/270° with 1920 × 1080 resolution.)
    • Mirror Yes
    • Privacy Masking 4 areas
    Audio
    • Built-in MIC Yes
    • Audio Compression G.711a; G.711Mu; G726; AAC
    Network
    • Network RJ-45 (10/100 Base-T)
    • Protocol: IPv4;IPv6;HTTP;HTTPS;TCP;UDP;ARP;RTP;RTSP;RTCP;RTMP;SMTP;FTP;SFTP;DHCP;DNS;DDNS;QoS;UPnP;NTP;Multicast;ICMP;IGMP;NFS;PPPoE;802.1x;SNMP
    • Interoperability ONVIF(Profile S/Profile G);CGI;P2P;Milestone;Genetec
    • Scene Self-adaptation Yes
    • User/Host 20 (Total bandwidth: 64 M)
    • Edge Storage FTP; SFTP; Micro SD Card (support max. 256 G); Dahua
    • Cloud; NAS
    • Browser: IE: IE8, IE9, IE11 Chrome Firefo
    • Management Software Smart PSS, DSS, DMSS
    • Mobile Phone IOS; Android
    Certifications
    • CE-LVD: EN60950-1
    • CE-EMC: Electromagnetic Compatibility Directive
    • 2014/30/EU
    • FCC: 47 CFR FCC Part 15, Subpart B
    • UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07
    Power
    • Power Supply 12V DC/PoE (802.3af)
    • Power Consumption <8.3W
    Environment
    • Operating Conditions -30°C to +60°C (-22°F to +140°F)/less than=95%
    • Strorage Conditions -40°C to +60°C (-40°F to +140°F)
    • Ingress Protection IP67
    Structure
    • Casing Metal
    • Dimensions 108.3 mm × F122 mm (4.3" × F4.8")
    • Net Weight 685g (1.5 lb)
    • Gross Weight 828 g (1.8 lb)

    Product Details

    HDW3441T-ZAS
    3 Items

    Quick Compare

    Product
    		 Camera BCS LINE BCS-L-EIP25FSR5-Ai2 IP Camera BCS LINE BCS-L-EIP25FSR5-Ai2-G DAHUA SD1A404DB-GNY IP CAMERA DS-2CD2186G2H-ISU(4mm)(eF) Kamera IP
    Availability
    Price
    €206.33
    €206.33
    €206.39
    €206.44
    Description
    Type
    		 IP security camera IP security camera
    Height
    		 65.7 mm 97.6 mm
    Connectivity technology
    		 Wired Wired
    Weight
    		 500 g 525 g
    Package depth
    		 120 mm
    Package height
    		 117 mm
    Package width
    		 234 mm
    Package weight
    		 700 g 750 g
    Power source type
    		 DC, PoE DC, PoE
    Storage relative humidity (H-H)
    		 0 - 95%
    Operating temperature (T-T)
    		 -30 - 60 °C -30 - 60 °C
    Operating relative humidity (H-H)
    		 0 - 95% 0 - 95%
    Storage temperature (T-T)
    		 -30 - 60 °C
    Mounting type
    		 Ceiling/wall Ceiling/wall
    Form factor
    		 Dome Bullet
    Built-in microphone
    		 Yes
    LED indicators
    		 Yes
    Bluetooth
    		 No No
    Bit rate
    		 32 Kbps - 16 Mbps
    Noise reduction
    		 Yes Yes
    Mobile operating systems supported
    		 Android
    Protection features
    		 Water resistant
    Sensor type
    		 CMOS CMOS
    Wi-Fi
    		 No No
    Compatible memory cards
    		 MicroSD (TransFlash) MicroSD (TransFlash)
    Maximum memory card size
    		 512 GB 512 GB
    Audio formats supported
    		 G.711 μ-law
    Signal-to-Noise Ratio (SNR)
    		 52 dB
    Power consumption (max)
    		 13 W 8 W
    Power consumption (typical)
    		 4 W
    Maximum resolution
    		 2560 x 1440 pixels 3840 x 2160 pixels
    Placement supported
    		 Indoor & outdoor Outdoor
    Card reader integrated
    		 Yes Yes
    Ethernet LAN (RJ-45) ports
    		 1 1
    Number of languages
    		 33
    Audio output channels
    		 1.0 channels 1.0 channels
    Housing material
    		 Aluminium
    Networking standards
    		 IEEE 802.3af
    Security algorithms
    		 TLS
    Ethernet LAN
    		 Yes Yes
    Focus
    		 Motorized/Manual
    Supported graphics resolutions
    		 352 x 288 3840 x 2160
    Diameter
    		 12.8 cm 12.2 cm
    International Protection (IP) code
    		 IP66 IP67
    Digital zoom
    		 16x
    Auto focus
    		 Yes
    Ethernet interface type
    		 Fast Ethernet
    Optical Zoom
    		 4x
    Number of Users
    		 20 user(s) 32 user(s)
    Web-based management
    		 Yes Yes
    Quality of Service (QoS) support
    		 Yes
    Reset button
    		 Yes
    Browser supported
    		 IE 10, IE 11, Chrome 57.0+, Firefox 52.0+
    Password protection
    		 Yes
    Languages support
    		 Multi
    Frame Rate
    		 30 fps 30 fps
    Product colour
    		 Black White
    Tilt angle range
    		 5 - 90° 0 - 75°
    Focal length range
    		 2.8 - 12 mm
    Fixed focal length
    		 4 mm
    RAM capacity
    		 512 MB
    Image stabilizer
    		 Yes
    LED type
    		 IR IR
    Night vision
    		 Yes Yes
    Total megapixels
    		 4 MP 8 MP
    PTZ control
    		 Yes
    Optical sensor size
    		 25.4 / 28 mm (1 / 28") 25.4 / 1.8 mm (1 / 1.8")
    White balance
    		 Natural
    Minimum illumination
    		 0.0005 lx 0 lx
    Pan range
    		 0 - 355° 0 - 355°
    Dynamic range
    		 130 dB
    Lens viewing angle, diagonal
    		 109.4°
    Video compression formats
    		 H.265 H.264+
    Angle of rotation
    		 355°
    DC output current
    		 0.66 A
    DC output voltage
    		 12
    Video motion detection
    		 Yes Yes
    Number of cameras
    		 1 1
    Camera pan control
    		 Yes
    Camera tilt control
    		 Yes
    Night vision distance
    		 20 m 30 m
    Number of lenses
    		 1 1
    Privacy protection
    		 Yes
    Day/night mode
    		 Yes
    Preset points
    		 Yes
    Infrared (IR) cut-off filter
    		 Yes
    Built-in HDD
    		 No No
    Camera shutter type
    		 Electronic
    Lens viewing angle, vertical
    		 45.8°
    Noise reduction technology
    		 2D noise reduction, 3D noise reduction 3D noise reduction
    Region of Interest (ROI) encoding
    		 Yes Yes
    Maximum aperture number
    		 2.7 1
    Lens viewing angle, horizontal
    		 90°
    Number of sensors
    		 1
    Infra-red wavelength
    		 850 nm
    Audio detection
    		 Yes
    Wide Dynamic Range (WDR)
    		 Yes Yes
    Progressive scan
    		 Yes Yes
    Mirror
    		 Yes
    Heartbeat
    		 Yes
    Digital watermark
    		 Yes
    Back Light Compensation (BLC)
    		 Yes Yes
    Video streaming
    		 Yes Yes
    Active tampering alarm
    		 Yes
    Alarm input/output
    		 Yes Yes
    Terminal block port
    		 Yes
    IP address filtering
    		 Yes
    Intelligent Video Surveillance (IVS) system features
    		 Face detection Face detection
    ROM capacity
    		 256 MB
    Camera shutter speed
    		 1 - 1/30000 s 1/3 - 1/100000 s
    Bit rate control
    		 Constant Bit Rate (CBR)/Variable Bit Rate (VBR) Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
    Gain control type
    		 Auto/Manual
    Privacy masking
    		 Yes
    Highlight Compensation (HLC)
    		 Yes Yes
    Signal-to-Noise Ratio (SNR) (panoramic camera)
    		 55 dB
    Live view
    		 Yes
    Power consumption (Power over Ethernet (PoE))
    		 9.5 W
    HTTPS encryption
    		 Yes
    Behavior analysis
    		 Intrusion detection, Line crossing detection
    Image quality adjustment
    		 Brightness
    IK code
    		 IK08 IK10
    Lens mount interface
    		 M12
    Digest authentication
    		 Yes
    Password reset via email
    		 Yes
    Number of simultaneous live view channels
    		 6 channels
    User access level
    		 Administrator, Operator, User
    Identify distance (wide)
    		 24 m
    Recognize distance (wide)
    		 48 m
    Audio input channels
    		 1.0 channels 1.0 channels
    Observe distance (wide)
    		 94.8 m
    Management software
    		 DMSS; DSS Pro
    Closest focusing distance
    		 0.2 m
    Detect distance
    		 109 m
    Observe distance
    		 43 m
    Recognize distance
    		 21 m
    Identify distance
    		 10 m
    Detect distance (wide)
    		 240 m
    Pixel counter
    		 Yes
    Human and vehicle targets classification
    		 Yes
    Minimum aperture number
    		 1.8
    Client interoperability
    		 iVMS-4200, Hik-Connect, Hik-Central
    Bit rate range
    		 8 - 320 Kbit/s
    Pan preset speed
    		 0.1 °/sec
    PTZ modes
    		 8 Tour
    Tilt preset speed
    		 0.1 °/sec
    PTZ protocols
    		 DH-SD
    Alarm output channels
    		 1 1
    Alarm input channels
    		 1 1
    Pan manual speed
    		 0.1 - 70 °/sec
    Tilt manual speed
    		 0.1 - 30 °/sec
    Compliance certificates
    		 UL
    Number of Privacy masking areas
    		 4
    Sample rates
    		 8 - 48 kHz
    Automatic Network Replenishment (ANR)
    		 Yes
    Network access storage (NAS)
    		 Yes
    Infra-red LEDs life
    		 3 h
    Warnings
    		 Avoid direct contact with water to prevent electrical damage.
    Audit log
    		 Yes
    Flash log
    		 Yes
