Mini 2 Megapixel HD Network IR PTZ Dome Camera, x4 zoom WIFI
    DAHUA TECHNOLOGY CO., LTD

    Mini 2 Megapixel HD Network IR PTZ Dome Camera, x4 zoom WIFI

    €278.58
    Tax included
    Quantity

    Features:

    • 1/2.8” STARVIS™ CMOS
    • Powerful 4x optical zoom
    • Support Triple-streams encoding
    • WDR, Day/Night(ICR), Ultra DNR
    • Max. 25/30fps@1080P
    • IVS
    • Support Wi-Fi
    • IR distance up to 30m

    Technical Specifications:

    Camera
    • Image Sensor 1/2.8” STARVIS™ CMOS
    • Effective Pixels 1920(H) x 1080(V), 2 Megapixels
    • RAM/ROM 256M/128M
    • Scanning System Progressive
    • Electronic Shutter Speed 1/1s~1/30,000s
    • Minimum Illumination Color: 0.005Lux@F1.6; B/W: 0.0005Lux@F1.6; 0Lux@F1.6 (IR on)
    • IR Distance Distance up to 30m (98ft)
    • IR On/Off Control Auto/Manual
    • IR LEDs 4
    Lens
    • Focal Length 2.7mm~11mm
    • Max. Aperture F1.6
    • Angle of View H: 112.5° ~ 30°
    • Optical Zoom 4x
    • Focus Control Auto/Manual
    • Close Focus Distance 100mm~ 1000mm
    PTZ
    • Pan/Tilt Range Pan: 0° ~ 360° limited; Tilt: 0° ~ 90°
    • Manual Control Speed Pan: 0.1° ~100° /s; Tilt: 0.1° ~60° /s
    • Preset Speed Pan: 100° /s; Tilt: 60° /s
    • Presets 300
    • PTZ Mode 5 Pattern, 8 Tour(up to 32 preset per tour),Auto Scan
    • Speed Setup Human-oriented focal Length/ speed adaptation
    • Power up Action Auto restore to previous PTZ and lens status after power failure
    • Idle Motion Activate Preset/ Scan/ Tour/ Pattern if there is no command in the specified period
    • Protocol DH-SD
    Intelligence
    • Event Trigger
    • Motion detection, Video tampering, Network disconnection, IP address conflict, Illegal access, Storage anomaly
    • Auto Tracking N/A
    • IVS Tripwire, Intrusion,Abandoned/Missing
    • Advanced Intelligent Functions Face Detection
    Video
    • Compression H.265/H.264/MJPEG(Sub Stream)
    • Streaming Capability 3 Streams
    • Resolution 1080P(1920×1080)/720P(1280×720)/D1(704×576/704×480)/CIF(352×288/352×240)
    Frame Rate
    • Main stream: 1080P/720P/D1 (1 ~ 25/30fps)
    • Sub stream1: D1/CIF(1 ~ 25/30fps)
    • Sub stream2: 720P/D1/CIF (1 ~ 25/30fps)
    • Bit Rate Control CBR/VBR
    • Bit Rate H.265/H.264: 448K ~ 8192Kbps, MJPEG: 5120K ~ 10240Kbps
    • Day/Night Auto(ICR) / Color / B/W
    • Backlight Compensation BLC / HLC / WDR (120dB)
    • White Balance Auto, ATW, Indoor, Outdoor, Manual
    • Gain Control Auto / Manual
    • Noise Reduction Ultra DNR (2D/3D)
    • Motion Detection Support
    • Region of Interest support
    • Electronic Image Stabilization (EIS) N/A
    • Defog Support
    • Digital Zoom 16x
    • Flip 180°
    • Privacy Masking Up to 24 areas
    Audio
    • Compression G.711a/G.711mu/PCM/G.726/AAC/G722.1/G.729/MPEG2-Layer2
    Network
    • Ethernet RJ-45 (10XBase-T/100Base-TX)
    • Wifi N/A
    Protocol
    • IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS,PPPOE,DDNS,FTP, IP Filter,QoS,Bonjour,802.1x Interoperability ONVIF Profile S&G, API
    • Streaming Method Unicast / Multicast
    • Max. User Access 20 users
    • Edge Storage NAS (Network Attached Storage),Local PC for instant recording, Micro SD card 128GB
    • Web Viewer IE, Chrome, Firefox, Safari
    • Management Software Smart PSS, DSS, DMSS
    • Smart Phone IOS, Android
    Certifications
    • CE: EN55032/EN55024/EN50130-4
    • FCC: Part15 subpartB,ANSI C63.4- 2014
    • UL: UL60950-1+CAN/CSA C22.2,No.60950-1
    Interface
    • Video Interface N/A
    • RS485 N/A
    • udio I/O Built-in Mic
    • Alarm I/O N/A
    Electrical
    • Power Supply DC 12V/1.5A
    • Power Consumption 10W,13W (IR on)
    Environmental
    • Operating Conditions -30°C ~ 60°C (-22°F ~ +140°F) / Less than 90% RH (Only for indoor!!)
    • Ingress Protection N/A
    • Vandal Resistance N/A
    Construction
    • Casing Metal
    • Dimensions ?132.7 (mm) x 117.9 (mm)
    • Net Weight 0.95kg(2.09lb)
    • Gross Weight 1kg(2.20lb)
