DAHUA

DAHUA IP CAMERA IPC-HFW3649T-ZAS-IL-27135-BLACK

€385.90

Tax included

Product Details
Quick Compare

Product Details

Reference WLONONWCROKDB

In stock 4 Items

Data sheet

Type: IP security camera
Width: 90.7 mm
Height: 90.7 mm
Depth: 238.5 mm
Connectivity technology: Wired
Weight: 835 g
Package weight: 1.09 kg
Power source type: DC, PoE
Storage relative humidity (H-H): 0 - 95%
Manual: Yes
Operating temperature (T-T): -40 - 60 °C
Operating relative humidity (H-H): 0 - 95%
Storage temperature (T-T): -40 - 60 °C
Mounting type: Ceiling/wall
Form factor: Bullet
Built-in microphone: Yes
Bluetooth: No
Bit rate: H.264: 3 kbps–8192 kbps; H.265: 3 kbps–8192 kbps
Noise reduction: Yes
Sensor type: CMOS
Wi-Fi: No
Signal-to-Noise Ratio (SNR): 56 dB
Maximum resolution: 3288 x 1850 pixels
Placement supported: Indoor & outdoor
Audio output channels: 1.0 channels
Housing material: Plastic
Networking standards: IEEE 802.3af
Ethernet LAN: Yes
Supported graphics resolutions: 704 x 576
International Protection (IP) code: IP67
Web-based management: Yes
Frame Rate: 30 fps
Product colour: Black
Tilt angle range: 0 - 90°
Web browser: Yes
Voice codecs: G.711Mu
Image stabilizer: Yes
Night vision: Yes
Total megapixels: 6 MP
Optical sensor size: 25.4 / 2.7 mm (1 / 2.7")
White balance: Auto
Minimum illumination: 0.005 lx
Pan range: 0 - 360°
Video compression formats: M-JPEG
Angle of rotation: 360°
Video motion detection: Yes
Number of cameras: 1
Number of lenses: 1
Built-in HDD: No
Noise reduction technology: 3D noise reduction
Wide Dynamic Range (WDR): Yes
Progressive scan: Yes
Back Light Compensation (BLC): Yes
Video streaming: Yes
Fog proof: Yes
Active tampering alarm: Yes
Camera shutter speed: 1/3 – 1/100.000
Bit rate control: Constant Bit Rate (CBR), Variable Bit Rate (VBR)
Gain control type: Auto/Manual
Highlight Compensation (HLC): Yes
Flip & mirror: Yes
Signal-to-Noise Ratio (SNR) (panoramic camera): 56 dB
Cloud-managed: Yes
Identify distance (wide): 8.5 m
Recognize distance (wide): 17.1 m
Audio input channels: 1.0 channels
Observe distance (wide): 34 m
Detect distance (wide): 85.3 m
Identify distance (tele): 28 m
Recognize distance (tele): 56 m
Detect distance (tele): 280 m
Observe distance (tele): 112 m
