IP Camera DAHUA IPC-HDW1530T-0280B-S6-BLACK Black

Product Details

Reference WLONONWCR0070

In stock 29 Items

Data sheet

Type

IP security camera

Width

94 mm

Height

85.6 mm

Depth

94 mm

Connectivity technology

Wired

Weight

320 g

Power source type

DC, PoE

Operating temperature (T-T)

-40 - 60 °C

Operating relative humidity (H-H)

0 - 95%

Storage temperature (T-T)

-40 - 60 °C

Mounting type

Wall/ceiling

Form factor

Tube/dome

Built-in microphone

Yes

Bluetooth

No

Mobile operating systems supported

Android

Sensor type

CMOS

Wi-Fi

No

Signal-to-Noise Ratio (SNR)

56 dB

Power consumption (typical)

3.7 W

Maximum resolution

2880 x 1620 pixels

Placement supported

Outdoor

Housing material

Metal, Plastic

Networking standards

IEEE 802.3af

Lens type

Fixed focal length lens

International Protection (IP) code

IP67

Ethernet interface type

10 Megabit Ethernet

Motion Detection

Yes

Web-based management

Yes

Frame Rate

20 fps

Product colour

Black

Focal length range

2.8 mm

Web browser

Yes

RAM capacity

128 MB

LED type

IR

Night vision

Yes

Total megapixels

5 MP

4G LTE

No

Optical sensor size

25.4 / 2.7 mm (1 / 2.7")

Minimum illumination

0.03 lx

Video compression formats

H.264+

DC output voltage

12

Number of cameras

1

Night vision distance

30 m

Number of lenses

1

Lens viewing angle, vertical

56°

Maximum aperture number

2

Lens viewing angle, horizontal

106°

Number of sensors

1

Wide Dynamic Range (WDR)

DWDR

Viewing angle, diagonal

125°

Progressive scan

Yes

Video streaming

Yes

ROM capacity

16 MB

Camera shutter speed

1/3 - 1/100000 s

Adjustment shutter speed

Auto/Manual

Number of illumination LEDs

1

Motion detection

Yes

People detection

Yes

Two-way talk

N

People detection

Yes

Power consumption (Power over Ethernet (PoE))

4.5 W

Built-in loudspeaker

No

Horizontal rotation angle

0 - 360°

Vertical rotation angle

0 - 78°

Closest focusing distance

0.8 m

Audio codecs

G.711a, G.711Mu, G726
