DAHUA Camera IPC-HFW3449T-ZS-IL-27135

Product Details

Reference WLONONWCROXU5

In stock 14 Items

Data sheet

Type

IP security camera

Width

238.5 mm

Height

90.7 mm

Depth

90.7 mm

Connectivity technology

Wired

Weight

835 g

Package weight

1.09 kg

Power source type

DC, PoE

Operating temperature (T-T)

-30 - 60 °C

Operating relative humidity (H-H)

0 - 95%

Storage temperature (T-T)

-40 - 60 °C

Mounting type

Ceiling/Wall/Pole

Form factor

Bullet

Built-in microphone

Yes

Bluetooth

No

Bit rate

H.264: 3 kbps–8192 kbps; H.265: 3 kbps–8192 kbps

Noise reduction

Yes

Mobile operating systems supported

Android

Sensor type

CMOS

Wi-Fi

No

Compatible memory cards

MicroSD (TransFlash)

Maximum memory card size

512 GB

Signal-to-Noise Ratio (SNR)

56 dB

Power consumption (max)

9.3 W

Power consumption (typical)

3.2 W

Maximum resolution

2688 x 1520 pixels

Placement supported

Indoor & outdoor

Ethernet LAN (RJ-45) ports

1

Audio output channels

1.0 channels

Housing material

Plastic

Networking standards

IEEE 802.3af

Ethernet LAN

Yes

Focus

Motorized

Supported graphics resolutions

704 x 480

International Protection (IP) code

IP67

Number of Users

20 user(s)

Web-based management

Yes

Quality of Service (QoS) support

Yes

Frame Rate

30 fps

Product colour

White

Tilt angle range

0 - 90°

Focal length range

2.7 - 13.5 mm

Web browser

Yes

RAM capacity

1024 MB

Voice codecs

G.711a

Image stabilizer

Yes

LED type

IR

Night vision

Yes

Total megapixels

4 MP

Optical sensor size

25.4 / 2.9 mm (1 / 2.9")

White balance

Custom modes

Minimum illumination

0.005 lx

Pan range

0 - 360°

Lens viewing angle, diagonal

125-34°

Video compression formats

M-JPEG

Angle of rotation

360°

DC output voltage

12

Video motion detection

Yes

Number of cameras

1

Night vision distance

50 m

Number of lenses

1

Day/night mode

Yes

Built-in HDD

No

Lens viewing angle, vertical

54-16°

Noise reduction technology

3D noise reduction

Region of Interest (ROI) encoding

Yes

Maximum aperture number

1

Lens viewing angle, horizontal

104-29°

Wide Dynamic Range (WDR)

Yes

Progressive scan

Yes

Back Light Compensation (BLC)

Yes

Video streaming

Yes

Fog proof

Yes

Active tampering alarm

Yes

Intelligent Video Surveillance (IVS) system features

Intrusion

ROM capacity

256 MB

Adjustment shutter speed

Auto/Manual

Effective sensor resolution

4 pixels

Bit rate control

Constant Bit Rate (CBR), Variable Bit Rate (VBR)

Gain control type

Auto/Manual

Privacy masking

Yes

Highlight Compensation (HLC)

Yes

Flip & mirror

Yes

Signal-to-Noise Ratio (SNR) (panoramic camera)

56 dB

Power consumption (Power over Ethernet (PoE))

11.9 W

Identify distance (wide)

6.5 m

Recognize distance (wide)

13 m

Audio input channels

1.0 channels

Observe distance (wide)

26.1 m

Closest focusing distance

1.5 m

Detect distance (wide)

65.2 m

Identify distance (tele)

18.7 m

Recognize distance (tele)

37.3 m

Detect distance (tele)

186.6 m

Observe distance (tele)

74.6 m

Alarm output channels

1

Alarm input channels

1

Number of Privacy masking areas

8
