PowerWalker VFI 3000 ICT IoT Double-conversion (Online) 3 kVA 3000 W 9 AC outlet(s)

Product Details

Data sheet

Width

192 mm

Height

318 mm

Depth

428 mm

Weight

26.4 kg

Package height

475 mm

Package width

590 mm

Number of batteries supported

6

Cables included

Input power cable, Output power cable, USB cable

Manual

Yes

Operating temperature (T-T)

0 - 45 °C

Operating relative humidity (H-H)

0 - 95%

Form factor

Tower

USB port

Yes

LED indicators

Yes

Battery capacity

9 Ah

Battery recharge time

3 h

Cooling type

Active

Output power

3000 W

Input frequency

40/70 Hz

Response time

0 ms

Display type

LCD

Input operation voltage (min)

160 V

Power protection features

Overload

AC outlets quantity

9 AC outlet(s)

Output power capacity

3 kVA

Output operation voltage (max)

240 V

Waveform

Pure sine

AC outlet types

C19 coupler

Input operation voltage (max)

300 V

Battery voltage

12 V

Output operation voltage (min)

200 V

UPS topology

Double-conversion (Online)

Output voltage regulation

1%

Serial interface type

RS-232

Noise Level

50 dB

Serial ports quantity

1

Power plug

C20 coupler

Product colour

Black

Harmonized System (HS) code

85078000

Serial interface

Yes

ECO mode

Yes

Charging current

1.5 A

Output voltage Total Harmonic Distortion (THD)

1%

Crest factor

3:1

Emergency Power Off (EPO)

Yes

Output power factor

1

Emergency Power Off (EPO) connector

Yes

Input power factor

0.99

Built-in fan

Yes

Input current Total Harmonic Distortion (THD)

5%

Warnings

Keep away from sources of fire and water.
