Product Details
Data sheet
- Width
- 438 mm
- Height
- 86.5 mm
- Depth
- 608 mm
- Weight
- 28.1 kg
- Battery type
- 12V / 7Ah
- Form factor
- Rackmount
- Battery recharge time
- 4 h
- Output power
- 1800 W
- Input frequency
- 50/60 Hz
- USB 2.0 ports quantity
- 1
- Display type
- LCD
- Number of battery cells
- 6
- Input operation voltage (min)
- 154 V
- Power protection features
- Over power
- AC outlets quantity
- 9 AC outlet(s)
- Output power capacity
- 2 kVA
- Output operation voltage (max)
- 240 V
- AC outlet types
- IEC 309 516C6
- Input operation voltage (max)
- 288 V
- Output operation voltage (min)
- 220 V
- Modem (RJ-11) ports
- 2
- RS-232 ports
- 1
- Package dimensions (WxDxH)
- 790 x 590 x 236 mm
- Noise Level
- 45 dB
- Surge energy rating
- 430 J
- Product colour
- Black
- Harmonized System (HS) code
- 85078000
- Emergency Power Off (EPO)
- Yes
Quick Compare
Product |
|
APC Smart-UPS SMT1000IC – 8x C13, USB, SmartConnect, 1000VA
|
Availability |
|
|
Price |
€614.00
|
€624.88
|
Description |
||
Width |
171 mm | |
Height |
219 mm | |
Depth |
439 mm | |
Weight |
18.9 kg | |
Package height |
376 mm | |
Package width |
328 mm | |
Cables included |
RJ-45, USB cable | |
Storage relative humidity (H-H) |
0 - 95% | |
Operating temperature (T-T) |
0 - 40 °C | |
Operating relative humidity (H-H) |
0 - 95% | |
Storage temperature (T-T) |
-15 - 45 °C | |
Form factor |
Mini tower | |
USB port |
Yes | |
LED indicators |
Yes | |
Battery technology |
Sealed Lead Acid (VRLA) | |
Battery life (max) |
5 year(s) | |
Battery recharge time |
3 h | |
Output power |
700 W | |
Input frequency |
50/60 Hz | |
USB 2.0 ports quantity |
1 | |
Response time |
10 ms | |
Display type |
LCD | |
Ethernet LAN (RJ-45) ports |
1 | |
Input operation voltage (min) |
151 V | |
Cold start |
Yes | |
AC outlets quantity |
8 AC outlet(s) | |
Output power capacity |
1 kVA | |
Output operation voltage (max) |
240 V | |
Waveform |
Sine | |
Auto-restart |
Yes | |
AC outlet types |
C13 coupler | |
Input operation voltage (max) |
302 V | |
Audible alarm(s) |
Yes | |
Output operation voltage (min) |
220 V | |
UPS topology |
Line-Interactive | |
Automatic Voltage Regulation (AVR) |
Yes | |
Automatic battery test |
Yes | |
Surge protection |
Yes | |
Operating altitude |
0 - 3000 m | |
Quick installation guide |
Yes | |
Output frequency |
50/60 Hz | |
Noise Level |
41 dB | |
Serial ports quantity |
1 | |
Surge energy rating |
459 J | |
Power plug |
C14 coupler | |
Non-operating altitude |
0 - 15000 m | |
Product colour |
Black | |
Harmonized System (HS) code |
85078000 | |
Sustainability certificates |
Green Premium | |
Serial interface |
Yes | |
USB port type |
USB Type-A | |
Output voltage Total Harmonic Distortion (THD) |
5% | |
Hot-swap battery |
Yes | |
Compliance certificates |
RoHS | |
Total carbon footprint (kg of CO2e) |
984.74 | |
Audible alarm modes |
Alarm when on battery, Low battery alarm, Overload alarm | |
Temperature voltage compensation |
Yes | |
SmartSlot |
Yes | |
Replacement battery cartridge |
RBC6 | |
Management card included |
No | |
Warnings |
Use the appliance in well-ventilated areas to avoid overheating. | |
SmartConnect port |
Yes | |
