POWER WALKER

POWER WALKER UPS ON-LINE VFI 1000 AT FR

€267.30

Tax included

Product Details
Quick Compare

Product Details

Brand POWER WALKER

Reference WLONONWCRFPNO

In stock 7 Items

Data sheet

Width: 140 mm
Height: 191 mm
Depth: 327 mm
Weight: 9.11 kg
Package depth: 432 mm
Package height: 274 mm
Package width: 218 mm
Package weight: 9.95 kg
Number of batteries supported: 2
Cables included: RS-232, USB cable
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 20 - 90%
Form factor: Tower
USB port: Yes
Battery capacity: 9 Ah
Battery recharge time: 4 h
Output power: 900 W
Input frequency: 40/70 Hz
USB 2.0 ports quantity: 1
Response time: 0 ms
Display type: LCD
Efficiency: 88%
Input operation voltage (min): 80 V
AC outlets quantity: 3 AC outlet(s)
Output power capacity: 1 kVA
Output operation voltage (max): 240 V
Waveform: Pure sine
AC outlet types: Type E
Input operation voltage (max): 300 V
Battery voltage: 12 V
Output operation voltage (min): 208 V
UPS topology: Double-conversion (Online)
Typical backup time at full load: 3.5 min
Typical backup time at half load: 11 min
Output frequency regulation: ±0.5 Hz
Output voltage regulation: ±1%
RS-232 ports: 1
Power plug: C14 coupler
Product colour: Black
Harmonized System (HS) code: 85078000
USB port type: USB Type-B
Output voltage Total Harmonic Distortion (THD): 5%
Crest factor: 3:1
Output power factor: 0.9
Input power factor: 0.99
Built-in fan: Yes
Warnings: Keep away from sources of fire and water.
