Armac

Emergency power supply Armac UPS OFFICE LINE-INTERACTIVE O/650F/LCD

€57.32

Tax included

Product Details
Quick Compare

Product Details

Reference ZSIARMUPS0013

In stock 12 Items

Data sheet

Width: 85 mm
Height: 141 mm
Depth: 305 mm
Weight: 4.6 g
Number of batteries supported: 1
Operating temperature (T-T): 0 - 45 °C
Operating relative humidity (H-H): 10 - 90%
Form factor: Tower
USB port: Yes
Battery technology: Maintenance Free, Lead Acid (AGM)
Built-in display: LCD
Battery capacity: 7 Ah
Output power: 390 W
Input frequency: 45 - 65 Hz
Output voltage: 230 V
Response time: 2 - 6 ms
RJ-45 ports quantity: 2
Input operation voltage (min): 145 V
Power protection features: Battery discharge
Cold start: Yes
AC outlets quantity: 2 AC outlet(s)
Output power capacity: 650 VA
Output operation voltage (max): 195 V
Waveform: Sine
Auto-restart: Yes
AC outlet types: Type F
Input operation voltage (max): 290 V
Battery voltage: 12 V
Output operation voltage (min): 255 V
UPS topology: Line-Interactive
Typical backup time at full load: 3 min
Automatic Voltage Regulation (AVR): Yes
Automatic battery test: Yes
Typical backup time at half load: 20 min
Output frequency: 50 Hz
Noise Level: 45 dB
Product colour: Black
USB cable included: No
Battery recharge time (90%): 6 h
