Product Details
Data sheet
- Width
- 505 mm
- Height
- 88 mm
- Depth
- 438 mm
- Weight
- 22.9 kg
- Operating temperature (T-T)
- 0 - 40 °C
- Operating relative humidity (H-H)
- 20 - 95%
- Form factor
- Rackmount
- USB port
- Yes
- Battery technology
- Lead-acid
- Battery capacity
- 9 Ah
- Battery recharge time
- 6 h
- Output power
- 2000 W
- Input frequency
- 50/60 Hz
- Display type
- LCD
- Efficiency
- 90%
- Input operation voltage (min)
- 110 V
- AC outlets quantity
- 8 AC outlet(s)
- Output power capacity
- 2 kVA
- Output operation voltage (max)
- 240 V
- Waveform
- Pure sine
- AC outlet types
- C13 coupler
- Input operation voltage (max)
- 300 V
- Battery voltage
- 12 V
- Output operation voltage (min)
- 208 V
- UPS topology
- Line-Interactive
- Automatic Voltage Regulation (AVR)
- Yes
- Surge protection
- Yes
- Output voltage regulation
- 1%
- RS-232 ports
- 1
- International Protection (IP) code
- IP20
- Output frequency
- 50 Hz
- Noise Level
- 50 dB
- Product colour
- Black
- USB port type
- USB Type-B
- Number of batteries included
- 6 pc(s)
- Power factor
- 1
- Rack capacity
- 2U
Quick Compare
Product |
Eaton 9E uninterruptible power supply (UPS) Double-conversion (Online) 1 kVA 800 W 4 AC outlet(s)
|
Qoltec Uninterruptible Power Supply (UPS) for RACK | 3kVA | 3000W | Power Factor 1.0 | LCD | EPO | USB | Online
|
PowerWalker VI 1500 R1U uninterruptible power supply (UPS) Line-Interactive 1.5 kVA 900 W 4 AC outlet(s)
|
Green Cell UPS15 uninterruptible power supply (UPS) Double-conversion (Online) 3 kVA 2700 W 6 AC outlet(s)
|
Availability |
|
|
|
|
Price |
€433.42
|
€435.26
|
€437.98
|
€445.80
|
Description |
||||
Width |
228 mm | 438 mm | 433 mm | 440 mm |
Height |
356 mm | 88 mm | 44 mm | 430 mm |
Depth |
144 mm | 525 mm | 485 mm | 86.5 mm |
Weight |
9.5 kg | 20 kg | 16.2 kg | 13.9 kg |
Package height |
180 mm | |||
Package width |
620 mm | |||
Number of batteries supported |
4 | |||
Storage relative humidity (H-H) |
20 - 95% | |||
Manual |
Yes | |||
Operating temperature (T-T) |
0 - 40 °C | 0 - 40 °C | 0 - 40 °C | |
Operating relative humidity (H-H) |
0 - 90% | |||
Storage temperature (T-T) |
-15 - 60 °C | |||
Form factor |
Tower | |||
USB port |
Yes | Yes | Yes | |
LED indicators |
Battery level | |||
Battery capacity |
7 Ah | 9 Ah | ||
Battery recharge time |
6 h | |||
Cooling type |
Active | |||
Output power |
800 W | 3000 W | 900 W | 2700 W |
Input frequency |
50/60 Hz | 50/60 Hz | 45/55 Hz | 45/65 Hz |
USB 2.0 ports quantity |
1 | |||
Display type |
LCD | |||
Ethernet LAN (RJ-45) ports |
2 | |||
Efficiency |
91% | |||
Input operation voltage (min) |
100 V | 110 V | 165 V | 110 V |
Power protection features |
Short circuit | Overload | Overcharge | |
Cold start |
Yes | |||
AC outlets quantity |
4 AC outlet(s) | 1 AC outlet(s) | 4 AC outlet(s) | 6 AC outlet(s) |
Output power capacity |
1 kVA | 3 kVA | 1.5 kVA | 3 kVA |
Output operation voltage (max) |
240 V | 230 V | 230 V | 240 V |
Waveform |
Pure sine | Pure sine | ||
AC outlet types |
IEC 320 | Schuko | C13 coupler | |
Input operation voltage (max) |
300 V | 300 V | 290 V | 290 V |
Battery voltage |
12 V | 6 V | 12 V | |
Output operation voltage (min) |
208 V | 230 V | 230 V | 200 V |
UPS topology |
Double-conversion (Online) | Double-conversion (Online) | Line-Interactive | Double-conversion (Online) |
Typical backup time at full load |
4 min | 0.4 min | ||
Automatic Voltage Regulation (AVR) |
Yes | |||
Typical backup time at half load |
12 min | 8.7 min | ||
RS-232 ports |
1 | 1 | 1 | |
Serial interface type |
RS-232 | |||
Output frequency |
50/60 Hz | 50 Hz | 50/60 Hz | |
Noise Level |
37 dB | 50 dB | ||
Serial ports quantity |
1 | |||
Power plug |
C13 coupler | C14 coupler | ||
Product colour |
Black | Black | Black | |
Harmonized System (HS) code |
85078000 | |||
Safety |
IEC/EN 62040-1 | |||
Serial interface |
Yes | |||
USB port type |
USB Type-B | |||
Number of batteries |
6 | |||
Power factor |
1 | |||
Number of output IEC jumpers |
1 | |||
Rack capacity |
1U | |||
Number of type F outputs |
2 | |||
Built-in fan |
Yes | |||
Battery recharge time (90%) |
8 h | |||
Apparent power |
3000 VA | |||
Overload capacity (1 minute) |
130% | |||
Overload capacity (10 seconds) |
150% | |||
Warnings |
Keep away from sources of fire and water. | |||
Overload capacity (5 minute) |
150% | |||
