Product Details
Data sheet
- Cable length
- 1.83 m
- Width
- 138 mm
- Height
- 157 mm
- Depth
- 358 mm
- Weight
- 13.2 kg
- Package height
- 301 mm
- Package width
- 278 mm
- Cables included
- USB cable
- Storage relative humidity (H-H)
- 0 - 95%
- Manual
- Yes
- Operating temperature (T-T)
- 0 - 40 °C
- Operating relative humidity (H-H)
- 5 - 95%
- Storage temperature (T-T)
- -15 - 45 °C
- Form factor
- Tower
- USB port
- Yes
- LED indicators
- Status
- Battery technology
- Sealed Lead Acid (VRLA)
- Battery life (max)
- 5 year(s)
- Battery recharge time
- 3 h
- Output power
- 500 W
- Input frequency
- 50/60 Hz
- Display type
- LCD
- Ethernet LAN (RJ-45) ports
- 1
- Efficiency
- 98%
- Input operation voltage (min)
- 151 V
- Cold start
- Yes
- AC outlets quantity
- 6 AC outlet(s)
- Output power capacity
- 0.75 kVA
- Output operation voltage (max)
- 240 V
- Waveform
- Sine
- Auto-restart
- Yes
- AC outlet types
- C13 coupler
- Input operation voltage (max)
- 302 V
- Audible alarm(s)
- Yes
- Output operation voltage (min)
- 220 V
- UPS topology
- Line-Interactive
- Typical backup time at full load
- 4.6 min
- Automatic Voltage Regulation (AVR)
- Yes
- Automatic battery test
- Yes
- Typical backup time at half load
- 15.8 min
- Operating altitude
- 0 - 3000 m
- Quick installation guide
- Yes
- Noise Level
- 40 dB
- Surge energy rating
- 540 J
- Power plug
- C14 coupler
- Non-operating altitude
- 0 - 15000 m
- Product colour
- Black
- Harmonized System (HS) code
- 85078000
- Sustainability certificates
- Green Premium
- Hot-swap battery
- Yes
- Compliance certificates
- RoHS
- Number of output IEC jumpers
- 2
- SmartSlot
- Yes
Quick Compare
Product |
CyberPower OR1500ERM1U uninterruptible power supply (UPS) Line-Interactive 1500 VA 900 W 6 AC outlet(s) | POWER WALKER UPS ON-LINE VFI 3000 AT FR | APC BR1600MI uninterruptible power supply (UPS) Line-Interactive 1.6 kVA 960 W 8 AC outlet(s) | DIGITUS OnLine UPS, rack/tower, 1500VA, 1500W, LCD, 8 x C13, 1 x C19, RS-232, USB, RJ45, SNMP card (optional), relay card (optio |
Availability |
|
|
|
|
Price |
€499.71
|
€501.80
|
€512.59
|
€519.54
|
Description |
DIGITUS OnLine UPS, rack/tower, 1500VA, 1500W, LCD, 8 x C13, 1 x C19, RS-232, USB, RJ45, SNMP card (optional), relay card (optional) Digitus | |||
Warranty |
24 month(s) | |||
Producer product name |
OnLine UPS Modul, 1500VA/1500W | |||
Net weight |
19.2 kg | |||
Gross weight |
19.6 kg | |||
WEEE tax |
Yes | |||
Packing quantity |
1.00 pc(s) | |||
Volume (m3) |
0.068915875 m | |||
Tare weight (kg) |
0.40 kg | |||
Gross depth (mm) |
565 mm | |||
Gross width (mm) |
595.00 mm | |||
Gross height (mm) |
205 mm | |||
WEE classification |
CL109:6:2017-04-01 | |||
Paper/Pasteboard |
350.00 g | |||
Embeeded battery |
Yes | |||
TI weight (kg) |
19.00 kg | |||
Cable length |
1.83 m | 1.83 m | ||
Width |
443 mm | 196 mm | 250 mm | |
Height |
44 mm | 342 mm | 100 mm | |
Depth |
389 mm | 416 mm | 382 mm | |
Other features |
Easy-to-use LCD screen provides insight into UPS status for easy installation, configuration and operation. Various communication interfaces (RS232/USB, parallel port, SNMP slot) enable remote monitoring of the system. | |||
Plastic (No PET) |
50.00 g | |||
Composition of battery |
CL127:KT:2016-12-09 | |||
Classification of battery |
CL126:NE:2016-12-09 | |||
Type of battery |
Accumulator | |||
Weight |
14.9 kg | 25.4 kg | 10.9 kg | |
Producer product family |
OnLine UPS | |||
Package height |
342 mm | 330 mm | ||
Package width |
294 mm | 485 mm | ||
Cables included |
USB cable | |||
Storage relative humidity (H-H) |
0 - 95% | 0 - 95% | ||
Manual |
Yes | Yes | ||
Operating temperature (T-T) |
0 - 40 °C | 0 - 40 °C | 0 - 40 °C | |
Operating relative humidity (H-H) |
0 - 95% | 20 - 90% | 0 - 95% | |
Storage temperature (T-T) |
-15 - 45 °C | -15 - 45 °C | ||
Form factor |
Rackmount | Tower | ||
USB port |
Yes | Yes | Yes | |
LED indicators |
Yes | |||
Battery technology |
Sealed Lead Acid (VRLA) | Sealed Lead Acid (VRLA) | ||
Battery life (max) |
5 year(s) | |||
Battery capacity |
9 Ah | |||
Capacity |
1500 W | |||
Battery recharge time |
4 h | 16 h | ||
Cooling type |
Passive | |||
Display |
LCD | |||
Output power |
900 W | 2700 W | 960 W | |
Input frequency |
50/60 Hz | 40 - 70 Hz | 50/60 Hz | |
USB 2.0 ports quantity |
1 | |||
Display type |
LCD | |||
Ethernet LAN (RJ-45) ports |
1 | 2 | ||
Number of battery cells |
6 | |||
Input operation voltage (min) |
165 V | 80 V | 176 V | |
Power protection features |
Overload | |||
Cold start |
Yes | |||
AC outlets quantity |
6 AC outlet(s) | 4 AC outlet(s) | 8 AC outlet(s) | |
Output power capacity |
1500 kVA | 3000 kVA | 1.6 kVA | |
Output operation voltage (max) |
230 V | 240 V | ||
Waveform |
Sine | Sine | Sine | |
AC outlet types |
C13 coupler | Type E / F | C13 coupler | |
Input operation voltage (max) |
271 V | 300 V | 294 V | |
Audible alarm(s) |
Yes | Yes | ||
Battery voltage |
12 V | |||
Output operation voltage (min) |
208 V | |||
UPS topology |
Line-Interactive | Double-conversion (Online) | Line-Interactive | On line |
Cabling technology |
10/100/1000Base-T(X) | |||
Automatic Voltage Regulation (AVR) |
Yes | Yes | ||
Automatic battery test |
Yes | |||
Surge protection |
Yes | |||
Nominal input voltage |
230 V | |||
Nominal output voltage |
230 V | |||
Output frequency regulation |
0.5 Hz | |||
Output voltage regulation |
± 1% | |||
Operating altitude |
0 - 3000 m | |||
Output frequency |
50/60 Hz | 50/60 Hz | ||
Noise Level |
45 dB | |||
Serial ports quantity |
1 | |||
Maximum current |
10 A | |||
Surge energy rating |
509 J | |||
Power plug |
C14 coupler | |||
Non-operating altitude |
0 - 15000 m | |||
Product colour |
Silver | Black | Black | |
Harmonized System (HS) code |
85078000 | |||
Sustainability certificates |
RoHS | |||
ECO mode |
Yes | |||
Hot-swap battery |
Yes | Yes | ||
Audible alarm modes |
Fault, Low battery alarm, Overload alarm | Alarm when on battery, Low battery alarm, Overload alarm | ||
Power factor |
0.9 | |||
Surge protection features |
Network | |||
Emergency Power Off (EPO) |
Yes | |||
Rack capacity |
1U | |||
EMI/RFI noise filtering |
Yes | |||
Emergency Power Off (EPO) connector |
Yes | |||
Expansion module support |
Yes | |||
