Product Details
Data sheet
- Type
- IP security camera
- Width
- 184 mm
- Height
- 74 mm
- Depth
- 74 mm
- Connectivity technology
- Wired
- Weight
- 525 g
- Power source type
- DC, PoE
- Storage relative humidity (H-H)
- 0 - 95%
- Operating temperature (T-T)
- -30 - 60 °C
- Operating relative humidity (H-H)
- 0 - 95%
- Storage temperature (T-T)
- -40 - 60 °C
- Mounting type
- Wall
- Form factor
- Bullet
- Built-in microphone
- Yes
- Bluetooth
- No
- Noise reduction
- Yes
- Sensor type
- CMOS
- Wi-Fi
- No
- Compatible memory cards
- MicroSD (TransFlash)
- Maximum memory card size
- 512 GB
- Audio system
- 2-way
- Signal-to-Noise Ratio (SNR)
- 52 dB
- Power consumption (max)
- 9.7 W
- Maximum resolution
- 2688 x 1520 pixels
- Built-in speaker(s)
- Yes
- Placement supported
- Outdoor
- Card reader integrated
- Yes
- Ethernet LAN (RJ-45) ports
- 1
- DC-in jack
- Yes
- Housing material
- Metal
- Ethernet LAN
- Yes
- Supported graphics resolutions
- 1280 x 720 (HD 720)
- International Protection (IP) code
- IP67
- Ethernet interface type
- Fast Ethernet
- Supported network protocols
- TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS
- Reset button
- Yes
- Password protection
- Yes
- Frame Rate
- 30 fps
- Product colour
- White
- Tilt angle range
- 0 - 90°
- Fixed focal length
- 6 mm
- LED type
- IR/White
- Night vision
- Yes
- Total megapixels
- 4 MP
- Optical sensor size
- 25.4 / 2.7 mm (1 / 2.7")
- Minimum illumination
- 0.005 lx
- Pan range
- 0 - 360°
- Dynamic range
- 120 dB
- Lens viewing angle, diagonal
- 60.8°
- Video compression formats
- H.265
- Angle of rotation
- 360°
- DC output voltage
- 12
- Video motion detection
- Yes
- Number of cameras
- 1
- Night vision distance
- 30 m
- Number of lenses
- 1
- Day/night mode
- Yes
- Infrared (IR) cut-off filter
- Yes
- Built-in HDD
- No
- Lens viewing angle, vertical
- 29°
- Noise reduction technology
- 3D noise reduction
- Smart IR
- Yes
- Region of Interest (ROI) encoding
- Yes
- Maximum aperture number
- 1.6
- Lens viewing angle, horizontal
- 52.7°
- Infra-red wavelength
- 850 nm
- Wide Dynamic Range (WDR)
- Yes
- Progressive scan
- Yes
- Mirror
- Yes
- Back Light Compensation (BLC)
- Yes
- IP address filtering
- Yes
- Camera shutter speed
- 1/3 to 1/10000 s
- Bit rate control
- Constant Bit Rate (CBR), Variable Bit Rate (VBR)
- Privacy masking
- Yes
- Highlight Compensation (HLC)
- Yes
- Number of illumination LEDs
- 2
- Live view
- Yes
- Power consumption (Power over Ethernet (PoE))
- 10.7 W
- Digest authentication
- Yes
- Built-in light
- Yes
- Detect distance
- 120 m
- Observe distance
- 50 m
- Recognize distance
- 24 m
- Identify distance
- 12 m
- Human and vehicle targets classification
- Yes
- Number of Privacy masking areas
- 4
- Warnings
- The product contains electronic components; do not dispose of with the normal household waste.
Quick Compare
Product |
DS-2CD1063G2-LIU(2.8mm) IP Camera
|
|
IP network camera Full HD HDW2231T-AS 3.6
|
IP network camera FULL HD HFW2231S-S black 2.8mm
|
Availability |
|
|
|
|
Price |
€94.90
|
€95.02
|
€95.04
|
€95.04
|
Description |
||||
Type |
IP security camera | |||
Width |
66 mm | |||
Height |
69.1 mm | |||
Connectivity technology |
Wired | |||
Weight |
285 g | |||
Package depth |
121 mm | |||
Package height |
118 mm | |||
Package width |
216 mm | |||
Package weight |
481 g | |||
Power source type |
DC, PoE | |||
Storage relative humidity (H-H) |
0 - 95% | |||
Operating temperature (T-T) |
-30 - 60 °C | |||
Operating relative humidity (H-H) |
0 - 95% | |||
Storage temperature (T-T) |
-30 - 60 °C | |||
Mounting type |
Ceiling/wall | |||
Form factor |
Bullet | |||
Built-in microphone |
Yes | |||
Bluetooth |
No | |||
Bit rate |
32 Kbps - 16 Mbps | |||
Protection features |
Waterproof | |||
Length |
170.8 mm | |||
Sensor type |
CMOS | |||
Wi-Fi |
No | |||
Audio formats supported |
G.722.1 | |||
Signal-to-Noise Ratio (SNR) |
52 dB | |||
Power consumption (max) |
5 W | |||
Maximum resolution |
3200 x 1800 pixels | |||
Placement supported |
Indoor & outdoor | |||
Ethernet LAN (RJ-45) ports |
1 | |||
Number of languages |
2 | |||
Housing material |
Plastic | |||
Ethernet LAN |
Yes | |||
Supported graphics resolutions |
640 x 360 | |||
International Protection (IP) code |
IP67 | |||
Ethernet interface type |
Fast Ethernet | |||
Number of Users |
32 user(s) | |||
Web-based management |
Yes | |||
Supported network protocols |
TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6, UDP, QoS, FTP, SMTP | |||
Password protection |
Yes | |||
Languages support |
Ukrainian | |||
Product colour |
White | |||
Tilt angle range |
0 - 90° | |||
Sustainability compliance |
Yes | |||
Fixed focal length |
2.8 mm | |||
Night vision |
Yes | |||
Total megapixels |
6 MP | |||
Fixed focus |
Yes | |||
Optical sensor size |
25.4 / 2.4 mm (1 / 2.4") | |||
Minimum illumination |
0 lx | |||
Pan range |
0 - 360° | |||
Dynamic range |
120 dB | |||
Lens viewing angle, diagonal |
127° | |||
Video compression formats |
H.265+ | |||
Angle of rotation |
360° | |||
DC output current |
0.41 A | |||
DC output voltage |
12 | |||
Video motion detection |
Yes | |||
Number of cameras |
1 | |||
Night vision distance |
30 m | |||
Number of lenses |
1 | |||
Privacy protection |
Yes | |||
Day/night mode |
Yes | |||
Infrared (IR) cut-off filter |
Yes | |||
Built-in HDD |
No | |||
Lens viewing angle, vertical |
55° | |||
Region of Interest (ROI) encoding |
Yes | |||
Maximum aperture number |
1.6 | |||
Lens viewing angle, horizontal |
105° | |||
Number of sensors |
1 | |||
Infra-red wavelength |
850 nm | |||
Wide Dynamic Range (WDR) |
Yes | |||
Progressive scan |
Yes | |||
Mirror |
Yes | |||
Heartbeat |
Yes | |||
Digital watermark |
Yes | |||
Back Light Compensation (BLC) |
Yes | |||
Video streaming |
Yes | |||
Camera shutter speed |
1 - 1/100000 s | |||
Bit rate control |
Constant Bit Rate (CBR)/Variable Bit Rate (VBR) | |||
Privacy masking |
Yes | |||
Highlight Compensation (HLC) |
Yes | |||
Live view |
Yes | |||
Power consumption (Power over Ethernet (PoE)) |
6.5 W | |||
Image quality adjustment |
Sharpness | |||
Digest authentication |
Yes | |||
Password reset via email |
Yes | |||
Number of simultaneous live view channels |
6 channels | |||
User access level |
Administrator, Operator, User | |||
Built-in light |
Yes | |||
Detect distance |
76 m | |||
Observe distance |
30 m | |||
Recognize distance |
15 m | |||
Identify distance |
7 m | |||
Client interoperability |
iVMS-4200, Hik-Connect | |||
Bit rate range |
16 - 160 Kbit/s | |||
Compliance certificates |
Low Voltage Directive (LVD) | |||
Number of Privacy masking areas |
4 | |||
Sample rates |
8 - 16 kHz | |||
Warnings |
The product contains electronic components; do not dispose of with the normal household waste. | |||
Audit log |
Yes | |||
