Product Details
Data sheet
- Type
- IP security camera
- Width
- 63 mm
- Height
- 63 mm
- Depth
- 153.3 mm
- Connectivity technology
- Wireless
- Weight
- 223 g
- Package weight
- 569 g
- Power source type
- Battery, DC
- Cables included
- USB
- Operating temperature (T-T)
- -20 - 50 °C
- Operating relative humidity (H-H)
- 0 - 95%
- Mounting type
- Wall
- Noise reduction
- Yes
- Power supply
- Built-in rechargeable battery
- Battery capacity
- 5200 mAh
- Cord length
- 4 m
- Sensor type
- CMOS
- Wi-Fi
- Yes
- Compatible memory cards
- MicroSD (TransFlash)
- Wi-Fi standards
- Wi-Fi 4 (802.11n)
- Maximum memory card size
- 512 GB
- Power consumption (max)
- 10 W
- Maximum resolution
- 2304 x 1296 pixels
- Tilt adjustment
- Yes
- Placement supported
- Outdoor
- Card reader integrated
- Yes
- Networking standards
- IEEE 802.11g
- Security algorithms
- WPA3-Personal
- Supported graphics resolutions
- 2304 x 1296
- International Protection (IP) code
- IP65
- Video formats supported
- H.265
- Maximum current
- 0.7 A
- Password protection
- Yes
- Power supply voltage
- 6 V
- Product colour
- White
- Screws included
- Yes
- Night vision
- Yes
- Total megapixels
- 3 MP
- Optical sensor size
- 25.4 / 2.8 mm (1 / 2.8")
- Lens viewing angle, diagonal
- 130°
- Operating frequency
- 2400 - 2.4835 MHz
- Number of cameras
- 1
- Camera pan control
- No
- Camera tilt control
- No
- Night vision distance
- 15 m
- Infrared (IR) cut-off filter
- Yes
- Built-in HDD
- No
- Lens viewing angle, vertical
- 56°
- Noise reduction technology
- 3D noise reduction
- Maximum aperture number
- 1.6
- Channel bandwidth
- 20 MHz
- Lens viewing angle, horizontal
- 108°
- Progressive scan
- Yes
- Heartbeat
- Yes
- Anti-flicker
- Yes
- Digital watermark
- Yes
- Weatherproof
- Yes
- Mounting brackets included
- Yes
- Product dimensions
- 105.9 x 62.8 x 62.8 mm
- Solar panel current
- 740 mA
- Solar panel
- 4.2 W
- Solar cell type
- Monocrystalline silicon
- Solar panel included
- Y
- Idle voltage
- 7.2 V
- Power supply
- Built-in rechargeable battery
- Warnings
- The product contains electronic components; do not dispose of with the normal household waste.
