IP network camera FULL HD HFW2231S-S black 2.8mm
    DAHUA TECHNOLOGY CO., LTD

    IP network camera FULL HD HFW2231S-S black 2.8mm

    €98.77
    Tax included
    Quantity

    Add to favorites Add to compare
    Camera
    Image Sensor 1/2.8" CMOS
    Max. Resolution 1920 (H) × 1080 (V)
    ROM 128 MB
    RAM 128 MB
    Scanning System Progressive
    Electronic Shutter Speed Auto/Manual 1/3 s–1/100,000 s
    Min. Illumination 0.002 Lux@F1.6 (Color, 30 IRE)
    0.0002 Lux@F1.6 (B/W, 30 IRE)
    0 Lux (Illuminator on)
    S/N Ratio > 56 dB
    Illumination Distance 30 m (98.43 ft) (IR)
    Illuminator On/Off Control Auto; manual
    Illuminator Number 1 (IR LED)
    Pan/Tilt/Rotation Range Pan: 0°–360°
    Tilt: 0°–90°
    Rotation: 0°–360°
    Lens
    Lens Type Fixed-focal
    Lens Mount M12
    Focal Length 2.8 mm
    Max. Aperture 2.8 mm: F1.6
    Field of View 2.8 mm: Horizontal: 107°; Vertical: 56°; Diagonal: 127°
    Iris Control Fixed
    Close Focus Distance 2.8 mm: 0.7 m (2.30 ft)
    DORI Distance Lens Detect Observe Recognize Identify
    2.8 mm 43.9 m (144.03 ft) 17.5 m (57.41 ft) 8.8 m (28.87 ft) 4.4 m (14.44 ft)
    Smart Event
    IVS Tripwire; intrusion
    Video
    Video Compression H.265; H.264; H.264B; MJPEG (Only supported by the sub stream)
    Smart Codec Smart H.265+; Smart H.264+
    Video Frame Rate Main stream:
    1920 × 1080@1–25/30 fps
    Sub stream:
    704 × 576@1–25 fps
    704 × 480@1–30 fps
    *The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity
    Stream Capability 2 streams
    Resolution 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)
    Bit Rate Control CBR/VBR
    Video Bit Rate H.264: 32 kbps–6144 kbps
    H.265: 12 kbps–6144 kbps
    Day/Night Auto(ICR)/Color/B/W
    BLC Yes
    HLC Yes
    WDR 120 dB
    White Balance Auto; natural; street lamp; outdoor; manual; regional custom
    Gain Control Auto; manual
    Noise Reduction 3D NR
    Motion Detection OFF/ON (4 areas, rectangular)
    Region of Interest (RoI) Yes (4 areas)
    Smart Illumination Yes
    Image Rotation 0°/90°/180°/270° (Support 90°/270° with 1080p resolution and lower)
    Mirror Yes
    Privacy Masking 4 areas
    Alarm
    Alarm Event No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; voltage detection; security exception
    Network
    Network Port RJ-45 (10/100 Base-T)
    SDK and API Yes
    Cyber Security Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade
    Network Protocol IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; Boujour
    Interoperability ONVIF (Profile S/Profile G/Profile T); CGI; P2P; Milestone
    User/Host 20 (Total bandwidth: 48 M)
    Storage FTP; SFTP; Micro SD card (support max. 256 G); NAS
    Browser IE
    Chrome
    Firefox
    Management Software Smart PSS; DSS; DMSS
    Mobile Client IOS; Android
    Certification
    Certifications CE-LVD: EN 62368-1
    CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
    FCC: 47 CFR FCC Part 15, Subpart B
    Power
    Power Supply 12 V DC/PoE (802.3af)
    Power Consumption Basic: 1.8 W (12 V DC); 2.4 W (PoE)
    Max. (ICR + H.265 + max. resolution + main stream + IR intensity + WDR + IVS): 3.9 W (12 V DC); 4.6 W (PoE)
    Environment
    Operating Temperature –40 °C to +60 °C (–40 °F to +140 °F)
    Operating Humidity ? 95%
    Storage Temperature –40 °C to +60 °C (–40 °F to +140 °F)
    Protection IP67
    Structure
    Casing Metal
    Product Dimensions 166.2 mm × ?70 mm (6.54" × ?2.76")
    Net Weight 0.48 kg (1.06 lb)
    Gross Weight 0.57 kg (1.26 lb)

    Product Details

    HFW2231S-SB
