Product Details
Data sheet
- Type
- IP security camera
- Height
- 62.8 mm
- Depth
- 62.8 mm
- Connectivity technology
- Wired & Wireless
- Weight
- 522 g
- Package depth
- 186 mm
- Package height
- 103 mm
- Package width
- 103 mm
- Power source type
- Battery, DC
- Cables included
- USB
- Operating temperature (T-T)
- -20 - 50 °C
- Operating relative humidity (H-H)
- 0 - 95%
- Mounting type
- Wall
- Form factor
- Bullet
- Noise reduction
- Yes
- Length
- 105.9 mm
- Sensor type
- CMOS
- Wi-Fi
- Yes
- Compatible memory cards
- MicroSD (TransFlash)
- Wi-Fi standards
- 802.11b
- Maximum memory card size
- 256 GB
- Power consumption (max)
- 10 W
- Maximum resolution
- 2304 x 1296 pixels
- Placement supported
- Outdoor
- Card reader integrated
- Yes
- Networking standards
- IEEE 802.11b
- Security algorithms
- WPA2-PSK
- Supported graphics resolutions
- 2304 x 1296
- Video formats supported
- H.264
- Password protection
- Yes
- Product colour
- Black
- Screws included
- Yes
- Night vision
- Yes
- Total megapixels
- 3 MP
- Optical sensor size
- 25.4 / 2.8 mm (1 / 2.8")
- Lens viewing angle, diagonal
- 131°
- Operating frequency
- 2400 - 2.4835 MHz
- Number of cameras
- 1
- Camera pan control
- No
- Camera tilt control
- No
- Night vision distance
- 15 m
- Infrared (IR) cut-off filter
- Yes
- Built-in HDD
- No
- Lens viewing angle, vertical
- 58°
- Noise reduction technology
- 3D noise reduction
- Maximum aperture number
- 2.8
- Channel bandwidth
- 20 MHz
- Lens viewing angle, horizontal
- 110°
- Progressive scan
- Yes
- Heartbeat
- Yes
- Anti-flicker
- Yes
- Digital watermark
- Yes
- Weatherproof
- Yes
- Mounting brackets included
- Yes
