Product Details
Data sheet
- Type
- IP security camera
- Height
- 62.8 mm
- Depth
- 62.8 mm
- Connectivity technology
- Wireless
- Weight
- 522 g
- Package depth
- 186 mm
- Package height
- 103 mm
- Package width
- 103 mm
- Power source type
- Battery
- Cables included
- USB
- Manual
- Yes
- Operating temperature (T-T)
- -20 - 50 °C
- Operating relative humidity (H-H)
- 0 - 95%
- Mounting type
- Wall
- Form factor
- Bullet
- Built-in microphone
- Yes
- Bluetooth
- No
- Bit rate
- 1.5 Mbps
- Noise reduction
- Yes
- Battery capacity
- 5200 mAh
- Length
- 105.9 mm
- Sensor type
- CMOS
- Wi-Fi
- Yes
- Compatible memory cards
- MicroSD (TransFlash)
- Wi-Fi standards
- 802.11g
- Maximum memory card size
- 256 GB
- Audio system
- 2-way
- Power consumption (max)
- 10 W
- Maximum resolution
- 2304 x 1296 pixels
- Built-in speaker(s)
- Yes
- Placement supported
- Outdoor
- Card reader integrated
- Yes
- Security algorithms
- 128-bit WEP
- Ethernet LAN
- No
- Supported graphics resolutions
- 2304 x 1296
- Wi-Fi data rate (max)
- 72 Mbit/s
- Video formats supported
- H.265
- Reset button
- Yes
- Password protection
- Yes
- Product colour
- Black
- Sustainability compliance
- Yes
- Fixed focal length
- 2.8 mm
- Screws included
- Yes
- LED type
- IR
- Night vision
- Yes
- Total megapixels
- 3 MP
- Motion sensor
- Yes
- Optical sensor size
- 25.4 / 2.8 mm (1 / 2.8")
- Minimum illumination
- 0 lx
- Lens viewing angle, diagonal
- 131°
- Video compression formats
- H.264
- DC output current
- 2 A
- DC output voltage
- 5
- Video motion detection
- Yes
- Operating frequency
- 2400 - 2.4835 MHz
- Number of cameras
- 1
- Motion sensor technology
- Passive infrared (PIR) sensor
- Day/night mode
- Yes
- Infrared (IR) cut-off filter
- Yes
- Built-in HDD
- No
- Lens viewing angle, vertical
- 58°
- Noise reduction technology
- 3D noise reduction
- Maximum aperture number
- 2
- Channel bandwidth
- 20 MHz
- Lens viewing angle, horizontal
- 110°
- Progressive scan
- Yes
- Heartbeat
- Yes
- Anti-flicker
- Yes
- Digital watermark
- Yes
- Weatherproof
- Yes
- Mounting brackets included
- Yes
- Built-in light
- Yes
- Drilling template included
- Yes
- B/W night vision distance
- 15 m
- Colour night vision distance
- 15 m
- Compliance certificates
- RoHS
- Warnings
- The product contains electronic components; do not dispose of with the normal household waste.
Quick Compare
Product |
|
![]() |
![]() |
![]() |
Availability |
|
|
|
|
Price |
€75.40
|
€75.90
|
€76.42
|
€76.56
|
Description |
||||
Type |
IP security camera | |||
Width |
162.1 mm | |||
Height |
70.1 mm | |||
Depth |
70.1 mm | |||
Connectivity technology |
Wired | |||
Weight |
320 g | |||
Power source type |
DC | |||
Operating temperature (T-T) |
-40 - 60 °C | |||
Operating relative humidity (H-H) |
0 - 95% | |||
Storage temperature (T-T) |
-40 - 60 °C | |||
Mounting type |
Ceiling/wall | |||
Form factor |
Bullet | |||
Built-in microphone |
Yes | |||
Bluetooth |
No | |||
Noise reduction |
Yes | |||
Mobile operating systems supported |
Android | |||
Sensor type |
CMOS | |||
Wi-Fi |
No | |||
Internal memory |
128 MB | |||
Signal-to-Noise Ratio (SNR) |
56 dB | |||
Power consumption (max) |
4.5 W | |||
Power consumption (typical) |
2.3 W | |||
Maximum resolution |
2880 x 1620 pixels | |||
Placement supported |
Indoor & outdoor | |||
Ethernet LAN (RJ-45) ports |
1 | |||
Housing material |
Metal | |||
Networking standards |
IEEE 802.1x | |||
Security algorithms |
HTTPS | |||
Ethernet LAN |
Yes | |||
Supported graphics resolutions |
2560 x 1440 | |||
International Protection (IP) code |
IP67 | |||
Ethernet interface type |
Gigabit Ethernet | |||
Video formats supported |
H.264 | |||
Supported network protocols |
IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; SMTP; FTP; DHCP; DNS; DDNS; NTP; Multicast | |||
Frame Rate |
20 fps | |||
Product colour |
White | |||
Tilt angle range |
0 - 90° | |||
Focal length range |
2.8 mm | |||
Web browser |
Yes | |||
Video recording |
Yes | |||
LED type |
IR | |||
Night vision |
Yes | |||
Total megapixels |
5 MP | |||
Optical sensor size |
25.4 / 2.7 mm (1 / 2.7") | |||
White balance |
Outdoor | |||
Field of view (FOV) angle |
106° | |||
Minimum illumination |
0.03 lx | |||
Pan range |
0 - 360° | |||
Lens viewing angle, diagonal |
125° | |||
Video compression formats |
H.264 | |||
Angle of rotation |
360° | |||
DC output voltage |
12 | |||
Video motion detection |
Yes | |||
Number of cameras |
1 | |||
Night vision distance |
30 m | |||
Number of lenses |
2 | |||
Day/night mode |
Yes | |||
Built-in HDD |
No | |||
Camera shutter type |
Electronic | |||
Lens viewing angle, vertical |
56° | |||
Noise reduction technology |
3D noise reduction | |||
Smart IR |
Yes | |||
Digital Wide Dynamic Range (DWDR) |
Yes | |||
Region of Interest (ROI) encoding |
Yes | |||
Maximum aperture number |
2 | |||
Lens viewing angle, horizontal |
106° | |||
Number of sensors |
1 | |||
Wide Dynamic Range (WDR) |
Yes | |||
Progressive scan |
Yes | |||
Mirror |
Yes | |||
Back Light Compensation (BLC) |
Yes | |||
Video streaming |
Yes | |||
ROM capacity |
16 MB | |||
Camera shutter speed |
1/3 s–1/100,000 | |||
Adjustment shutter speed |
Auto/Manual | |||
Number of effective pixels (H x V) |
2880 x 1620 pixels | |||
Effective sensor resolution |
2 pixels | |||
Bit rate control |
Constant Bit Rate (CBR)/Variable Bit Rate (VBR) | |||
Gain control type |
Auto/Manual | |||
Privacy masking |
Yes | |||
Highlight Compensation (HLC) |
Yes | |||
Number of illumination LEDs |
1 | |||
Minimum illumination (panoramic camera) |
0.003 lx | |||
Signal-to-Noise Ratio (SNR) (panoramic camera) |
56 dB | |||
Management software |
Smart PSS; DSS; DMSS | |||
Closest focusing distance |
0.8 m | |||
Detect distance |
56 m | |||
Observe distance |
22.4 m | |||
Recognize distance |
11.2 m | |||
Identify distance |
5.6 m | |||
