Camera | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Image Sensor | 1/2.7" CMOS | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Max. Resolution | 2592 (H) × 1944 (V) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
ROM | 128 MB | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
RAM | 512 MB | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Scanning System | Progressive | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Electronic Shutter Speed | Auto/Manual 1/3 s–1/100,000 s | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Min. Illumination | 0.005 lux@F1.5(Color,30 IRE) 0.0005 lux@F1.5(B/W,30 IRE) 0 lux (Illuminator on) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
S/N Ratio | >56 dB | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Illumination Distance | 40 m (131.23 ft) (IR LED) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Illuminator On/Off Control | Auto; Manual | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Illuminator Number | 2 (IR LED) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Pan/Tilt/Rotation Range | Pan: 0°–355° Tilt: 0°–75° Rotation: 0°–355° | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Lens | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Lens Type | Motorized vari-focal | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Lens Mount | ?14 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Focal Length | 2.7 mm–13.5 mm | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Max. Aperture | F1.5 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Field of View | H: 100°–30° V: 72° –23° D: 134° –38° | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Iris Control | Fixed | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Close Focus Distance | 0.8 m (2.62 ft) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
DORI Distance | Lens | Detect | Observe | Recognize | Identify | ||||||||||||||||||||||||||||||||||||||||||||||||||||||
W | 64.4 m (211.29 ft) | 25.8 m (84.65 ft) | 12.9 m (42.32 ft) | 6.4 m (21.00 ft) | |||||||||||||||||||||||||||||||||||||||||||||||||||||||
T | 221.4 m (726.37 ft) | 88.6 m (290.68 ft) | 44.3 m (145.34 ft) | 22.1 m (72.51 ft) | |||||||||||||||||||||||||||||||||||||||||||||||||||||||
Intelligence | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
IVS (Perimeter Protection) | Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Smart Search | Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Video | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Video Compression | H.265; H.264; H.264H; H.264B; MJPEG (Only supported by the sub stream) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Smart Codec | Smart H.265+; Smart H.264+ | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Video Frame Rate | Main stream: 2592 × 1944@(1–20 fps)/2688 × 1520@(1–25/30 fps) sub stream: 704 × 576@(1–25 fps)/704 × 480@(1–30 fps) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Stream Capability | 2 streams | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Resolution | 5M (2592 × 1944); 4M (2688 × 1520); 3M (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Bit Rate Control | CBR/VBR | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Video Bit Rate | H.264: 3 kbps–8192 kbps H.265: 3 kbps–8192 kbps | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Day/Night | Auto(ICR)/Color/B/W | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
BLC | Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
HLC | Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
WDR | 120 dB | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Scene Self-adaptation (SSA) | Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
White Balance | Auto; natural; street lamp; outdoor; manual; regional custom | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Gain Control | Auto;Manual | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Noise Reduction | 3D DNR | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Motion Detection | OFF/ON (4 areas, rectangular) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Region of Interest (RoI) | Yes (4 areas) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Smart Illumination | Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Image Rotation | 0°/90°/180°/270° (Support 90°/270° with 1080p resolution and lower) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Mirror | Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Privacy Masking | 4 areas | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio Compression | G.711a; G.711Mu; PCM; G.726 (Only - ZAS supports) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Alarm | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Alarm Event | -ZAS:No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; intrusion; tripwire; scene changing; audio detection; voltage detection; defocus detection; external alarm; SMD; safety exception -ZS:No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; intrusion; tripwire; scene changing; voltage detection; defocus detection; SMD; safety exception | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Network | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Network Port | RJ-45 (10/100 Base-T) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
SDK and API | Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Cyber Security | Video encryption; firmware encryption; configuration encryption; digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Network Protocol | IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Interoperability | ONVIF (Profile S/Profile G/Profile T); CGI; P2P; Milestone; Genetec | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
User/Host | 20 (Total bandwidth: 64 M) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Storage | FTP; SFTP; Micro SD card (support max. 256 GB); NAS | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Browser | IE Chrome Firefox | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Management Software | Smart PSS; DSS; DMSS | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Mobile Client | iOS; Android | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Certification | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Certifications | CE-LVD: EN62368-1 CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU FCC: 47 CFR FCC Part 15, Subpart B | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Port | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio Input | 1 channel (RCA port) (Only - ZAS supports) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio Output | 1 channel (RCA port) (Only - ZAS supports) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Alarm Input | 1 channel in: 5 mA 3–5 VDC (Only - ZAS supports) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Alarm Output | 1 channel out: 300 mA 12 VDC (Only - ZAS supports) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power Supply | 12 VDC/PoE (802.3af) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power Consumption | Basic: 3.1 W (12 VDC); 4 W (PoE) Max(WDR + IR intensity + Intelligence on): 6.9 W (12 VDC); 8.1 W (PoE) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Environment | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Operating Temperature | –30 °C to +60 °C (–22 °F to +140 °F) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Operating Humidity | ?95% | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Storage Temperature | –40 °C to +60 °C (–40 °F to +140 °F) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Protection | IP67; IK10 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Structure | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Casing | Metal | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Product Dimensions | 88.9 mm × ?122 mm (3.50" × ?4.80") | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Net Weight | 492g (1.08 lb) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Gross Weight | 663g (1.46 lb) |
Quick Compare
Product |
IP camera Hikvision DS-2CD2T83G2-2I (2.8mm) | KAMERA IP PTZ HIKVISION DS-2DE2A204IW-DE3/W(S6)(C) | Hikvision Dome PTZ IR DS-2DE2A404IW-DE3(C0)(S6) | Dahua Technology WizSense IPC-HFW3549T1-AS-PV-0280B Bullet IP security camera Outdoor 2592 x 1944 pixels Ceiling/wall |
Availability |
|
|
|
|
Price |
€202.68
|
€202.74
|
€203.51
|
€204.88
|
Description |
||||
Type |
IP security camera | IP security camera | IP security camera | IP security camera |
Width |
94.4 mm | |||
Height |
101.7 mm | 101.7 mm | ||
Depth |
84.7 mm | |||
Connectivity technology |
Wired | Wired | Wired | Wired |
Weight |
1.09 kg | 530 g | 530 g | 1 kg |
Package depth |
156 mm | |||
Package height |
155 mm | |||
Package width |
386 mm | |||
Package weight |
1.59 kg | 1.23 kg | ||
Power source type |
DC, PoE | DC, PoE | DC, PoE | DC, PoE |
Storage relative humidity (H-H) |
0 - 95% | 0 - 95% | ||
Operating temperature (T-T) |
-30 - 60 °C | -20 - 60 °C | -20 - 60 °C | -40 - 60 °C |
Operating relative humidity (H-H) |
0 - 95% | 0 - 90% | 0 - 90% | 0 - 95% |
Storage temperature (T-T) |
-30 - 60 °C | -40 - 60 °C | ||
Mounting type |
Ceiling/wall | Ceiling | Ceiling | Ceiling/wall |
Form factor |
Bullet | Dome | Dome | Bullet |
Built-in microphone |
Yes | Yes | ||
Bluetooth |
No | No | No | No |
Bit rate |
32 Kbps - 16 Mbps | 32 - 8192 Kbps, 12 - 8192 Kbps | ||
Noise reduction |
Yes | Yes | Yes | Yes |
Microphone in |
Yes | |||
Protection features |
Dust resistant | |||
Length |
293 mm | 288.4 mm | ||
Sensor type |
CMOS | CMOS | CMOS | CMOS |
Wi-Fi |
No | Yes | No | No |
Internal memory |
512 MB | |||
Compatible memory cards |
MicroSD (TransFlash) | MicroSD (TransFlash) | MicroSDXC | |
Wi-Fi standards |
802.11g | |||
Maximum memory card size |
256 GB | 256 GB | 256 GB | |
Audio formats supported |
G.711 A-law | |||
Signal-to-Noise Ratio (SNR) |
52 dB | 52 dB | ||
Power consumption |
60 mA | |||
Power consumption (max) |
8 W | 11.2 W | 9.2 W | 2 W |
Maximum resolution |
3840 x 2160 pixels | 1920 x 1080 pixels | 2560 x 1440 pixels | 2592 x 1944 pixels |
Placement supported |
Outdoor | Indoor & outdoor | Indoor & outdoor | Outdoor |
Card reader integrated |
Yes | Yes | Yes | |
Ethernet LAN (RJ-45) ports |
1 | 1 | 1 | 1 |
Number of languages |
33 | |||
Audio output channels |
1 channels | 1 channels | 1 channels | |
Housing material |
Aluminium | Metal | ||
Networking standards |
IEEE 802.3af | IEEE 802.1x | IEEE 802.1x | |
Security algorithms |
HTTPS | HTTPS | EAP-TLS | |
Ethernet LAN |
Yes | Yes | Yes | Yes |
Focus |
Manual | |||
Supported graphics resolutions |
640 x 480 (VGA) | 1280 x 720 (HD 720) | 1280 x 720 (HD 720) | 1280 x 720 (HD 720) |
Zoom capability |
Yes | |||
Diameter |
10.5 cm | 13.1 cm | 13.1 cm | |
International Protection (IP) code |
IP67 | IP66 | IP65 | IP67 |
Digital zoom |
16x | 16x | ||
Wi-Fi data rate (max) |
54 Mbit/s | |||
Auto focus |
Yes | |||
Ethernet interface type |
Fast Ethernet | Fast Ethernet | Fast Ethernet | |
Optical Zoom |
4x | 4x | ||
Number of Users |
32 user(s) | 32 user(s) | 32 user(s) | 20 user(s) |
Web-based management |
Yes | Yes | ||
Quality of Service (QoS) support |
Yes | Yes | Yes | |
Reset button |
Yes | Yes | ||
Password protection |
Yes | Yes | Yes | |
Languages support |
Danish | |||
Frame Rate |
30 fps | 30 fps | 30 fps | |
Product colour |
White | Black | Black | White |
Tilt angle range |
0 - 90° | 0 - 90° | 0 - 90° | 0 - 90° |
Focal length range |
2.8 - 12 mm | 2.8 - 12 mm | ||
Fixed focal length |
2.8 mm | 2.8 mm | 2.8 mm | |
Web browser |
Yes | Yes | ||
Voice codecs |
G.726 | PCM | ||
LED type |
IR | IR | IR | IR |
Night vision |
Yes | Yes | Yes | Yes |
Total megapixels |
8 MP | 2 MP | 4 MP | 5 MP |
PTZ control |
Yes | |||
Optical sensor size |
25.4 / 2.8 mm (1 / 2.8") | 25.4 / 2.8 mm (1 / 2.8") | 25.4 / 2.8 mm (1 / 2.8") | 25.4 / 2.7 mm (1 / 2.7") |
White balance |
Natural | |||
Minimum illumination |
0.005 lx | 0.003 lx | ||
Pan range |
0 - 360° | 0 - 355° | 0 - 355° | 0 - 360° |
Dynamic range |
120 dB | 120 dB | ||
Lens viewing angle, diagonal |
128° | 129° | ||
Video compression formats |
H.264 | M-JPEG | H.265 | H.264+ |
Angle of rotation |
360° | 360° | ||
DC output voltage |
12 | 12 | 12 | 12 |
Video motion detection |
Yes | Yes | Yes | Yes |
Number of cameras |
1 | 1 | 1 | 1 |
Camera pan control |
Yes | Yes | Yes | |
Camera tilt control |
Yes | Yes | Yes | |
Night vision distance |
60 m | 20 m | 20 m | 40 m |
Number of lenses |
1 | 1 | 1 | |
Day/night mode |
Yes | Yes | Yes | Yes |
Infrared (IR) cut-off filter |
Yes | Yes | ||
Built-in HDD |
No | No | No | No |
Lens viewing angle, vertical |
57° | 71° | ||
Noise reduction technology |
3D noise reduction | 3D noise reduction | 3D noise reduction | 3D noise reduction |
Region of Interest (ROI) encoding |
Yes | Yes | Yes | Yes |
Maximum aperture number |
1.6 | 1.5 | 1.5 | 1 |
Channel bandwidth |
40 MHz | |||
Lens viewing angle, horizontal |
107° | 98° | ||
Number of sensors |
1 | 1 | 1 | 1 |
Infra-red wavelength |
850 nm | 850 nm | 850 nm | |
Alert notification type |
||||
Wide Dynamic Range (WDR) |
Yes | Yes | Yes | Yes |
Progressive scan |
Yes | Yes | Yes | |
Mirror |
Yes | Yes | Yes | Yes |
Heartbeat |
Yes | |||
Anti-flicker |
Yes | |||
Digital watermark |
Yes | |||
Back Light Compensation (BLC) |
Yes | Yes | Yes | Yes |
Video streaming |
Yes | Yes | Yes | |
Active tampering alarm |
Yes | Yes | ||
Alarm input/output |
Yes | |||
IP address filtering |
Yes | Yes | ||
Intelligent Video Surveillance (IVS) system features |
Face detection | Face detection | Face detection | Intrusion |
ROM capacity |
128 MB | |||
Camera shutter speed |
1/3 - 1/100000 s | 1/1 - 1/30000 s | 1/1 - 1/30000 s | 1/3 - 1/100000 s |
Bit rate control |
Constant Bit Rate (CBR)/Variable Bit Rate (VBR) | Constant Bit Rate (CBR)/Variable Bit Rate (VBR) | ||
Gain control type |
Auto | Auto/Manual | ||
Privacy masking |
Yes | Yes | Yes | Yes |
Highlight Compensation (HLC) |
Yes | Yes | Yes | Yes |
Live view |
Yes | Yes | ||
Power consumption (Power over Ethernet (PoE)) |
9 W | 2.6 W | ||
HTTPS encryption |
Yes | Yes | ||
Behavior analysis |
Intrusion detection, Line crossing detection | |||
Image quality adjustment |
Saturation | Contrast | Sharpness | |
IK code |
IK10 | IK10 | ||
Number of simultaneous live view channels |
6 channels | |||
User access level |
Administrator, Operator, User | Administrator, Operator, User | ||
Identify distance (wide) |
9 m | |||
Recognize distance (wide) |
17 m | |||
Pan speed |
100 °/sec | 100 °/sec | ||
Audio input channels |
1 channels | 1 channels | 1 channels | |
Closest focusing distance |
1.2 m | |||
Detect distance |
67.4 m | |||
Observe distance |
27 m | |||
Recognize distance |
13.5 m | |||
Identify distance |
6.7 m | |||
Identify distance (tele) |
18 m | |||
Tilt speed |
100 °/sec | 100 °/sec | ||
Pan preset speed |
100 °/sec | 100 °/sec | ||
Tilt preset speed |
100 °/sec | 100 °/sec | ||
Preset programs quantity |
300 | |||
