Product Details
Data sheet
- Type
- IP security camera
- Width
- 122 mm
- Height
- 94 mm
- Depth
- 122 mm
- Connectivity technology
- Wired
- Weight
- 712.9 g
- Package weight
- 986 g
- Power source type
- DC, PoE
- Operating temperature (T-T)
- -30 - 60 °C
- Operating relative humidity (H-H)
- 0 - 95%
- Mounting type
- Ceiling/wall
- Form factor
- Dome
- Bluetooth
- No
- Bit rate
- 32 - 8192, 19 - 8192 Kbps
- Noise reduction
- Yes
- Mobile operating systems supported
- Android
- Sensor type
- CMOS
- Wi-Fi
- No
- Internal memory
- 512 MB
- Compatible memory cards
- MicroSD (TransFlash)
- Maximum memory card size
- 256 GB
- Audio formats supported
- AAC
- Power consumption (max)
- 6.1 W
- Maximum resolution
- 2688 x 1520 pixels
- Placement supported
- Outdoor
- Card reader integrated
- Yes
- Ethernet LAN (RJ-45) ports
- 1
- Audio output channels
- 1.0 channels
- Housing material
- Metal
- Networking standards
- IEEE 802.3af
- Ethernet LAN
- Yes
- Supported graphics resolutions
- 2560 x 1440
- Diameter
- 12.2 cm
- International Protection (IP) code
- IP67
- Ethernet interface type
- Fast Ethernet
- Number of Users
- 20 user(s)
- Web-based management
- Yes
- Frame Rate
- 30 fps
- Product colour
- White
- Tilt angle range
- 0 - 75°
- Fixed focal length
- 3.6 mm
- Web browser
- Yes
- Voice codecs
- G.711Mu
- LED type
- IR
- Night vision
- Yes
- Total megapixels
- 4 MP
- Optical sensor size
- 25.4 / 1.8 mm (1 / 1.8")
- Minimum illumination
- 0.002 lx
- Pan range
- 0 - 355°
- Video compression formats
- M-JPEG
- Angle of rotation
- 355°
- DC output voltage
- 12
- Video motion detection
- Yes
- Number of cameras
- 1
- Camera pan control
- Yes
- Camera tilt control
- Yes
- Night vision distance
- 50 m
- Number of lenses
- 1
- Day/night mode
- Yes
- Built-in HDD
- No
- Camera shutter type
- Electronic
- Lens viewing angle, vertical
- 48°
- Noise reduction technology
- 3D noise reduction
- Smart IR
- Yes
- Region of Interest (ROI) encoding
- Yes
- Maximum aperture number
- 1.6
- Lens viewing angle, horizontal
- 89°
- Number of sensors
- 1
- Wide Dynamic Range (WDR)
- Yes
- Progressive scan
- Yes
- Back Light Compensation (BLC)
- Yes
- Video streaming
- Yes
- Alarm input/output
- Yes
- Intelligent Video Surveillance (IVS) system features
- Scene change
- ROM capacity
- 128 MB
- Camera shutter speed
- 1/3 - 1/100000 s
- Adjustment shutter speed
- Auto/Manual
- Number of effective pixels (H x V)
- 2688 x 1520 pixels
- Bit rate control
- Constant Bit Rate (CBR), Variable Bit Rate (VBR)
- Gain control type
- Auto/Manual
- Privacy masking
- Yes
- Highlight Compensation (HLC)
- Yes
- Flip & mirror
- Yes
- Number of illumination LEDs
- 1
- Behavior analysis
- Intrusion detection, Line crossing detection
- IK code
- IK10
- Streaming method
- Unicast
- Audio input channels
- 1.0 channels
- Closest focusing distance
- 1.3 m
- Detect distance
- 50 m
- Observe distance
- 38.6 m
- Recognize distance
- 19.3 m
- Identify distance
- 9.7 m
