IP network camera 4MP 2K IPC- HDBW5442R-ASE

Features:

• 1/1.8” 4Megapixel progressive scan CMOS
• H.265 & H.264 triple-stream encoding
• 25/30 fps@2688 × 1520, 50/60 fps@1080 (1920 × 1080)
• WDR (140 dB), Day/Night (ICR), 3D DNR, AWB, AGC, BLC
• Multiple network monitoring: Web viewer, CMS (DSS/PSS) & DMSS
• 2.8 mm fixed lens
• 1/1 Alarm in/out, 1/1 audio in/out
• Max. IR LEDs Length 50 m
• Micro SD memory, IP67, IK10

Technical Specifications:

Camera
• Image Sensor 1/1.8” 4Megapixel progressive scan CMOS
• Effective Pixels 2688 (H) × 1520 (V)
• RAM/ROM 512 MB/128 MB
• Scanning System Progressive
• Electronic Shutter Speed Auto/Manual, 1/3 s–1/100000 s
• Minimum Illumination 0.001 Lux@F1.6
• IR Distance Distance up to 50 m (164 ft)
• IR On/Off Control Auto/Manual
• IR LEDs 1
Lens
• Lens Type Fixed
• Mount Type Board-in
• Focal Length 2.8 mm
• Max. Aperture F1.6
• Angle of View H: 113°, V: 60°/H: 89°
• Optical Zoom N/A
• Aperture Type Fixed
Pan/Tilt/Rotation
• Pan/Tilt/Rotation Range Pan: 0?–355?; Tilt: 0?–75?; Rotation: 0?–355?
Artificial Intelligence
• Face Capture Support face image capture
• Perimeter Protection Tripwire, Intrusion (Human & Vehicle classification)
People Counting
• Support Line crossing/Region/Queueing people counting; Support 4 accesses independent detection, 4 areas independent detection
General Intelligence
• Event Trigger
• Motion detection, Video tampering , Scene changing, Network disconnection , IP address conflict, Illegal Access,Storage anomaly
• General Intelligence: Object Abandoned/Missing
Video
• Compression H.265+, H.265, H.264+, H.264, H.264B, H.264H, MJPEG (sub stream)
• Streaming Capability 3 Streams
• Resolution: 2688 × 1520/2560 × 1440/2304 × 1296/1080P (1920 × 1080)/1.3M (1280 × 960)/720P (1280 ×720)/D1 (704 × 576/704 × 480)/VGA (640 × 480)/CIF (352 × 288/352 × 240)
• Frame Rate: Main Stream: 2688 × 1520 (1 fps–25/30 fps) 2560 × 1440 (1 fps–25/30 fps) 1920 × 1080 (1 fps–50/60 fps), Sub Stream: D1 (1 fps–25/30 fps)
D1 (1 fps–50/60 fps), Third Stream: 1080P (1 fps–16 fps)
• Bit Rate Control CBR/VBR
• Bit Rate H.264: 32 Kbps–8192 Kbps H.265: 19 Kbps–8192 Kbps
• Day/Night Auto(ICR)/Color/B/W
• BLC Mode BLC/HLC/WDR (140 dB)
• White Balance Auto/Natural/Street Lamp/Outdoor/Manual
• Gain Control Auto/Manual
• Noise Reduction 3D DNR
• Motion Detetion Off/On (4 Zone, Rectangle)
• Region of Interest Off/On (4 Zone)
• Electronic Image Stabilization (EIS) N/A
• Smart IR Support
• Defog Support
• Digital Zoom N/A
• Flip 0°/90°/180°/270°
• Mirror Off/On
• Privacy Masking Off/On (4 Area, Rectangle)

Audio
• Compression G.711a, G.711Mu, G.726, AAC, G.723
Network
• Ethernet RJ-45 (10/100 Base-T)
Protocol
• HTTP, TCP, ARP, RTSP, RTP, UDP, RTCP, SMTP, FTP, DHCP, DNS, DDNS, PPPoE, IPv4/v6, SNMP, QoS, UPnP, NTP, ICMP, HTTPS, IGMP, 802.1x
• Interoperability ONVIF (Profile S/Profile G), CGI, Milstone, Genetec, P2P
• Streaming Method Unicast/Multicast
• Max. User Access 20 Users
• Edge Storage: NAS, FTP, Micro SD card 256 GB
• Web Viewer IE (versions newer than IE8), Chrome, Firefox, Safari (versions newer than Safari 12)
• Management Software Smart PSS, DSS, P2P
• Smart Phone iOS, Android
Certifications
• CE-LVD: EN60950-1
• CE-EMC: Electromagnetic Compatibility Directive
• 2014/30/EU
• FCC: 47 CFR FCC Part 15, Subpart B
• UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07
Interface
• Video Interface N/A
• Audio Interface 1/1 channel In/Out
• RS485 N/A
• Alarm 1 channel In: 5mA 5V DC
• 1 channel Out: 300mA 12V DC
Electrical
• Power Supply DC 12V (±30%), PoE (802.3af) (Class 0)
• Power Consumption <6.1W
Environmental
• Operating Conditions -30° C to +60° C (-22° F to +140° F)/10%RH–95%RH
• Strorage Conditions -30° C to +60° C (-22° F to +140° F)
• Ingress Protection IP67
• Vandal Resistance IK10
Construction
• Casing Metal
• Dimensions ?122.0 mm × 88.9 mm (4.80” × 3.50”)
• Net Weight 0.47 kg (1.04 lb)
• Gross Weight 0.63 kg (1.39 lb)
