KAMERA IP HIKVISION DS-2CD1083G2-LIUF 2.8mm PL

Product Details

Reference CIPHIKKAM0801

In stock 21 Items

Data sheet

Type

IP security camera

Width

69.1 mm

Height

66 mm

Connectivity technology

Wired

Weight

285 g

Package depth

121 mm

Package height

118 mm

Package width

216 mm

Package weight

481 g

Power source type

DC, PoE

Storage relative humidity (H-H)

0 - 95%

Operating temperature (T-T)

-30 - 60 °C

Operating relative humidity (H-H)

0 - 95%

Storage temperature (T-T)

-30 - 60 °C

Mounting type

Ceiling/wall

Form factor

Bullet

Built-in microphone

Yes

Bluetooth

No

Bit rate

32 Kbps - 16 Mbps

Noise reduction

Yes

Protection features

Waterproof

Length

170.8 mm

Sensor type

CMOS

Wi-Fi

No

Compatible memory cards

MicroSDXC

Maximum memory card size

512 GB

Audio formats supported

AAC-LC

Signal-to-Noise Ratio (SNR)

52 dB

Power consumption (max)

5 W

Maximum resolution

3840 x 2160 pixels

Placement supported

Outdoor

Card reader integrated

Yes

Ethernet LAN (RJ-45) ports

1

Number of languages

2

Housing material

Metal

Ethernet LAN

Yes

Supported graphics resolutions

640 x 360

International Protection (IP) code

IP67

Number of Users

32 user(s)

Web-based management

Yes

Quality of Service (QoS) support

Yes

Supported network protocols

TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6, UDP, QoS, FTP, SMTP, UPnP

Reset button

Yes

Password protection

Yes

Languages support

Ukrainian

Frame Rate

15 fps

Product colour

White

Tilt angle range

0 - 90°

Fixed focal length

2.8 mm

Voice codecs

MP2L2

LED type

IR

Night vision

Yes

Total megapixels

8 MP

Optical sensor size

25.4 / 2.7 mm (1 / 2.7")

Minimum illumination

0 lx

Pan range

0 - 360°

Dynamic range

120 dB

Lens viewing angle, diagonal

134°

Video compression formats

H.264+

Angle of rotation

360°

DC output current

0.41 A

DC output voltage

12

Video motion detection

Yes

Number of cameras

1

Night vision distance

30 m

Number of lenses

1

Privacy protection

Yes

Day/night mode

Yes

Infrared (IR) cut-off filter

Yes

Built-in HDD

No

Lens viewing angle, vertical

62°

Noise reduction technology

3D noise reduction

Region of Interest (ROI) encoding

Yes

Maximum aperture number

2

Lens viewing angle, horizontal

113°

Number of sensors

1

Infra-red wavelength

850 nm

Wide Dynamic Range (WDR)

Yes

Progressive scan

Yes

Mirror

Yes

Heartbeat

Yes

Digital watermark

Yes

Back Light Compensation (BLC)

Yes

Active tampering alarm

Yes

Camera shutter speed

1/3 - 1/100000 s

Bit rate control

Constant Bit Rate (CBR)/Variable Bit Rate (VBR)

Privacy masking

Yes

Highlight Compensation (HLC)

Yes

Live view

Yes

Power consumption (Power over Ethernet (PoE))

6.5 W

Image quality adjustment

Saturation

Digest authentication

Yes

Password reset via email

Yes

Number of simultaneous live view channels

6 channels

User access level

Administrator, Operator, User

Built-in light

Yes

Detect distance

79 m

Observe distance

31 m

Recognize distance

15 m

Identify distance

7 m

B/W night vision distance

30 m

Client interoperability

iVMS-4200, Hik-Connect

Bit rate range

16 - 160 Kbit/s

Compliance certificates

REACH

Number of Privacy masking areas

4

Sample rates

8 - 16 kHz

Audit log

Yes
