KAMERA IP HIKVISION DS-2CD1343G2-LIU(2.8mm)

Product Details

Reference WLONONWCR5427

In stock 200 Items

Data sheet

Type

IP security camera

Height

89.2 mm

Connectivity technology

Wired

Weight

340 g

Package depth

150 mm

Package height

141 mm

Package width

150 mm

Package weight

560 g

Power source type

DC, PoE

Storage relative humidity (H-H)

0 - 95%

Operating temperature (T-T)

-30 - 60 °C

Operating relative humidity (H-H)

0 - 95%

Storage temperature (T-T)

-30 - 60 °C

Mounting type

Ceiling/wall

Form factor

Turret

Built-in microphone

Yes

Bluetooth

No

Bit rate

32 Kbps - 8 Mbps

Noise reduction

Yes

Sensor type

CMOS

Wi-Fi

No

Power consumption (max)

5 W

Maximum resolution

2560 x 1440 pixels

Viewing angle, horizontal

98°

Viewing angle, vertical

54°

Placement supported

Outdoor

Ethernet LAN (RJ-45) ports

1

Housing material

Plastic

Networking standards

IEEE 802.3af

Ethernet LAN

Yes

Supported graphics resolutions

1920 x 1080 (HD 1080)

Diameter

11 cm

International Protection (IP) code

IP67

Number of Users

32 user(s)

Web-based management

Yes

Quality of Service (QoS) support

Yes

Password protection

Yes

Frame Rate

20 fps

Product colour

White

Tilt angle range

0 - 75°

Fixed focal length

2.8 mm

LED type

IR

Night vision

Yes

Total megapixels

4 MP

Optical sensor size

25.4 / 3 mm (1 / 3")

Pan range

0 - 360°

Video compression formats

H.264+

Angle of rotation

360°

DC output current

0.4 A

DC output voltage

12

Video motion detection

Yes

Number of cameras

1

Camera pan control

Yes

Camera tilt control

Yes

Night vision distance

30 m

Number of lenses

1

Day/night mode

Yes

Infrared (IR) cut-off filter

Yes

Built-in HDD

No

Noise reduction technology

3D noise reduction

Region of Interest (ROI) encoding

Yes

Maximum aperture number

1.6

Number of sensors

1

Infra-red wavelength

850 nm

Wide Dynamic Range (WDR)

Yes

Viewing angle, diagonal

114°

Progressive scan

Yes

Mirror

Yes

Heartbeat

Yes

Digital watermark

Yes

Video streaming

Yes

Camera shutter speed

1/3 - 1/100000 s

Gain control type

Auto

Privacy masking

Yes

Dedicated application

Hik-Connect (Android, iOS)

Power consumption (Power over Ethernet (PoE))

6.5 W

Image quality adjustment

Sharpness
