IP camera Hikvision DS-2CD1043G2-LIU(2.8mm)

Product Details

Reference WLONONWCR5428

In stock 200 Items

Data sheet

Type

IP security camera

Width

69.1 mm

Height

66 mm

Connectivity technology

Wired

Weight

270 g

Package depth

121 mm

Package height

118 mm

Package width

216 mm

Package weight

481 g

Power source type

DC, PoE

Storage relative humidity (H-H)

0 - 95%

Operating temperature (T-T)

-30 - 60 °C

Operating relative humidity (H-H)

0 - 95%

Storage temperature (T-T)

-30 - 60 °C

Mounting type

Ceiling/wall

Form factor

Bullet

Bluetooth

No

Bit rate

32 Kbps - 8 Mbps

Protection features

Dust resistant

Sensor type

CMOS

Wi-Fi

No

Power consumption (max)

5 W

Maximum resolution

2560 x 1440 pixels

Placement supported

Indoor & outdoor

Ethernet LAN (RJ-45) ports

1

Number of languages

2

Housing material

Plastic

Ethernet LAN

Yes

Supported graphics resolutions

1280 x 720 (HD 720)

International Protection (IP) code

IP67

Ethernet interface type

Fast Ethernet

Number of Users

32 user(s)

Web-based management

Yes

Quality of Service (QoS) support

Yes

Password protection

Yes

Languages support

Ukrainian

Frame Rate

25 fps

Product colour

White

Tilt angle range

0 - 90°

Sustainability certificates

Federal Communications Commission (FCC)

Fixed focal length

2.8 mm

LED type

IR

Night vision

Yes

Total megapixels

4 MP

Optical sensor size

25.4 / 3 mm (1 / 3")

Pan range

0 - 360°

Dynamic range

120 dB

Lens viewing angle, diagonal

114°

Video compression formats

H.264

Angle of rotation

360°

DC output current

0.4 A

DC output voltage

12

Video motion detection

Yes

Number of cameras

1

Night vision distance

30 m

Number of lenses

1

Privacy protection

Yes

Day/night mode

Yes

Built-in HDD

No

Lens viewing angle, vertical

54°

Noise reduction technology

3D noise reduction

Region of Interest (ROI) encoding

Yes

Maximum aperture number

1.6

Lens viewing angle, horizontal

98°

Number of sensors

1

Infra-red wavelength

850 nm

Wide Dynamic Range (WDR)

Yes

Progressive scan

Yes

Mirror

Yes

Heartbeat

Yes

Digital watermark

Yes

Back Light Compensation (BLC)

Yes

Video streaming

Yes

Active tampering alarm

Yes

Camera shutter speed

1/3 - 1/100000 s

Bit rate control

Constant Bit Rate (CBR)/Variable Bit Rate (VBR)

Privacy masking

Yes

Highlight Compensation (HLC)

Yes

Live view

Yes

Power consumption (Power over Ethernet (PoE))

6.5 W

Image quality adjustment

Saturation

Lens mount interface

M12

Digest authentication

Yes

Password reset via email

Yes

Number of simultaneous live view channels

6 channels

User access level

Administrator, Operator, User

Detect distance

63 m

Observe distance

25 m

Recognize distance

12 m

Identify distance

6 m

Number of Privacy masking areas

4
