Camera | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Image Sensor | 1/2.9" CMOS | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Max. Resolution | 2688 (H) × 1520 (V) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
ROM | 128 MB | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
RAM | 512 MB | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Scanning System | Progressive | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Electronic Shutter Speed | Auto/Manual 1/3 s–1/100,000 s | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Min. Illumination | 0.005 lux@F1.4 (Color, 30 IRE) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
S/N Ratio | >56 dB | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Illumination Distance | 50 m (164.04 ft) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Illuminator On/Off Control | Auto/Manual | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Illuminator Number | 3 (IR LED) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Pan/Tilt/Rotation Range | Pan: 0°–355°; Tilt: 0°–75°; Rotation: 0°–355° | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Lens | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Lens Type | Fixed-focal | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Lens Mount | M12 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Focal Length | 2.8 mm | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Max. Aperture | F1.4 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Field of View | 2.8 mm: Horizontal:107°; vertical: 56°; diagonal: 127° | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Iris Control | Fixed | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Close Focus Distance | 2.8 mm: 0.7 m (2.30 ft) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
DORI Distance | Lens | Detect | Observe | Recognize | Identify | ||||||||||||||||||||||||||||||||||||||||||||||||||||||
2.8 mm | 63.6 m | 25.4 m | 12.7 m | 6.4 m | |||||||||||||||||||||||||||||||||||||||||||||||||||||||
| | | | | |||||||||||||||||||||||||||||||||||||||||||||||||||||||
| | | | | |||||||||||||||||||||||||||||||||||||||||||||||||||||||
Intelligence | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
IVS (Perimeter Protection) | Tripwire, intrusion (support the classification and accurate detection of vehicle and human) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
AI SSA | Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Quick Pick | With AI NVR, quickly pick up the human/vehicle targets that users are interested in from SMD events | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Smart Search | Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Video | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Video Compression | H.265; H.264; H.264H; H.264B; MJPEG (only supported by the sub stream) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Smart Codec | Smart H.265+ | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
AI Coding | AI H.265 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Video Frame Rate | Main stream: 2688 × 1520 @ (1–25/30) fps *The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Stream Capability | 3 streams | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Resolution | 4M (2688 × 1520); 3.6M (2560 × 1440); 3M (2048 × 1536); 3M (2304×1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); CIF (352 × 288/352 × 240); VGA (640 × 480) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Bit Rate Control | CBR/VBR | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Video Bit Rate | H.264: 3 kbps–8192 kbps | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Day/Night | Auto (ICR)/Color/B/W | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
BLC | Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
HLC | Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
WDR | 120 dB | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Scene Self-adaptation (SSA) | Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
White Balance | Auto; natural; street lamp; outdoor; manual; regional custom | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Gain Control | Auto | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Noise Reduction | 3D NR | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Motion Detection | OFF/ON (4 areas, rectangular) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Region of Interest (RoI) | Yes (4 areas) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Defog | Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
AFSA | Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Image Rotation | 0°/90°/180°/270° (support 90°/270° with 2688×1520 resolution and lower) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Mirror | Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Privacy Masking | 4 areas | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Built-in MIC | Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio Compression | G.711a; G.711Mu; PCM; G.726; G.723 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Alarm | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Alarm Event | - AS: No SD card; SD card full; SD card error; service life warning (only supported by Dahua card); network disconnection; IP conflict; illegal access; motion detection; video tampering; intrusion; tripwire; scene changing; audio detection; voltage detection; external alarm; SMD; safety exception -S: No SD card; SD card full; SD card error; service life warning (only supported by Dahua card); network disconnection; IP conflict; illegal access; motion detection; video tampering; intrusion; tripwire; scene changing; audio detection; voltage detection; SMD; safety exception | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Network | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Network Port | RJ-45 (10/100 Base-T) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
SDK and API | Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Network Protocol | IPv4; IPv6; HTTP;TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Cyber Security | Video encryption; Firmware encryption; Configuration encryption; Digest; WSSE; Account lockout; Security logs; IP/MAC filtering; Generation and importing of X.509 certification; syslog; HTTPS; 802.1x; Trusted boot; Trusted execution; Trusted upgrade | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Interoperability | ONVIF (Profile S/Profile G/Profile T); CGI; P2P; Milestone; Genetec | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
User/Host | 20 (Total bandwidth: 64 M) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Storage | FTP; SFTP; Micro SD card (support max. 256 G); NAS | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Browser | IE:IE11 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Management Software | Smart PSS; DSS; DMSS | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Mobile Client | IOS; Android | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Certification | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Certifications | CE-LVD:EN62368-1; | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Port | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio Input |
| ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio Output |
| ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Alarm Input |
| ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Alarm Output |
| ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power Supply | 12 VDC/PoE (802.3af) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power Consumption | Basic: 2.8 W (12 VDC); 3.5 W (PoE) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Environment | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Operating Temperature | –40 °C to +60 °C (–40 °F to 140 °F) /Less than 95% RH | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Storage Temperature | –40 °C to +60 °C (–40 °F to 140 °F) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Protection | IP67; IK10 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Structure | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Casing | Metal | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Product Dimensions | 89.1 mm × ?111.7 mm (3.51" × ?4.40") | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Net Weight | 516 g (1.14 lb) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Gross Weight | 670 g (1.48 lb) |
Quick Compare
Product |
![]() |
![]() |
![]() |
![]() |
Availability |
|
|
|
|
Price |
€130.56
|
€130.75
|
€130.99
|
€131.20
|
Description |
||||
Type |
IP security camera | IP security camera | IP security camera | IP security camera |
Width |
106 mm | 145 mm | ||
Height |
93.6 mm | 142 mm | ||
Depth |
116 mm | |||
Connectivity technology |
Wired | Wired | Wired & Wireless | Wired |
Weight |
500 g | 490 g | 668 g | 490 g |
Package depth |
121 mm | 150 mm | 121 mm | |
Package height |
118 mm | 194 mm | 118 mm | |
Package width |
216 mm | 150 mm | 216 mm | |
Package weight |
960 g | 724 g | ||
Power source type |
DC, PoE | DC, PoE | DC | DC, PoE |
Storage relative humidity (H-H) |
0 - 95% | 0 - 95% | ||
Operating temperature (T-T) |
-40 - 60 °C | -30 - 60 °C | -30 - 50 °C | -30 - 60 °C |
Operating relative humidity (H-H) |
0 - 95% | 0 - 95% | 0 - 95% | 0 - 95% |
Storage temperature (T-T) |
-40 - 60 °C | -30 - 60 °C | -30 - 60 °C | |
Mounting type |
Wall/ceiling | Ceiling/wall | Ceiling/Wall/Pole | Ceiling/wall |
Form factor |
Tube/dome | Bullet | Dome | Bullet |
Built-in microphone |
Yes | |||
Bluetooth |
No | No | No | |
Bit rate |
32 Kbps - 16 Mbps | 32 Kbps - 8 Mbps | ||
Noise reduction |
Yes | Yes | Yes | |
Mobile operating systems supported |
iOS | |||
Length |
16.2 cm | 16.2 cm | ||
Sensor type |
HD CMOS | CMOS | CMOS | CMOS |
Wi-Fi |
No | No | Yes | No |
Compatible memory cards |
MicroSDXC | MicroSD (TransFlash) | MicroSDXC | |
Wi-Fi standards |
Wi-Fi 4 (802.11n) | |||
Maximum memory card size |
256 GB | 512 GB | 256 GB | |
Audio system |
2-way | |||
Signal-to-Noise Ratio (SNR) |
56 dB | |||
Power consumption (max) |
8.9 W | 6 W | 12 W | 6 W |
Power consumption (typical) |
4.3 W | |||
Maximum resolution |
2960 x 1668 px | 2880 x 1620 pixels | 2688 x 1520 pixels | |
Built-in speaker(s) |
Yes | |||
Placement supported |
Outdoor | Outdoor | Outdoor | Outdoor |
Card reader integrated |
Yes | Yes | Yes | |
Ethernet LAN (RJ-45) ports |
1 | 1 | 1 | |
Number of languages |
33 | 33 | ||
Housing material |
Metal | |||
Networking standards |
IEEE 802.3af | IEEE 802.3af | IEEE 802.1x | |
Security algorithms |
WPA-PSK | |||
Ethernet LAN |
Yes | Yes | Yes | |
Lens type |
Fixed focal length lens | |||
Supported graphics resolutions |
2688 x 1520 | 640 x 360 | ||
Zoom capability |
Yes | |||
Diameter |
7 cm | 7 cm | ||
International Protection (IP) code |
IP67 | IP67 | IP67 | |
Ethernet interface type |
10 Megabit Ethernet | Fast Ethernet | Fast Ethernet | Fast Ethernet |
Motion Detection |
Yes | |||
Number of Users |
32 user(s) | 32 user(s) | ||
Web-based management |
Yes | Yes | Yes | |
Quality of Service (QoS) support |
Yes | Yes | ||
Reset button |
Yes | Yes | ||
Password protection |
Yes | Yes | Yes | |
Languages support |
French | |||
Frame Rate |
25 / 30 fps | 30 fps | ||
Mounting kit |
Yes | |||
Product colour |
White | White | White | White |
Tilt angle range |
0 - 90° | 0 - 90° | ||
Sustainability certificates |
CE | RoHS | ||
Focal length range |
2.8 mm | |||
Fixed focal length |
2.8 mm | 2.8 mm | ||
Web browser |
Yes | Yes | ||
Virtual assistant |
Amazon Alexa & Google Assistant | |||
RAM capacity |
512 MB | |||
Screws included |
Yes | |||
LED type |
IR / White light LED | IR | IR | |
Night vision |
Yes | Yes | Yes | Yes |
Total megapixels |
5 MP | 6 MP | 4 MP | |
4G LTE |
No | |||
PTZ control |
Yes | |||
Optical sensor size |
25.4 / 2.7 mm (1 / 2.7") | 25.4 / 2.4 mm (1 / 2.4") | 25.4 / 2.7 mm (1 / 2.7") | 25.4 / 3 mm (1 / 3") |
Minimum illumination |
0.0005 lx | 0.5 lx | ||
Pan range |
0 - 360° | 0 - 360° | ||
Lens viewing angle, diagonal |
122° | |||
Video compression formats |
H.264H | H.265+ | H.264 | H.264+ |
Angle of rotation |
360° | 360° | ||
DC output current |
0.5 A | 1.5 A | 0.5 A | |
DC output voltage |
12 | 12 | 12 | 12 |
Video motion detection |
Yes | Yes | Yes | |
Number of cameras |
1 | 1 | 1 | 1 |
Camera pan control |
Yes | Yes | ||
Camera tilt control |
Yes | Yes | ||
Night vision distance |
50 m | 40 m | 40 m | |
Number of lenses |
1 | 1 | 2 | 1 |
Day/night mode |
Yes | Yes | ||
Infrared (IR) cut-off filter |
Yes | Yes | Yes | |
Remote viewing |
Yes | |||
Auto patrol mode |
Yes | |||
Auto-tracking |
Yes | |||
Built-in HDD |
No | No | ||
Lens viewing angle, vertical |
71° | 53.4° | 55° | |
Noise reduction technology |
3D noise reduction | 3D noise reduction | 3D noise reduction | |
Region of Interest (ROI) encoding |
Yes | Yes | ||
Maximum aperture number |
1.4 | 1.6 | 1.6 | |
Lens viewing angle, horizontal |
97° | 103° | ||
Number of sensors |
1 | 1 | 1 | |
Infra-red wavelength |
850 nm | 850 nm | ||
Built-in siren |
Yes | |||
Wide Dynamic Range (WDR) |
120 dB | Yes | Yes | Yes |
Viewing angle, diagonal |
129° | |||
Progressive scan |
Yes | Yes | Yes | Yes |
Mirror |
Yes | Yes | ||
Heartbeat |
Yes | Yes | Yes | |
Anti-flicker |
Yes | Yes | Yes | |
Digital watermark |
Yes | |||
Back Light Compensation (BLC) |
Yes | Yes | ||
Video streaming |
Yes | Yes | Yes | |
Weatherproof |
Yes | |||
IP address filtering |
Yes | Yes | ||
Intelligent Video Surveillance (IVS) system features |
Scene change | Human detection | ||
ROM capacity |
128 MB | |||
Camera shutter speed |
1/3 - 1/100000 s | 1/3 - 1/100000 s | 1/3 - 1/100000 s | |
Adjustment shutter speed |
Auto/Manual | |||
Bit rate control |
Constant Bit Rate (CBR)/Variable Bit Rate (VBR) | |||
Privacy masking |
Yes | Yes | ||
Highlight Compensation (HLC) |
Yes | Yes | ||
Number of illumination LEDs |
1 / 1 | |||
Motion detection |
Yes | |||
People detection |
Yes | |||
Two-way talk |
N | |||
People detection |
Yes | |||
Power consumption (Power over Ethernet (PoE)) |
4.9 W | 7.2 W | 7 W | |
HTTPS encryption |
Yes | Yes | ||
Behavior analysis |
Intrusion detection, Line crossing detection, Region entrance detection, Region exiting detection | Intrusion detection, Line crossing detection | ||
Image quality adjustment |
Contrast | Saturation | ||
Built-in loudspeaker |
No | |||
Horizontal rotation angle |
0 - 360° | |||
Vertical rotation angle |
0 - 78° | |||
Built-in light |
Yes | |||
Drilling template included |
Yes | |||
Colour night vision distance |
40 m | |||
Audio codecs |
G.711a / G.711Mu / G.723 / G.726 / PCM | |||
Warnings |
The product contains electronic components; do not dispose of with the normal household waste. | |||
