Product Details
Data sheet
- Mac operating systems supported
- Yes
- Type
- IP security camera
- Windows operating systems supported
- Yes
- Height
- 103.8 mm
- Connectivity technology
- Wired
- Weight
- 526 g
- Package depth
- 262 mm
- Package height
- 145 mm
- Package width
- 159 mm
- Package weight
- 1.13 kg
- Power source type
- DC, PoE
- Cables included
- LAN (RJ-45)
- Operating temperature (T-T)
- -10 - 55 °C
- Operating relative humidity (H-H)
- 10 - 90%
- Mounting type
- Ceiling
- Form factor
- Dome
- Built-in microphone
- Yes
- LED indicators
- Yes
- Bluetooth
- No
- Mobile operating systems supported
- iOS
- Sensor type
- CMOS
- Wi-Fi
- No
- Compatible memory cards
- MicroSD (TransFlash)
- Maximum memory card size
- 256 GB
- Audio system
- 2-way
- Power consumption (max)
- 12 W
- Maximum resolution
- 3840 x 2160 pixels
- Built-in speaker(s)
- Yes
- Placement supported
- Indoor & outdoor
- Card reader integrated
- Yes
- Ethernet LAN (RJ-45) ports
- 1
- DC-in jack
- Yes
- Networking standards
- IEEE 802.3af
- Ethernet LAN
- Yes
- Diameter
- 11.7 cm
- International Protection (IP) code
- IP66
- Ethernet interface type
- Fast Ethernet
- Number of Users
- 20 user(s)
- Supported network protocols
- HTTPS, SSL, TCP/IP, UDP, HTTP, IPv4, UPnP, RTSP, RTMP, ONVIF, SMTP, NTP, DHCP, DNS, DDNS, FTP, P2P
- Reset button
- Yes
- Frame Rate
- 25 fps
- Mounting kit
- Yes
- Product colour
- White
- Fixed focal length
- 2.8 mm
- Virtual assistant
- Google Assistant
- Screws included
- Yes
- LED type
- IR
- Night vision
- Yes
- Total megapixels
- 8 MP
- Optical sensor size
- 25.4 / 2.49 mm (1 / 2.49")
- Video compression formats
- H.265
- DC output current
- 1 A
- DC output voltage
- 12, 48
- Number of cameras
- 1
- Night vision distance
- 30 m
- Built-in HDD
- No
- Lens viewing angle, vertical
- 56°
- Maximum aperture number
- 1.6
- Lens viewing angle, horizontal
- 105°
- Number of sensors
- 1
- Infra-red wavelength
- 850 nm
- Number of illumination LEDs
- 2
- User access level
- Administrator, User
- Bit rate range
- 64 - 8192 Kbit/s
