Product Details
Data sheet
- Type
- IP security camera
- Height
- 111.6 mm
- Connectivity technology
- Wired
- Weight
- 890 g
- Package weight
- 1.3 kg
- Power source type
- DC, PoE
- Operating temperature (T-T)
- -30 - 60 °C
- Operating relative humidity (H-H)
- 0 - 95%
- Interface
- RJ-45
- Mounting type
- Ceiling
- Form factor
- Dome
- Noise reduction
- Yes
- Sensor type
- CMOS
- Compatible memory cards
- MicroSDXC
- Maximum memory card size
- 128 GB
- Audio formats supported
- G.711
- Power consumption (max)
- 11 W
- Maximum resolution
- 1920 x 1080 pixels
- Placement supported
- Indoor & outdoor
- Card reader integrated
- Yes
- Ethernet LAN (RJ-45) ports
- 1
- FULL HD
- YES
- Audio output channels
- 1.0 channels
- Cabling technology
- 10/100Base-T(X)
- Housing material
- Metal
- Networking standards
- IEEE 802.1x
- Ethernet LAN
- Yes
- Focus
- Motorized
- Diameter
- 15.3 cm
- International Protection (IP) code
- IP67
- Ethernet interface type
- Fast Ethernet
- Analog signal format system
- PAL
- Power Over Ethernet (PoE)
- Yes
- Number of Users
- 32 user(s)
- Quality of Service (QoS) support
- Yes
- Reset button
- Yes
- Password protection
- Yes
- Frame Rate
- 30 fps
- Product colour
- White
- Tilt angle range
- 0 - 75°
- Focal length range
- 2.8 - 12 mm
- Web browser
- Yes
- LED type
- IR
- Night vision
- Yes
- Total megapixels
- 2 MP
- Optical sensor size
- 25.4 / 2.8 mm (1 / 2.8")
- Minimum illumination
- 0 lx
- Pan range
- 0 - 355°
- Video compression formats
- M-JPEG
- Angle of rotation
- 355°
- DC output current
- 0.9 A
- DC output voltage
- 12
- Number of cameras
- 1
- Night vision distance
- 50 m
- Day/night mode
- Yes
- Infrared (IR) cut-off filter
- Yes
- Region of Interest (ROI) encoding
- Yes
- Maximum aperture number
- 1.4
- Infra-red wavelength
- 850 nm
- Wide Dynamic Range (WDR)
- Yes
- Progressive scan
- Yes
- Mirror
- Yes
- Heartbeat
- Yes
- Anti-flicker
- Yes
- Digital watermark
- Yes
- Back Light Compensation (BLC)
- Yes
- Weatherproof
- Yes
- Active tampering alarm
- Yes
- Alarm input/output
- Yes
- IP address filtering
- Yes
- Camera shutter speed
- 1/3 - 100000 s
- Privacy masking
- Yes
- Power consumption (Power over Ethernet (PoE))
- 12.9 W
- Behavior analysis
- Intrusion detection, Line crossing detection
- Image quality adjustment
- Saturation
- IK code
- IK10
- Audio input channels
- 1.0 channels
- 3D NR (Noise Reduction)
- Yes
- Warnings
- The product contains electronic components; do not dispose of with the normal household waste.
Quick Compare
Product |
Camera BCS LINE BCS-L-PTHOME07
|
|
Hikvision DS-2CD1027G0-L Bullet IP Security Camera Outdoor 1920 x 1080 px Ceiling / Wall
|
IMOU Cruiser Dual 6MP IPC-S7XP-6M0WED Camera
|
Availability |
|
|
|
|
Price |
€61.48
|
€61.54
|
€61.79
|
€61.83
|
Description |
||||
Type |
IP security camera | IP security camera | IP security camera | |
Width |
68.4 mm | 158.7 mm | ||
Height |
84 mm | 201.9 mm | ||
Depth |
65.2 mm | 125 mm | ||
Connectivity technology |
Wired | Wired | Wired & Wireless | |
Weight |
420 g | 642 g | ||
Package depth |
163 mm | 104 mm | ||
Package height |
116 mm | 80 mm | ||
Package width |
163 mm | 172 mm | ||
Package weight |
400 g | 510 g | ||
Power source type |
DC, PoE | DC, PoE | DC | |
Cables included |
USB | |||
Storage relative humidity (H-H) |
0 - 95% | |||
Manual |
Yes | |||
Operating temperature (T-T) |
-30 - 60 °C | -30 - 60 °C | -20 - 50 °C | |
Operating relative humidity (H-H) |
0 - 95% | 0 - 95% | ||
Storage temperature (T-T) |
-30 - 60 °C | |||
Mounting type |
Ceiling | Ceiling/wall | Desk | |
Form factor |
Turret | Bullet | Turret | |
Built-in microphone |
Yes | Yes | ||
Bluetooth |
No | No | No | |
Bit rate |
64 Kbps - 4 Mbps | 32 Kbps - 8 Mbps | ||
Noise reduction |
Yes | Yes | ||
Mobile operating systems supported |
Android | |||
Protection features |
Water resistant | |||
Sensor type |
CMOS | CMOS | CMOS | |
Wi-Fi |
No | No | Yes | |
Compatible memory cards |
MicroSD (TransFlash) | MicroSD (TransFlash) | ||
Wi-Fi standards |
Wi-Fi 6 (802.11ax) | |||
Maximum memory card size |
256 GB | |||
Audio system |
2-way | 2-way | ||
Power consumption (max) |
5.5 W | 3.6 W | 12 W | |
Maximum resolution |
2560 x 1440 pixels | 1920 x 1080 pixels | 2304 x 1296 pixels | |
Built-in speaker(s) |
Yes | Yes | ||
Placement supported |
Indoor & outdoor | Outdoor | Outdoor | |
Card reader integrated |
Yes | Yes | ||
Ethernet LAN (RJ-45) ports |
1 | 1 | 1 | |
Number of languages |
1 | |||
DC-in jack |
Yes | |||
Housing material |
Plastic | Metal | Plastic | |
Networking standards |
IEEE 802.3at | IEEE 802.3af | ||
Security algorithms |
TLS | |||
Ethernet LAN |
Yes | Yes | Yes | |
Supported graphics resolutions |
352 x 288 | 320 x 240 | ||
Zoom capability |
Yes | |||
Diameter |
12.3 cm | |||
International Protection (IP) code |
IP67 | IP66 | ||
Ethernet interface type |
Fast Ethernet | Fast Ethernet | Fast Ethernet | |
Number of Users |
21 user(s) | 32 user(s) | ||
Web-based management |
Yes | |||
Quality of Service (QoS) support |
Yes | |||
Supported network protocols |
ONVIF, TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS | |||
Reset button |
Yes | Yes | ||
Password protection |
Yes | Yes | ||
Languages support |
English | |||
Frame Rate |
30 fps | 30 fps | 15 fps | |
Mounting kit |
Yes | |||
Product colour |
White | Black | White | |
Tilt angle range |
0 - 85° | 0 - 90° | 0 - 90° | |
Sustainability certificates |
RoHS | |||
Sustainability compliance |
Yes | |||
Focal length range |
2.8 mm | |||
Fixed focal length |
2.8 mm | 3.6 mm | ||
Screws included |
Yes | Yes | ||
LED type |
IR | |||
Night vision |
Yes | Yes | Yes | |
Total megapixels |
4 MP | 2 MP | 3 MP | |
PTZ control |
Yes | |||
Optical sensor size |
25.4 / 3 mm (1 / 3") | 25.4 / 2.8 mm (1 / 2.8") | 25.4 / 2.8 mm (1 / 2.8") | |
Minimum illumination |
0.001 lx | |||
Pan range |
0 - 360° | 0 - 360° | 0 - 355° | |
Lens viewing angle, diagonal |
122° | 127° | 107° | |
Video compression formats |
H.265+ | H.264+ | H.264 | |
Angle of rotation |
360° | 360° | ||
DC output current |
0.3 A | 1 A | ||
DC output voltage |
12 | 12 | 12 | |
Video motion detection |
Yes | Yes | Yes | |
Number of cameras |
1 | 1 | 1 | |
Camera pan control |
Yes | Yes | ||
Camera tilt control |
Yes | Yes | ||
Night vision distance |
30 m | 30 m | 30 m | |
Number of lenses |
1 | 1 | 2 | |
Day/night mode |
Yes | Yes | Yes | |
Infrared (IR) cut-off filter |
Yes | |||
Auto-tracking |
Yes | |||
Built-in HDD |
No | No | No | |
Lens viewing angle, vertical |
55° | 56° | 45° | |
Noise reduction technology |
3D noise reduction | 3D noise reduction | ||
Digital Wide Dynamic Range (DWDR) |
Yes | Yes | ||
Region of Interest (ROI) encoding |
Yes | |||
Maximum aperture number |
1.6 | 1 | ||
Lens viewing angle, horizontal |
102° | 107° | 88° | |
Number of sensors |
1 | 2 | ||
Infra-red wavelength |
850 nm | |||
Built-in siren |
Yes | |||
Audio detection |
Yes | |||
Wide Dynamic Range (WDR) |
Yes | |||
Progressive scan |
Yes | Yes | Yes | |
Mirror |
Yes | Yes | ||
Heartbeat |
Yes | |||
Anti-flicker |
Yes | |||
Back Light Compensation (BLC) |
Yes | Yes | ||
Video streaming |
Yes | |||
Weatherproof |
Yes | |||
Active tampering alarm |
Yes | |||
IP address filtering |
Yes | Yes | ||
Intelligent Video Surveillance (IVS) system features |
Crossing line | Vehicle detection | ||
Camera shutter speed |
1/3 - 1/100000 s | |||
Privacy masking |
Yes | Yes | Yes | |
Highlight Compensation (HLC) |
Yes | |||
Power consumption (Power over Ethernet (PoE)) |
4.5 W | |||
HTTPS encryption |
Yes | Yes | ||
Image quality adjustment |
Brightness | Sharpness | ||
Digest authentication |
Yes | |||
Password reset via email |
Yes | |||
Streaming method |
Multicast | |||
Mounting template |
Yes | |||
Anchors included |
Yes | |||
Closest focusing distance |
1.7 m | |||
Siren noise level |
110 dB | |||
Detect distance |
64 m | |||
Observe distance |
27 m | |||
Recognize distance |
13 m | |||
Identify distance |
6 m | |||
Smartphone/tablet remote support |
Yes | |||
Warnings |
The product contains electronic components; do not dispose of with the normal household waste. | |||
