Camera | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Image Sensor | 1/1.8” 4Megapixel progressive scan CMOS | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Effective Pixels | 2688 (H) × 1520 (V) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
RAM/ROM | 1 GB/128 MB | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Scanning System | Progressive | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Electronic Shutter Speed | Auto/Manual, 1/3 s–1/100000 s | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Minimum Illumination | 0.001 Lux @F1.0 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Lens | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Lens Type | Fixed-focal | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Mount Type | Board-in | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Focal Length | 3.6 mm | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Max. Aperture | F1.0 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Angle of View | H: 93°, V: 50° | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Aperture Type | Fixed | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Close Focus Distance | 2.0 m (6.56 ft) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
DORI Distance | Lens | Detect | Observe | Recognize | Identify | ||||||||||||||||||||||||||||||||||||||||||||||||||||||
3.6mm | 70 m (230 ft) | 28 m (91 ft) | 14m(46ft) | 7m(23ft) | |||||||||||||||||||||||||||||||||||||||||||||||||||||||
Pan/Tilt/Rotation | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Pan/Tilt/Rotation Range | Pan: 0?–360?; Tilt: 0?–90?; Rotation: 0?–360? | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Artificial Intelligence | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Face Detection | Support face image capture | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Perimeter Protection | Tripwire; intrusion (Recognition of vehicle and people); fast moving; loitering detection; parking detection and people gathering | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
People Counting | Support Line crossing/Region/Queueing people counting; Support 4 accesses independent detection, 4 areas independent detection | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
General Intelligence | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Event Trigger | Motion detection, Video tampering , Scene changing, Network disconnection , IP address conflict, Illegal Access, Storage anomaly | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
General Intelligence | Object Abandoned/Missing | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Heat Map | Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Video | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Compression | H.265, H.264, H.264B, H.264H, MJPEG(sub stream) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Smart Codec | Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Streaming Capability | 3 Streams | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Resolution | 2688 × 1520/2560 × 1440/2304 × 1296/1080P (1920 × 1080)/1.3M (1280 × 960)/720P (1280 × 720)/D1 (704 × 576/704 × 480)/VGA (640 × 480)/CIF (352 × 288/352 × 240) |
Frame Rate | Main Stream: 2688 × 1520 (1 fps–25/30 fps) 2560 × 1440 (1 fps–25/30 fps) 1920 × 1080 (1 fps–50/60 fps) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Sub Stream: D1 (1 fps–25/30 fps) D1 (1 fps–50/60 fps) | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Third Stream: 1080P (1 fps–16 fps) | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Bit Rate Control | CBR/VBR | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Bit Rate | H.264: 32 Kbps–8192 Kbps H.265: 19 Kbps–8192 Kbps | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Day/Night | Day/Night: Electronic Color/B/W | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
BLC Mode | BLC/HLC/WDR (140 dB) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
White Balance | Auto/Natural/Street Lamp/Outdoor/Manual | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Gain Control | Auto/Manual | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Noise Reduction | 3D DNR | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Motion Detetion | Off/On (4 Zone, Rectangle) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Region of Interest | Off/On (4 Zone) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Defog | Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Flip | 0°/90°/180°/270° | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Mirror | Off/On | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Privacy Masking | Off/On (4 Area, Rectangle) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Compression | G.711a, G.711Mu, G.726, AAC, G.723 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Network | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Ethernet | RJ-45 (10/100 Base-T) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Protocol | IPv4; IPv6; HTTP; HTTPS; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; 802.1x; SNMP | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Interoperability | ONVIF (Profile S/Profile G/Profile T); CGI; Milstone, Genetec; P2P | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Streaming Method | Unicast/Multicast | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Max. User Access | 20 Users | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Edge Storage | NAS; FTP; SFTP Micro SD card 256 GB | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Web Viewer | IE (versions newer than IE8), Chrome, Firefox, Safari (versions newer than Safari 12) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Management Software | Smart PSS, DSS, P2P | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Smart Phone | iOS, Android | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Certifications | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Certifications | CE-LVD: EN60950-1 CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU FCC: 47 CFR FCC Part 15, Subpart B UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Interface | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio Interface | 1/1 channel In/Out |
Alarm | 1 channel In: 5mA 5V DC 1 channel Out: 300mA 12V DC | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Electrical | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power Supply | DC 12V (±30%), PoE (802.3af) (Class 0) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power Consumption | <4.4W | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Environmental | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Operating Conditions | -30° C to +60° C (-22° F to +140° F)/Less than 95% RH | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Storage Conditions | -30° C to +60° C (-22° F to +140° F) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Ingress Protection | IP67 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Construction | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Casing | Metal | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Dimensions | 244.1 mm × 79.0 mm × 75.9 mm (9.61” × 3.11” × 2.99”) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Net Weight | 0.805 Kg (1.77 lb) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Gross Weight | 1.16 Kg (2.56 lb) |
Quick Compare
Product |
![]() |
![]() |
![]() |
![]() |
Availability |
|
|
|
|
Price |
€284.01
|
€285.36
|
€285.47
|
€285.50
|
Description |
||||
Type |
IP security camera | |||
Height |
105 mm | |||
Connectivity technology |
Wired | |||
Weight |
716.4 g | |||
Package weight |
929.7 g | |||
Power source type |
DC, PoE | |||
Operating temperature (T-T) |
-30 - 60 °C | |||
Operating relative humidity (H-H) |
0 - 95% | |||
Storage temperature (T-T) |
-40 - 60 °C | |||
Mounting type |
Ceiling | |||
Form factor |
Bullet | |||
Built-in microphone |
Yes | |||
Bit rate |
H.264: 3 kbps–20480 kbps H.265: 3 kbps–20480 kbps | |||
Noise reduction |
Yes | |||
Mobile operating systems supported |
Android | |||
Sensor type |
CMOS | |||
Internal memory |
512 MB | |||
Compatible memory cards |
SD | |||
Maximum memory card size |
256 GB | |||
Audio formats supported |
G.723 | |||
Signal-to-Noise Ratio (SNR) |
56 dB | |||
Power consumption (max) |
7.4 W | |||
Maximum resolution |
2688 x 1520 pixels | |||
Placement supported |
Indoor & outdoor | |||
Ethernet LAN (RJ-45) ports |
1 | |||
Audio output channels |
1 channels | |||
Housing material |
Metal | |||
Ethernet LAN |
Yes | |||
Focus |
Motorized | |||
Supported graphics resolutions |
2560 x 1440 | |||
Diameter |
12.6 cm | |||
International Protection (IP) code |
IP67 | |||
Supported video modes |
720p | |||
Video formats supported |
H.264+ | |||
Number of Users |
20 user(s) | |||
Frame Rate |
60 fps | |||
Product colour |
White | |||
Tilt angle range |
0 - 80° | |||
Focal length range |
2.7 - 12 mm | |||
Web browser |
Yes | |||
LED type |
IR | |||
Night vision |
Yes | |||
Total megapixels |
4 MP | |||
Optical sensor size |
25.4 / 1.8 mm (1 / 1.8") | |||
White balance |
Natural | |||
Minimum illumination |
0.0005 lx | |||
Pan range |
0 - 355° | |||
Dynamic range |
140 dB | |||
Lens viewing angle, diagonal |
142 - 55° | |||
Video compression formats |
H.264H | |||
Angle of rotation |
355° | |||
DC output voltage |
12 | |||
Video motion detection |
Yes | |||
Number of cameras |
1 | |||
Night vision distance |
40 m | |||
Number of lenses |
1 | |||
Day/night mode |
Yes | |||
Lens viewing angle, vertical |
59 - 27° | |||
Noise reduction technology |
3D noise reduction | |||
Region of Interest (ROI) encoding |
Yes | |||
Maximum aperture number |
2.8 | |||
Lens viewing angle, horizontal |
115 - 48° | |||
Progressive scan |
Yes | |||
Mirror |
Yes | |||
Back Light Compensation (BLC) |
Yes | |||
Intelligent Video Surveillance (IVS) system features |
Missing object | |||
ROM capacity |
128 MB | |||
Camera shutter speed |
1/3 – 1/100000 | |||
Number of effective pixels (H x V) |
2688 x 1520 pixels | |||
Bit rate control |
Constant Bit Rate (CBR), Variable Bit Rate (VBR) | |||
Gain control type |
Auto/Manual | |||
Privacy masking |
Yes | |||
Highlight Compensation (HLC) |
Yes | |||
Number of illumination LEDs |
3 | |||
Power consumption (Power over Ethernet (PoE)) |
3.3 W | |||
IK code |
IK10 | |||
Identify distance (wide) |
6 m | |||
Recognize distance (wide) |
12 m | |||
Audio input channels |
1 channels | |||
Observe distance (wide) |
24.1 m | |||
Management software |
Smart PSS;DSS;DMSS | |||
Closest focusing distance |
1.75 m | |||
Detect distance (wide) |
60.4 m | |||
Identify distance (tele) |
12.8 m | |||
Recognize distance (tele) |
27.5 m | |||
Detect distance (tele) |
128.6 m | |||
Observe distance (tele) |
51.4 m | |||
Alarm output channels |
1 | |||
Alarm input channels |
1 | |||
