Product Details
Data sheet
- Width
- 124.5 mm
- Height
- 200.7 mm
- Depth
- 119.4 mm
- Weight
- 2.8 kg
- USB port
- Yes
- LED indicators
- Yes
- Built-in display
- Yes
- Battery capacity
- 288 Wh
- Control type
- Buttons
- Number of simultaneously connected devices (max)
- 7
- Charging source
- AC, Cigar lighter, Solar
- AC outlets quantity
- 1 AC outlet(s)
- USB connector type
- USB Type-A
- Product colour
- Black
- Fast charging
- Yes
- USB Type-C ports quantity
- 2
- Built-in light
- Yes
- Solar panel power
- 100 W
- USB Type-A ports quantity
- 2
Quick Compare
Product |
UPS Bluewalker PowerWalker VI 1000 CSW - 600W - US
|
Eaton Ellipse ECO 800 USB IEC uninterruptible power supply (UPS) Standby (Offline) 0.8 kVA 500 W 4 AC outlet(s)
|
FSP iFP 2000 uninterruptible power supply (UPS) Line-Interactive 2 kVA 1200 W 2 AC outlet(s)
|
CyberPower Tracer III VP1200ELCD-FR uninterruptible power supply (UPS) Line-Interactive 1.2 kVA 720 W 5 AC outlet(s)
|
Availability |
|
|
|
|
Price |
€200.59
|
€200.91
|
€201.97
|
€203.15
|
Description |
||||
Cable length |
1.5 m | |||
Width |
99 mm | 81 mm | 130 mm | 100 mm |
Height |
280 mm | 263 mm | 182 mm | 281 mm |
Depth |
288 mm | 235 mm | 320 mm | 355 mm |
Weight |
8.5 kg | 4.1 kg | 11 kg | 9.62 kg |
Package depth |
378 mm | |||
Package height |
387 mm | |||
Package width |
188 mm | |||
Package weight |
8.5 kg | |||
Number of batteries supported |
2 | |||
Batteries included |
Yes | |||
Cables included |
USB cable | USB cable | ||
Storage relative humidity (H-H) |
0 - 90% | |||
Manual |
Yes | Yes | Yes | |
Operating temperature (T-T) |
0 - 40 °C | 0 - 40 °C | 0 - 40 °C | |
Operating relative humidity (H-H) |
0 - 90% | 0 - 90% | 0 - 90% | |
Storage temperature (T-T) |
-20 - 50 °C | |||
Form factor |
Tower | Tower | Mini tower | Tower |
USB port |
Yes | Yes | Yes | |
Mac compatibility |
Yes | |||
LED indicators |
Battery replacement | Yes | ||
Battery technology |
Sealed Lead Acid (VRLA) | Sealed Lead Acid (VRLA) | ||
Battery capacity |
10 Ah | 9 Ah | ||
Control type |
Buttons | |||
Battery recharge time |
8 h | 8 h | ||
Output power |
600 W | 500 W | 1200 W | 720 W |
Input frequency |
50/60 Hz | 50/60 Hz | 50/60 Hz | 50/60 Hz |
USB 2.0 ports quantity |
1 | 1 | 1 | |
Response time |
10 ms | 6 ms | 4 ms | |
Display type |
LCD | LCD | LCD | |
Ethernet LAN (RJ-45) ports |
1 | 1 | 2 | 1 |
Number of battery cells |
1 | |||
Efficiency |
98% | |||
Input operation voltage (min) |
170 V | 161 V | 140 V | 167 V |
Power protection features |
Battery discharge | |||
Cold start |
Yes | Yes | ||
AC outlets quantity |
4 AC outlet(s) | 4 AC outlet(s) | 2 AC outlet(s) | 5 AC outlet(s) |
Output power capacity |
1 kVA | 0.8 kVA | 2 kVA | 1.2 kVA |
Output operation voltage (max) |
230 V | 240 V | 240 V | 230 V |
Waveform |
Sine | Sine | Sine | |
Auto-restart |
Yes | |||
AC outlet types |
Type F | C13 coupler | Type F | Type E |
Input operation voltage (max) |
280 V | 284 V | 290 V | 295 V |
Audible alarm(s) |
Yes | Yes | Yes | |
Battery voltage |
12 V | 12 V | ||
Output operation voltage (min) |
200 V | 220 V | 110 V | |
UPS topology |
Line-Interactive | Standby (Offline) | Line-Interactive | Line-Interactive |
Modem (RJ-11) ports |
1 | 1 | ||
Typical backup time at full load |
4 min | |||
Automatic Voltage Regulation (AVR) |
Yes | Yes | ||
Automatic battery test |
Yes | |||
Housing material |
Plastic | |||
Typical backup time at half load |
11 min | 12 min | ||
Surge protection |
Yes | Yes | ||
Nominal input voltage |
220 V | |||
Nominal output voltage |
220-240 V | |||
Output frequency regulation |
±1 Hz | |||
Output voltage regulation |
±10% | 10% | ||
Operating altitude |
0 - 3048 m | |||
Serial interface type |
RJ-45 | RS-232 | ||
Output frequency |
50/60 Hz | 50/60 Hz | ||
Noise Level |
40 dB | 40 dB | 40 dB | |
Serial ports quantity |
1 | 1 | ||
Maximum current |
5.2 A | |||
Surge energy rating |
450 J | |||
Power plug |
C14 coupler | |||
Non-operating altitude |
0 - 3048 m | |||
Product colour |
Black | Black | Black | Black |
Harmonized System (HS) code |
85078000 | 85078000 | 85078000 | |
Sustainability compliance |
Yes | |||
Safety |
IEC 62040-1, IEC 60950-1, IEC 62040-2, CB Report, CE mark, IEC 61643-1 | |||
Serial interface |
Yes | |||
USB port type |
USB Type-B | USB Type-B | ||
Charging current |
2.1 A | |||
Hot-swap battery |
No | |||
Compliance certificates |
CE | RoHS | ||
Audible alarm modes |
Battery replacement | Alarm when on battery, Fault, Low battery alarm, Overload alarm | Alarm when on battery, Fault, Low battery alarm, Overload alarm | |
Overload protection |
Yes | |||
Power factor |
0.6 | |||
Surge protection features |
Modem | |||
Number of output IEC jumpers |
2 | |||
Emergency Power Off (EPO) |
No | |||
Rack capacity |
2U | |||
Number of type F outputs |
4 | |||
EMI/RFI noise filtering |
Yes | |||
Input connection type |
IEC | |||
Warnings |
Keep away from sources of fire and water. | Do not disassemble the unit housing, there may be a risk of electric shock. | ||
