Fortron

    FSP PSU VITA 750 GD 85+G 750W ATX3.1/GEN5

    €83.81
    Tax included
    Quantity

    Add to favorites Add to compare

    Product Details

    Fortron
    WLONONWCROKOS
    16 Items

    Data sheet

    Purpose
    PC
    Width
    150 mm
    Height
    86 mm
    Depth
    140 mm
    Cables included
    CPU, Peripheral (Molex), SATA
    Cooling type
    Active
    Fan diameter
    12 cm
    Input current
    10-5 A
    Efficiency
    90%
    Total power
    750 W
    Power protection features
    Under voltage
    AC input voltage
    100 - 240 V
    AC input frequency
    50/60 Hz
    Bearing technology
    HYB
    80 PLUS certification
    80 PLUS GOLD
    PCI Express power connectors (6+2 pin)
    4
    Number of SATA power connectors
    8
    Cabling Type
    Non-Modular
    Number of fans
    1 fan(s)
    CPU power connector (4+4 pin)
    Yes
    Peripheral (Molex) power connectors (4-pin)
    4
    Motherboard power connector
    20+4 pin ATX
    Max output current (+12V)
    62.5 A
    Max output current (+5Vsb)
    3 A
    Max output current (+3.3V)
    20 A
    Max output current (-12V)
    0.3 A
    Max output current (+5V)
    20 A
    Combined power (+3.3V)
    100 W
    Combined power (+5V)
    100 W
    Combined power (+12V)
    750 W
    Combined power (+5Vsb)
    15 W
    Combined power (-12V)
    3.6 W
    Product colour
    Black
    ATX version
    3.1
    Power Factor Correction (PFC) type
    Active
    Power supply unit (PSU) form factor
    ATX
    Fan location
    Top
    EPS version
    2.92
    Motherboard power cable length
    60 cm
    CPU power cable length
    70 cm
    SATA power cable length
    500
