APC

    APC Smart-UPS SMT1000IC – 8x C13, USB, SmartConnect, 1000VA

    €729.87
    Tax included
    Quantity

    Add to favorites Add to compare

    Product Details

    ZSIAPCUPS0191
    2 Items

    Data sheet

    Width
    171 mm
    Height
    219 mm
    Depth
    439 mm
    Weight
    18.9 kg
    Package height
    376 mm
    Package width
    328 mm
    Cables included
    RJ-45, USB cable
    Storage relative humidity (H-H)
    0 - 95%
    Operating temperature (T-T)
    0 - 40 °C
    Operating relative humidity (H-H)
    0 - 95%
    Storage temperature (T-T)
    -15 - 45 °C
    Form factor
    Mini tower
    USB port
    Yes
    LED indicators
    Yes
    Battery technology
    Sealed Lead Acid (VRLA)
    Battery life (max)
    5 year(s)
    Battery recharge time
    3 h
    Output power
    700 W
    Input frequency
    50/60 Hz
    USB 2.0 ports quantity
    1
    Response time
    10 ms
    Display type
    LCD
    Ethernet LAN (RJ-45) ports
    1
    Input operation voltage (min)
    151 V
    Cold start
    Yes
    AC outlets quantity
    8 AC outlet(s)
    Output power capacity
    1 kVA
    Output operation voltage (max)
    240 V
    Waveform
    Sine
    Auto-restart
    Yes
    AC outlet types
    C13 coupler
    Input operation voltage (max)
    302 V
    Audible alarm(s)
    Yes
    Output operation voltage (min)
    220 V
    UPS topology
    Line-Interactive
    Automatic Voltage Regulation (AVR)
    Yes
    Automatic battery test
    Yes
    Surge protection
    Yes
    Operating altitude
    0 - 3000 m
    Quick installation guide
    Yes
    Output frequency
    50/60 Hz
    Noise Level
    41 dB
    Serial ports quantity
    1
    Surge energy rating
    459 J
    Power plug
    C14 coupler
    Non-operating altitude
    0 - 15000 m
    Product colour
    Black
    Harmonized System (HS) code
    85078000
    Sustainability certificates
    Green Premium
    Serial interface
    Yes
    USB port type
    USB Type-A
    Output voltage Total Harmonic Distortion (THD)
    5%
    Hot-swap battery
    Yes
    Compliance certificates
    RoHS
    Total carbon footprint (kg of CO2e)
    984.74
    Audible alarm modes
    Alarm when on battery, Low battery alarm, Overload alarm
    Temperature voltage compensation
    Yes
    SmartSlot
    Yes
    Replacement battery cartridge
    RBC6
    Management card included
    No
    Warnings
    Do not disassemble the unit housing, there may be a risk of electric shock.
    SmartConnect port
    Yes
