Product Details
Quick Compare
Product |
![]() |
![]() |
![]() |
![]() |
Availability |
|
|
|
|
Price |
€95.21
|
€95.36
|
€96.49
|
€96.71
|
Description |
EnerGenie UPS UPS-PC-1202AP 1200 VA 220 V 220 V | Digitus All-in-One UPS, 800VA/480W, LED 12V/9Ah x1, 4x CEE 7/7,3x IEC C13, USB, RJ45 | ||
Colour of product |
Black | |||
Warranty |
24 month(s) | 24 month(s) | ||
Producer product name |
UPS UPS-PC-1202AP | All-in-One UPS, 800VA/480W, LED 12V/9Ah x1, 4x CEE 7/7,3x IEC C13, USB, RJ45 | ||
Net weight |
9.28 kg | 11.39 kg | ||
Gross weight |
10 kg | 12 kg | ||
WEEE tax |
Yes | Yes | ||
Packing quantity |
2 pc(s) | 1.00 pc(s) | ||
Gross depth master carton |
395 mm | |||
Gross width master carton |
375 mm | |||
Gross height master carton |
305 mm | |||
Net weight master carton |
20 kg | |||
Tare weight master carton |
0.768 kg | |||
Volume (m3) |
0.020709 m | 0.02652 m | ||
Tare weight (kg) |
0.72 kg | 0.61 kg | ||
Gross depth (mm) |
390 mm | 375 mm | ||
Gross width (mm) |
180 mm | 260 mm | ||
Gross height (mm) |
295 mm | 272 mm | ||
WEE classification |
CL109:5:2017-04-01 | CL109:6:2017-04-01 | ||
Paper/Pasteboard |
579 g | |||
Embeeded battery |
Yes | Yes | ||
TI weight (kg) |
7.16 kg | 2 kg | ||
Width |
22.2 cm | 100 mm | ||
Height |
12.4 cm | 141 mm | ||
Depth |
38.2 cm | 316 mm | ||
Other features |
Input: AC 220V 25%, 50Hz/60Hz 10%Output: AC 220V 10%, 50Hz/60Hz 0.5% (on battery)Switching time: no more than 10 msBackup time: 8...20mins (depends on the load)Battery: sealed lead-acid 12V/7Ah x 2pcsCharge time: up to 12 hoursSockets: Schuko EU type, 1 i | 4x shockproof sockets to connect your devices 3x IEC C13 sockets to connect monitors, for example 1x USB Type-A socket to charge mobile devices with 5V/2A max. 1x USB Type-B socket for software communication 1x RJ45 input / output for surge protection for | ||
Plastic (No PET) |
720.00 g | 30 g | ||
Composition of battery |
CL127:KT:2016-12-09 | CL127:KT:2016-12-09 | ||
Classification of battery |
CL126:PE:2016-12-09 | CL126:NE:2016-12-09 | ||
Type of battery |
Accumulator | Accumulator | ||
Weight |
10.4 g | 5.5 g | ||
Special features |
Regolazione automatica del voltaggio in output (AVR) Interfaccia USB Indicatori status del LED Protezione da corto circuiti Protezione da sovraccarichi e fulmini Allarmi sonori e visivi Protezione da sovraccaricamento e sovrascaricamento Protezione presa | |||
Product type |
UPS | |||
Producer product family |
All-in-One UPS | |||
Package depth |
39 cm | |||
Package height |
29.5 cm | |||
Package width |
18 cm | |||
Operating temperature (T-T) |
0 - 40 C | |||
Operating relative humidity (H-H) |
10 - 90 % | |||
Form factor |
Tower | Compact | Compact | |
RoHS compliance |
Yes | |||
Battery technology |
Sealed Lead Acid (VR | Sealed Lead Acid (VRLA) | ||
Battery capacity |
7 Ah | 9 Ah | ||
Capacity |
1200 VA | 480 W | ||
Palette Qty |
76 pc(s) | |||
Battery recharge time |
12 h | |||
Output power |
720 W | 480 W | ||
Input frequency |
50/60 Hz | |||
USB 2.0 ports quantity |
1 | |||
Response time |
10 ms | |||
Power supply input frequency |
50/60 Hz | |||
Input operation voltage (min) |
220 V | 230 V | ||
AC outlets quantity |
4 | 7 | ||
Output power capacity |
1200 VA | 0.8 kVA | ||
Output operation voltage (max) |
220 V | |||
Waveform |
Simulated sine | Pseudo sine | ||
Auto-restart |
Yes | |||
AC outlet types |
C13 coupler, C14 cou | C13 coupler | ||
Input operation voltage (max) |
220 V | 230 V | ||
Audible alarm(s) |
Yes | |||
Battery voltage |
12 V | 12 V | ||
Output operation voltage (min) |
220 V | |||
UPS topology |
Line-Interactive | Line-Interactive | Line-Interactive | |
Modem (RJ-11) ports |
2 | |||
Typical backup time at full load |
2-20 min | |||
Surge protection |
Yes | |||
Noise Level |
40 dB | |||
Product colour |
Black | |||
Power factor |
0.6 | |||
Number of input phases |
1 | |||
Number of output phases |
1 | |||
