- Full HD resolution delivers image clarity
- Wide viewing angles for an immersive experience
- Fast response time suitable for gaming
- Multiple connectivity options for versatility
- Eye care technologies reduce strain during use
Product Details
Data sheet
- Colour
- Black
- Weight
- 2.92 kg
- Device type
- LED-backlit LCD monitor - 24"
- Voltage
- AC 100-240 V (50/60 Hz)
- Response time
- 4 ms (grey-to-grey), 1 ms (MPRT)
- Panel type
- IPS
- Aspect ratio
- 16:9
- Pixel pitch
- 0.2745 mm
- Contrast ratio
- 1300:1
- PRODUCT DESCRIPTION
- Philips 24E1N1200A - 1000 Series - LED monitor - Full HD (1080p) - 24"
- Native resolution
- Full HD (1080p) 1920 x 1080 at 100 Hz
- Brightness
- 250 cd/m
- Colour Support
- 16.7 million colours
- Input Connectors
- HDMI, VGA, DisplayPort
- Display Position Adjustments
- Tilt
- Compliant Standards
- HDCP 1.4, Plug and Play, DDC/CI, RoHS, Mercury-free, CB, TUV/ISO 9241-307, TUV Bauart, EAC, EAEU RoHS, MEPS, PSB, PSE Mark, BSMI, VCCI, UKCA, EMF, FCC, ICES-003
- Screen Coating
- Anti-glare, 3H Hard Coating, Haze 25%
- Colour Gamut
- 81.39% DCI-P3 (CIE 1976), 89.36% NTSC (CIE 1976), 87.82% Adobe RGB (CIE 1976), 102.66% sRGB (CIE 1931)
- Dimensions (WxDxH) - with stand (highest position)
- 54.2 cm x 18 cm x 41.7 cm
Quick Compare
Product |
|
LCD Monitor|DAHUA|DHI-LM24-B201A|23.8"|Business|Panel IPS|1920x1080|100Hz|5 ms|Colour Black|LM24-B201A
|
|
|
Availability |
|
|
|
|
Price |
€94.61
|
€94.87
|
€94.87
|
€94.94
|
Description |
Model DHI-LM24-B201A | 23.8" | Business | Panel IPS | Resolution 1920x1080 | Refresh rate 100Hz | Brightness 250 | Contrast 1000:1 | Response time 5 ms | Horizontal 178 degrees | Vertical 178 degrees | Displayable colours 16.7 million | 1x15pin D-sub | 1xHDMI | 1xDisplayPort | 100 mm x 100 mm | Colour Black | AOC 22E2UMF 21.5" 1920x1080/16:9/250cd/m2/4ms/HDMI DP Audio | ||
Plug and Play |
Yes | |||
Warranty |
36 month(s) | |||
Net weight |
2.73 kg | |||
Gross weight |
4.33 kg | |||
WEEE tax |
Yes | |||
Packing quantity |
1.00 pc(s) | |||
Volume (m3) |
0.03 m | |||
Tare weight (kg) |
1.60 kg | |||
Gross depth (mm) |
401.00 mm | |||
Gross width (mm) |
564.00 mm | |||
Gross height (mm) |
137.00 mm | |||
WEE classification |
CL109:2:2017-04-01 | |||
Paper/Pasteboard |
1200.00 g | |||
Embeeded battery |
No | |||
Plastic (No PET) |
400.00 g | |||
Package depth |
124 mm | |||
Package height |
447 mm | |||
Package width |
690 mm | |||
Package weight |
6.04 kg | |||
Cables included |
DisplayPort | |||
Operating temperature (T-T) |
0 - 40 °C | |||
Operating relative humidity (H-H) |
20 - 80% | |||
Storage temperature (T-T) |
-20 - 60 °C | |||
LED indicators |
Operation | |||
Power supply type |
External | |||
Palette Qty |
28 pc(s) | |||
Mean time between failures (MTBF) |
50000 h | |||
HDMI ports quantity |
1 | 2 | ||
DisplayPorts quantity |
1 | |||
Display technology |
LCD | |||
Display diagonal |
68.6 cm (27") | 60.5 cm (23.8") | ||
Backlight type |
W-LED | |||
Built-in camera |
No | No | ||
VGA (D-Sub) ports quantity |
1 | |||
LED backlight |
Yes | |||
Power consumption (typical) |
15.6 W | 20 W | ||
HDCP |
Yes | |||
Response time |
4 ms | 5 ms | ||
HD type |
Full HD | Full HD | ||
Contrast ratio (typical) |
1500:1 | 3000:1 | ||
Viewing angle, horizontal |
178° | 178° | ||
Viewing angle, vertical |
178° | 178° | ||
Native aspect ratio |
16:9 | 16:9 | ||
Built-in speaker(s) |
No | Yes | ||
VESA mounting |
Yes | Yes | ||
Tilt adjustment |
Yes | Yes | ||
Height adjustment |
No | No | ||
Cable lock slot |
Yes | No | ||
Horizontal scan range |
30 - 85 kHz | |||
Vertical scan range |
48 - 75 Hz | |||
Viewable size, horizontal |
59.8 cm | 52.7 cm | ||
Viewable size, vertical |
33.6 cm | 29.6 cm | ||
DDC/CI |
Yes | |||
RMS rated power |
4 W | |||
NVIDIA G-SYNC |
No | No | ||
On Screen Display (OSD) languages |
English | |||
Power consumption (standby) |
0.5 W | 0.5 W | ||
Width (with stand) |
617 mm | 540 mm | ||
Depth (with stand) |
200 mm | 182 mm | ||
Height (with stand) |
451 mm | 408 mm | ||
Panel type |
IPS | IPS | ||
Maximum refresh rate |
120 Hz | 100 Hz | ||
HDMI version |
1.4 | 1.4 | ||
DisplayPort version |
1.2 | |||
HDMI |
Yes | Yes | ||
Touchscreen |
No | No | ||
Display sRGB |
Yes | |||
Display number of colours |
16.7 million colours | 16.7 million colours | ||
Power consumption (off) |
0.3 W | 0.5 W | ||
Pixel pitch |
0.3114 x 0.3114 mm | |||
Pixel density |
81.59 ppi | 93 ppi | ||
Display diagonal (metric) |
68.6 cm | 60.5 cm | ||
Garantija |
36 | |||
AC input voltage |
100 - 240 V | 100 - 240 V | ||
Cable lock slot type |
Kensington | |||
AC input frequency |
50/60 Hz | |||
Supported graphics resolutions |
1920 x 1080 (HD 1080) | |||
Digital horizontal frequency |
30 - 115 kHz | |||
Operating altitude |
0 - 3658 m | |||
On Screen Display (OSD) |
Yes | |||
Colour Gamut |
99% | |||
Screen shape |
Flat | Flat | ||
Built-in USB hub |
No | No | ||
Non-operating altitude |
3658 - 12192 m | |||
Product colour |
Black | Black | ||
Market positioning |
Home | |||
Energy consumption (SDR) per 1000 hours |
21 kWh | |||
Energy efficiency class (SDR) |
E | E | ||
Width (without stand) |
617 mm | 540 mm | ||
Weight (with stand) |
3.5 kg | 3.93 kg | ||
Height (without stand) |
358 mm | 343 mm | ||
Depth (without stand) |
33 mm | 61 mm | ||
Flicker-free technology |
Yes | Yes | ||
AMD FreeSync |
No | No | ||
Low Blue Light technology |
Yes | Yes | ||
Display resolution |
1920 x 1080 pixels | 1920 x 1080 pixels | ||
Display brightness (typical) |
250 cd/m² | 250 cd/m² | ||
Digital vertical frequency |
48 - 100 Hz | |||
Surface hardness |
3H | |||
Tilt angle range |
-5 - 20° | -5 - 20° | ||
Panel mounting interface |
100 x 100 mm | 100 x 100 mm | ||
Sustainability certificates |
ENERGY STAR | ENERGY STAR | ||
Weight (without stand) |
3.13 kg | 3.54 kg | ||
RGB colour space |
sRGB | |||
sRGB coverage (typical) |
104.02% | |||
Energy efficiency scale |
A to G | |||
Anti-glare screen |
Yes | |||
Energy efficiency class (HDR) |
Not available | |||
Dynamic contrast ratio marketing name |
Mega Infinity DCR | |||
Smart modes |
ePaper | |||
NTSC coverage (typical) |
91.27% | |||
Number of OSD languages |
21 | |||
HDCP version |
1.4 | |||
Adobe RGB coverage |
89.71% | |||
Recyclable packaging material |
100% | |||
Exterior finish type |
Textured | |||
DCI-P3 coverage |
79.86% | |||
Doesn't contain |
Mercury | |||
Component video sync |
Separate sync | |||
EasyRead mode |
Yes | |||
Haze rate |
25% | |||
Regulatory Approvals |
CB, CE Mark, TUV/ISO9241-307, TUV-BAUART, EAC, EAEU RoHS, KC, CEL, CCC, CECP, UKCA, EMF, FCC, ICES-003 | |||
LowBlue mode |
Yes | |||
Picture enhancement |
SmartImage | |||
Colour gamut standard |
DCI-P3 | |||
Producer |
AOC | |||
European Product Registry for Energy Labelling (EPREL) code |
2048079 | |||
Compliance certificates |
RoHS | |||
Response time (MPRT) |
1 ms | |||
Response time measurement type |
GTG (Gray to Gray) | |||
Adaptive synchronisation |
Yes | |||
Warnings |
Place the monitor on a flat and stable surface to avoid tipping and damage. | |||
