Product Details
Data sheet
- Type
- IP security camera
- Connectivity technology
- Wired
- Weight
- 740 g
- Package depth
- 170 mm
- Package height
- 150 mm
- Package width
- 170 mm
- Package weight
- 1.07 kg
- Power source type
- DC, PoE
- Storage relative humidity (H-H)
- 0 - 95%
- Operating temperature (T-T)
- -30 - 60 °C
- Operating relative humidity (H-H)
- 0 - 95%
- Storage temperature (T-T)
- -30 - 60 °C
- Mounting type
- Ceiling/wall
- Form factor
- Turret
- Built-in microphone
- Yes
- Bluetooth
- No
- Bit rate
- 32 Kbps - 16 Mbps
- Noise reduction
- Yes
- Protection features
- Water resistant
- Sensor type
- CMOS
- Wi-Fi
- No
- Compatible memory cards
- MicroSD (TransFlash)
- Maximum memory card size
- 256 GB
- Signal-to-Noise Ratio (SNR)
- 52 dB
- Power consumption (max)
- 5.4 W
- Placement supported
- Indoor & outdoor
- Card reader integrated
- Yes
- Ethernet LAN (RJ-45) ports
- 1
- Number of languages
- 33
- Housing material
- Metal
- Networking standards
- IEEE 802.3af
- Security algorithms
- TLS
- Ethernet LAN
- Yes
- Supported graphics resolutions
- 640 x 360
- Diameter
- 13.8 cm
- International Protection (IP) code
- IP67
- Ethernet interface type
- Fast Ethernet
- Number of Users
- 32 user(s)
- Quality of Service (QoS) support
- Yes
- Reset button
- Yes
- Password protection
- Yes
- Languages support
- Multi
- Frame Rate
- 30 fps
- Product colour
- Black
- Tilt angle range
- 0 - 75°
- Fixed focal length
- 2.8 mm
- Web browser
- Yes
- Voice codecs
- AAC
- LED type
- IR
- Night vision
- Yes
- Total megapixels
- 6 MP
- Optical sensor size
- 25.4 / 2.4 mm (1 / 2.4")
- Pan range
- 0 - 360°
- Video compression formats
- M-JPEG
- Angle of rotation
- 360°
- DC output voltage
- 12
- Video motion detection
- Yes
- Number of cameras
- 1
- Camera pan control
- Yes
- Camera tilt control
- Yes
- Night vision distance
- 30 m
- Number of lenses
- 1
- Day/night mode
- Yes
- Infrared (IR) cut-off filter
- Yes
- Built-in HDD
- No
- Lens viewing angle, vertical
- 53.4°
- Noise reduction technology
- 3D noise reduction
- Region of Interest (ROI) encoding
- Yes
- Maximum aperture number
- 1.6
- Number of sensors
- 1
- Infra-red wavelength
- 850 nm
- Wide Dynamic Range (WDR)
- Yes
- Progressive scan
- Yes
- Mirror
- Yes
- Heartbeat
- Yes
- Anti-flicker
- Yes
- Back Light Compensation (BLC)
- Yes
- Video streaming
- Yes
- Active tampering alarm
- Yes
- IP address filtering
- Yes
- Intelligent Video Surveillance (IVS) system features
- Face detection
- Bit rate control
- Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
- Gain control type
- Auto
- Privacy masking
- Yes
- Highlight Compensation (HLC)
- Yes
- Power consumption (Power over Ethernet (PoE))
- 6.5 W
- HTTPS encryption
- Yes
- Behavior analysis
- Intrusion detection, Line crossing detection, Region entrance detection, Region exiting detection
- Image quality adjustment
- Saturation
Quick Compare
Product |
![]() |
![]() |
![]() |
![]() |
Availability |
|
|
|
|
Price |
€154.65
|
€154.91
|
€155.58
|
€155.73
|
Description |
||||
Type |
IP security camera | IP security camera | IP security camera | |
Width |
48 mm | 183 mm | ||
Height |
107.5 mm | 216.3 mm | ||
Depth |
48 mm | 2.4 mm | ||
Connectivity technology |
Wired | Wired & Wireless | Wired | |
Weight |
170 g | 334 g | 1.07 kg | |
Product type |
Solar panel | |||
Package depth |
156 mm | |||
Package height |
155 mm | |||
Package width |
386 mm | |||
Power source type |
PoE | Battery, DC | DC, PoE | |
Cables included |
USB | |||
Storage relative humidity (H-H) |
0 - 90% | 0 - 90% | 0 - 95% | |
Manual |
Yes | |||
Operating temperature (T-T) |
-20 - 40 °C | -20 - 50 °C | -30 - 60 °C | |
Operating relative humidity (H-H) |
0 - 95% | 0 - 95% | ||
Storage temperature (T-T) |
-30 - 60 °C | |||
Mounting type |
Ceiling/wall | Wall | Ceiling/wall | |
Form factor |
Spherical | Bullet | ||
Built-in microphone |
Yes | |||
Material |
Polycarbonate (PC) | |||
Bluetooth |
No | No | ||
Bit rate |
2 Mbps | 32 Kbps - 8 Mbps | ||
Noise reduction |
Yes | Yes | Yes | |
Protection features |
Water resistant | |||
Length |
28.9 cm | |||
Cord length |
4 m | |||
Processor cores |
2 | |||
Sensor type |
CMOS | CMOS | CMOS | |
Wi-Fi |
No | Yes | No | |
Compatible memory cards |
MMC | MicroSDXC | ||
Wi-Fi standards |
802.11b | |||
Maximum memory card size |
32 GB | |||
Signal-to-Noise Ratio (SNR) |
52 dB | |||
Output voltage |
6,36 V | |||
Power consumption (max) |
10 W | 7.5 W | ||
Maximum resolution |
2688 x 1512 pixels | 2560 x 1440 pixels | 2688 x 1520 pixels | |
Placement supported |
External / Internal | Outdoor | Indoor & outdoor | |
Card reader integrated |
Yes | Yes | ||
Ethernet LAN (RJ-45) ports |
1 | 1 | ||
Number of languages |
33 | |||
Networking standards |
IEEE 802.11b | IEEE 802.3af | ||
Security algorithms |
WPA-PSK | TLS | ||
Ethernet LAN |
Yes | Yes | Yes | |
Lens type |
Fixed focal length lens | |||
Supported graphics resolutions |
2560 x 1440 | 1920 x 1080 (HD 1080) | ||
Diameter |
10.5 cm | |||
International Protection (IP) code |
IPX4 | IP65 | IP67 | |
Ethernet interface type |
Fast Ethernet | Fast Ethernet | ||
Number of Users |
32 user(s) | |||
Quality of Service (QoS) support |
Yes | |||
Reset button |
Yes | Yes | ||
Password protection |
Yes | Yes | ||
Languages support |
Multi | |||
Frame Rate |
30 fps | 30 fps | ||
Product colour |
White | Black | White | |
Tilt angle range |
0 - 65° | 0 - 90° | ||
Fixed focal length |
2.8 mm | |||
Web browser |
Yes | |||
Processor architecture |
ARM Cortex-A7 | |||
Screws included |
Yes | |||
LED type |
IR | IR | ||
Night vision |
Yes | Yes | Yes | |
Total megapixels |
4 MP | 4 MP | 4 MP | |
Motion sensor |
Yes | |||
PTZ control |
Yes | |||
Optical sensor size |
25.4 / 3 mm (1 / 3") | 25.4 / 3 mm (1 / 3") | ||
White balance |
Manual | |||
Pan range |
0 - 340° | 0 - 360° | ||
Lens viewing angle, diagonal |
120.6° | 100° | 123° | |
Video compression formats |
H.264 | H.264 | M-JPEG | |
Angle of rotation |
360° | |||
DC output current |
2 A | 0.63 A | ||
DC output voltage |
57 | 5 | 12 | |
Video motion detection |
Yes | Yes | ||
Operating frequency |
2400 - 24835 MHz | |||
Number of cameras |
1 | 1 | 1 | |
Camera pan control |
Yes | Yes | ||
Camera tilt control |
Yes | Yes | ||
Night vision distance |
6 m | 15 m | 60 m | |
Number of lenses |
1 | 1 | ||
Day/night mode |
Yes | Yes | Yes | |
Infrared (IR) cut-off filter |
Yes | Yes | Yes | |
Auto-tracking |
Yes | |||
Built-in HDD |
No | No | ||
Lens viewing angle, vertical |
54.9° | 44° | 55° | |
Noise reduction technology |
2D / 3D | 3D noise reduction | 3D noise reduction | |
Region of Interest (ROI) encoding |
Yes | |||
Maximum aperture number |
1.6 | 1.4 | ||
Lens diameter |
4 mm | |||
Channel bandwidth |
20 MHz | |||
Lens viewing angle, horizontal |
102.4° | 83° | 103° | |
Number of sensors |
1 | 1 | 1 | |
Infra-red wavelength |
850 nm | |||
Alert notification type |
||||
Audio detection |
Yes | |||
Wide Dynamic Range (WDR) |
Yes | |||
Progressive scan |
Yes | Yes | ||
Mirror |
Yes | |||
Heartbeat |
Yes | Yes | ||
Anti-flicker |
Yes | Yes | ||
Digital watermark |
Yes | |||
Back Light Compensation (BLC) |
Yes | |||
Video streaming |
Yes | |||
Weatherproof |
Yes | |||
Active tampering alarm |
Yes | |||
IP address filtering |
Yes | |||
Intelligent Video Surveillance (IVS) system features |
Human detection | Face detection | ||
Camera shutter speed |
1/3 - 1/100000 s | |||
Bit rate control |
Constant Bit Rate (CBR)/Variable Bit Rate (VBR) | |||
Gain control type |
Auto | |||
Highlight Compensation (HLC) |
Yes | |||
Power consumption (Power over Ethernet (PoE)) |
4 W | 9 W | ||
HTTPS encryption |
Yes | |||
Behavior analysis |
Intrusion detection, Line crossing detection, Region entrance detection, Region exiting detection | |||
Image quality adjustment |
Brightness | Saturation | ||
IK code |
IK04 | |||
Password reset via email |
Yes | |||
Identify distance (wide) |
6 m | |||
Recognize distance (wide) |
12 m | |||
Solar panel current |
660 mA | |||
Solar cell type |
Monocrystalline silicon | |||
Solar panel included |
Y | |||
Rated power |
4.2 W | |||
