Camera | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Image Sensor | 1/2.8" CMOS | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Max. Resolution | 1920 (H) × 1080 (V) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
ROM | 128 MB | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
RAM | 128 MB | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Scanning System | Progressive | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Electronic Shutter Speed | Auto/Manual 1/3 s–1/100,000 s | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Min. Illumination | 0.002 Lux@F1.6 (Color, 30IRE) 0.0002Lux@F1.6 (B/W, 30IRE) 0 lux (Illuminator on) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
S/N Ratio | >56 dB | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Illumination Distance | 30 m (98.43 ft) (IR), 30 m (98.43 ft) (Warm light) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Illuminator On/Off Control | Auto; Manual | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Illuminator Number | 1 (IR LED); 1 (Warm light) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Pan/Tilt/Rotation Range | Pan: 0°–360° Tilt: 0°–78° Rotation: 0°–360° | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Lens | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Lens Type | Fixed-focal | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Lens Mount | M12 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Focal Length | 2.8 mm | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Max. Aperture | F1.6 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Field of View | 2.8 mm: H: 107°; V: 56°; D: 127° | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Iris Control | Fixed | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Close Focus Distance | 2.8 mm: 0.7 m (2.30 ft) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
DORI Distance | Lens | Detect | Observe | Recognize | Identify | ||||||||||||||||||||||||||||||||||||||||||||||||||||||
2.8 mm | 43.9 m (144.03 ft) | 17.5 m (57.41 ft) | 8.8 m (28.87 ft) | 4.4 m (14.44 ft) | |||||||||||||||||||||||||||||||||||||||||||||||||||||||
Intelligence | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
IVS (Perimeter Protection) | Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Smart Search | Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Video | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Video Compression | H.264H; H.265; H.264; H.264B; MJPEG (Only supported by the sub stream) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Smart Codec | Smart H.265+; Smart H.264+ | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Video Frame Rate | Main stream: 1920 × 1080@(1–25/30 fps) Sub stream: 704 × 576@(1–25 fps)/704 × 480@(1–30 fps) *The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity. | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Stream Capability | 2 streams | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Resolution | 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Bit Rate Control | CBR/VBR | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Video Bit Rate | H.264: 32 kbps–6144 kbps; H.265: 12 kbps–6144 kbps | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Day/Night | Auto(ICR)/Color/B/W | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
BLC | Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
HLC | Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
WDR | 120 dB | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
White Balance | Auto; natural; street lamp; outdoor; manual; regional custom | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Gain Control | Auto;Manual | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Noise Reduction | 3D NR | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Motion Detection | OFF/ON (4 areas, rectangular) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Region of Interest (RoI) | Yes (4 areas) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Image Rotation | 0°/90°/180°/270° (Support 90°/270° with 1080p resolution and lower) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Mirror | Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Privacy Masking | 4 areas | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Built-in MIC | Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio Compression | G.711a; G.711Mu; PCM; G.726 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Alarm | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Alarm Event | No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; voltage detection; security exception; SMD | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Network | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Network Port | RJ-45 (10/100 Base-T) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
SDK and API | Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Network Protocol | IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; NTP; Multicast; ICMP; IGMP | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Interoperability | ONVIF (Profile S/Profile T); CGI; P2P; Milestone | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
User/Host | 6 (Total bandwidth: 36 M) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Storage | FTP; SFTP; Micro SD card (support max. 256 GB) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Browser | IE Chrome Firefox | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Management Software | DSS;DMSS | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Mobile Client | iOS;Android | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Cyber Security | Configuration encryption; Trusted execution; Digest; Security logs; WSSE; Account lockout; syslog; Video encryption; 802.1x; IP/MAC filtering; HTTPS; Trusted upgrade; Trusted boot; Generation and importing of X.509 certification | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Certification | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Certifications | CE-LVD: EN 62368-1; CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU; FCC: 47 CFR FCC Part 15, Subpart B | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power Supply | 12 VDC/PoE (802.3af) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power Consumption | Basic: 1.6 W (12 VDC); 1.9 W (PoE) Max. (H.265 + intelligence on + WDR + warm light): 3.8 W (12 VDC); 4.4 W (PoE) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Environment | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Operating Temperature | –40 °C to +60 °C (–40 °F to +140 °F) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Operating Humidity | ?95% | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Storage Temperature | –40 °C to +60 °C (–40 °F to +140 °F) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Protection | IP67 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Structure | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Casing Material | Inner core: Metal; Cover: Metal; Decoration ring: Plastic | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Product Dimensions | 99.1 mm × ?121.9 mm (3.90" × ?4.80") | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Net Weight | 0.46 kg (1.01 lb) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Gross Weight | 0.65 kg (1.43 lb) |
Quick Compare
Product |
![]() |
![]() |
![]() |
![]() |
Availability |
|
|
|
|
Price |
€109.68
|
€109.95
|
€110.15
|
€111.27
|
Description |
||||
Mac operating systems supported |
Yes | |||
Type |
IP security camera | IP security camera | IP security camera | |
Windows operating systems supported |
Yes | |||
Width |
63 mm | |||
Depth |
187 mm | |||
Connectivity technology |
Wireless | Wired | Wired & Wireless | |
Weight |
222.7 g | 1.21 kg | ||
Package depth |
103 mm | 190 mm | ||
Package height |
186 mm | 180 mm | ||
Package width |
103 mm | 385 mm | ||
Package weight |
569 g | |||
Power source type |
DC | DC, PoE | DC | |
Cables included |
DC | |||
Storage relative humidity (H-H) |
0 - 95% | |||
Manual |
Yes | |||
Operating temperature (T-T) |
-20 - 50 °C | -30 - 60 °C | -10 - 55 °C | |
Operating relative humidity (H-H) |
0 - 95% | 0 - 95% | 10 - 90% | |
Storage temperature (T-T) |
-30 - 60 °C | |||
Mounting type |
Ceiling/wall | Ceiling/wall | Wall | |
Form factor |
Bullet | Bullet | Bullet | |
Built-in microphone |
Yes | |||
Bluetooth |
No | No | No | |
Sample rate |
48 kHz | |||
Bit rate |
1.5 Mbps | 32 Kbps - 8 Mbps | 64 Kbps - 5120 Kbps | |
Noise reduction |
Yes | Yes | ||
Quick start guide |
Yes | |||
Battery capacity |
5200 mAh | |||
Length |
153.3 mm | 486 mm | ||
Sensor type |
CMOS | CMOS | CMOS | |
Wi-Fi |
Yes | No | Yes | |
Compatible memory cards |
MicroSD (TransFlash) | microSDHC | MicroSD (TransFlash) | |
Wi-Fi standards |
802.11a | |||
Maximum memory card size |
512 GB | 256 GB | 256 GB | |
Audio system |
2-way | 2-way | ||
Signal-to-Noise Ratio (SNR) |
120 dB | |||
Power consumption (max) |
10 W | 8.5 W | 12 W | |
Maximum resolution |
2304 x 1296 pixels | 1920 x 1080 pixels | 3840 x 2160 pixels | |
Viewing angle, horizontal |
107° | |||
Viewing angle, vertical |
56° | |||
Built-in speaker(s) |
Yes | |||
Placement supported |
Outdoor | Outdoor | Indoor & outdoor | |
Card reader integrated |
Yes | Yes | Yes | |
Ethernet LAN (RJ-45) ports |
1 | |||
Number of languages |
33 | |||
DC-in jack |
Yes | |||
Housing material |
Metal | |||
Networking standards |
IEEE 802.3af | IEEE 802.11a | ||
Security algorithms |
WPA2 | |||
Ethernet LAN |
No | Yes | Yes | |
Supported graphics resolutions |
2304 x 1296 | 640 x 480 (VGA) | 3840 x 2160 | |
Diameter |
6.7 cm | |||
International Protection (IP) code |
IP65 | IP67 | IP67 | |
Ethernet interface type |
Fast Ethernet | Fast Ethernet | ||
Supported video modes |
480p | 2160p | ||
Video formats supported |
H.264 | H.265 | H.265 | |
Number of Users |
32 user(s) | 20 user(s) | ||
Supported network protocols |
HTTPS, SSL, TCP/IP, UDP, IPv4, UPnP, RTSP, RTMP, ONVIF, SMTP, NTP, DHCP, DNS, DDNS, FTP, P2P | |||
Reset button |
Yes | Yes | ||
Password protection |
Yes | Yes | ||
Languages support |
Multi | |||
Frame Rate |
15 fps | 30 fps | 20 fps | |
Mounting kit |
Yes | Yes | ||
Product colour |
Black | White | White | |
Tilt angle range |
0 - 90° | |||
Fixed focal length |
2.8 mm | 2.8 mm | 4 mm | |
Web browser |
Yes | |||
Video recording |
Yes | Yes | ||
Virtual assistant |
Google Assistant | |||
Screws included |
Yes | Yes | ||
LED type |
IR | IR/White | ||
Night vision |
Yes | Yes | Yes | |
Total megapixels |
3 MP | 2 MP | 8 MP | |
Battery included |
Yes | |||
Optical sensor size |
25.4 / 2.8 mm (1 / 2.8") | 25.4 / 2.8 mm (1 / 2.8") | 25.4 / 2.7 mm (1 / 2.7") | |
Pan range |
0 - 360° | |||
Lens viewing angle, diagonal |
130° | |||
Video compression formats |
H.265 | M-JPEG | H.265 | |
Angle of rotation |
360° | |||
DC output current |
2 A | 0.7 A | 1 A | |
DC output voltage |
5 | 12 | 12 | |
Video motion detection |
Yes | Yes | ||
Number of cameras |
1 | 1 | 1 | |
Camera pan control |
Yes | |||
Camera tilt control |
Yes | |||
Night vision distance |
15 m | 60 m | 30 m | |
Number of lenses |
1 | 1 | 1 | |
Day/night mode |
Yes | Yes | ||
Infrared (IR) cut-off filter |
Yes | Yes | ||
Built-in HDD |
No | No | ||
Lens viewing angle, vertical |
56° | 45.2° | ||
Noise reduction technology |
3D noise reduction | 3D noise reduction | ||
Region of Interest (ROI) encoding |
Yes | |||
Maximum aperture number |
1.6 | 1 | 1.6 | |
Channel bandwidth |
20 MHz | |||
Lens viewing angle, horizontal |
108° | 88.8° | ||
Number of sensors |
1 | 1 | 1 | |
Infra-red wavelength |
850 nm | |||
Wide Dynamic Range (WDR) |
Yes | |||
Viewing angle, diagonal |
127° | |||
Progressive scan |
Yes | Yes | ||
Mirror |
Yes | |||
Heartbeat |
Yes | Yes | ||
Anti-flicker |
Yes | Yes | ||
Digital watermark |
Yes | |||
Back Light Compensation (BLC) |
Yes | |||
Video streaming |
Yes | Yes | ||
Active tampering alarm |
Yes | |||
Cloud services supported |
EZVIZ Cloud | |||
IP address filtering |
Yes | |||
Intelligent Video Surveillance (IVS) system features |
Human detection | |||
Camera shutter speed |
1/3 - 1/100000 s | |||
Bit rate control |
Constant Bit Rate (CBR)/Variable Bit Rate (VBR) | |||
Gain control type |
Auto | |||
Privacy masking |
Yes | |||
Highlight Compensation (HLC) |
Yes | |||
Number of illumination LEDs |
2 | |||
Live view |
Yes | |||
HTTPS encryption |
Yes | |||
Behavior analysis |
Intrusion detection, Line crossing detection, Region entrance detection, Region exiting detection | |||
Image quality adjustment |
Saturation | |||
Mounting brackets included |
Yes | |||
User access level |
Administrator, User | |||
Drilling template included |
Yes | |||
Colour night vision distance |
15 m | |||
Compliance certificates |
WEEE | |||
