- New


Product |
BCS-B-TIP12FR3(2.0) BCS BASIC Camera
|
|
IP PTZ CAMERA EZVIZ H8C
|
|
Availability |
|
|
|
|
Price |
€45.18
|
€45.22
|
€45.34
|
€45.40
|
Description |
||||
Type |
IP security camera | IP security camera | IP security camera | |
Package type |
Box | |||
Width |
73 mm | 100 mm | ||
Height |
71 mm | 149.7 mm | 96.9 mm | |
Depth |
129 mm | |||
Connectivity technology |
Wired | Wired & Wireless | Wired | |
Weight |
200 g | 420 g | 500 g | |
Package depth |
218 mm | 140 mm | ||
Package height |
103 mm | 192 mm | ||
Package width |
128 mm | 140 mm | ||
Package weight |
360 g | 730 g | 640 g | |
Power source type |
DC, PoE | DC | DC | |
Storage relative humidity (H-H) |
0 - 95% | 0 - 95% | ||
Manual |
Yes | Yes | ||
Operating temperature (T-T) |
-30 - 60 °C | -30 - 50 °C | -40 - 60 °C | |
Operating relative humidity (H-H) |
0 - 95% | 0 - 95% | 0 - 95% | |
Storage temperature (T-T) |
-40 - 60 °C | -40 - 60 °C | ||
Mounting type |
Ceiling/Wall/Pole | M12 | Ceiling/wall | |
Form factor |
Bullet | Spherical | Dome | |
Built-in microphone |
Yes | Yes | ||
Bluetooth |
No | No | ||
Bit rate |
256 Kbps - 4 Mbps | 2 Mbps | ||
Noise reduction |
Yes | Yes | ||
Length |
174 mm | |||
Sensor type |
CMOS | CMOS | CMOS | |
Wi-Fi |
No | Yes | ||
Compatible memory cards |
MicroSD (TransFlash) | |||
Maximum memory card size |
512 GB | |||
Signal-to-Noise Ratio (SNR) |
52 dB | 65 dB | ||
Power consumption (max) |
5 W | 12 W | 6.5 W | |
Power consumption (typical) |
1.32 W | |||
Maximum resolution |
2560 x 1440 pixels | 1920 x 1080 pixels | 2880 x 1620 pixels | |
Viewing angle, horizontal |
89° | |||
Viewing angle, vertical |
46° | |||
Placement supported |
Outdoor | Outdoor | Indoor & outdoor | |
Ethernet LAN (RJ-45) ports |
1 | 1 | ||
Viewing angle |
360° | |||
DC-in jack |
Yes | Yes | ||
Housing material |
Plastic | Metal | ||
Networking standards |
IEEE 802.3at | IEEE 802.11b | ||
Security algorithms |
HTTPS | |||
Ethernet LAN |
Yes | Yes | ||
Focus |
Motorized/Manual | |||
Bandwidth |
20 MHz | |||
Supported graphics resolutions |
2304 x 1296 | 2880 x 1620 | ||
Diameter |
10.6 cm | |||
International Protection (IP) code |
IP67 | IP67 | ||
Ethernet interface type |
Fast Ethernet | |||
Supported video modes |
480p | |||
Web-based management |
Yes | Yes | ||
Supported network protocols |
TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS | |||
Password protection |
Yes | |||
Frame Rate |
30 fps | 30 fps | 25 fps | |
Mounting kit |
Yes | |||
Product colour |
Black | White | White | |
Tilt angle range |
-90 - 90° | 0 - 80° | 2 - 74.8° | |
Sustainability compliance |
Yes | |||
Fixed focal length |
4 mm | 4 / 6 mm | 2.8 mm | |
Web browser |
Yes | |||
LED type |
IR | IR | ||
Night vision |
Yes | Yes | Yes | |
Total megapixels |
4 MP | 5 MP | ||
Fixed focus |
Yes | |||
Optical sensor size |
25.4 / 3 mm (1 / 3") | 25.4 / 2.7 mm (1 / 2.7") | ||
White balance |
Area white balance | |||
Minimum illumination |
0.01 lx | 0.05 lx | 0.01 lx | |
Pan range |
-90 - 90° | 0 - 350° | 0 - 360° | |
Lens viewing angle, diagonal |
88.7° | 104° | 134.3° | |
Video compression formats |
H.265 | H.264 | ||
Angle of rotation |
360° | |||
DC output current |
1 A | |||
DC output voltage |
12 | 12 | 12 | |
Video motion detection |
Yes | Yes | Yes | |
Number of cameras |
1 | 1 | 1 | |
Camera pan control |
Yes | |||
Camera tilt control |
Yes | |||
Night vision distance |
30 m | 30 m | 40 m | |
Number of lenses |
1 | 1 | 1 | |
Day/night mode |
Yes | Yes | Yes | |
Infrared (IR) cut-off filter |
Yes | |||
Remote viewing |
Yes | |||
Built-in HDD |
No | |||
Camera shutter type |
Electronic | |||
Lens viewing angle, vertical |
41.5° | 62.1° | ||
Noise reduction technology |
3D noise reduction | 3D noise reduction | ||
Smart IR |
Yes | Yes | ||
Digital Wide Dynamic Range (DWDR) |
Yes | Yes | ||
Region of Interest (ROI) encoding |
Yes | |||
Maximum aperture number |
2 | 2 | 1.6 | |
Lens viewing angle, horizontal |
75.1° | 113.3° | ||
Number of sensors |
1 | 1 | ||
Infra-red wavelength |
850 nm | |||
Wide Dynamic Range (WDR) |
Yes | DWDR | Yes | |
Progressive scan |
Yes | Yes | Yes | |
Mirror |
Yes | Yes | ||
Digital watermark |
Yes | |||
Back Light Compensation (BLC) |
Yes | Yes | ||
Video streaming |
Yes | Yes | ||
Weatherproof |
Yes | |||
Alarm input/output |
Yes | |||
IP address filtering |
Yes | |||
Intelligent Video Surveillance (IVS) system features |
Region exiting detection | Intrusion | ||
Camera shutter speed |
1/3 - 1/10000 s | 1/100000 s | ||
Bit rate control |
Constant Bit Rate (CBR)/Variable Bit Rate (VBR) | |||
Gain control type |
Auto | |||
Privacy masking |
Yes | |||
Highlight Compensation (HLC) |
Yes | Yes | ||
Number of illumination LEDs |
2 | 4 | ||
People detection |
Yes | |||
Two-way talk |
Yes | |||
People detection |
Yes | |||
HTTPS encryption |
Yes | |||
Behavior analysis |
Intrusion detection, Line crossing detection, Object removal detection, Region entrance detection, Region exiting detection | |||
Image quality adjustment |
Saturation | |||
Built-in loudspeaker |
Yes | |||
Digest authentication |
Yes | |||
Password reset via email |
Yes | |||
Card reader slot |
1 | |||
Number of simultaneous live view channels |
3 channels | |||
Built-in light |
Yes | |||
Adhesive type |
Wall | |||
Detect distance |
80 m | 59.8 m | ||
Observe distance |
33 m | 23.9 m | ||
Recognize distance |
16 m | 12 m | ||
Identify distance |
8 m | 6 m | ||
Human and vehicle targets classification |
Yes | |||
Alarm output channels |
1 | |||
Alarm input channels |
1 | |||
Compliance certificates |
BSMI | |||
Number of Privacy masking areas |
4 | 8 | ||
Network access storage (NAS) |
Yes | |||
3D positioning |
Yes | |||
Warnings |
The product contains electronic components; do not dispose of with the normal household waste. | |||
|
|
|
|
|
