KAMERA IP HIKVISION DS-2CD2347G3-LIS2UY/SL

Product Details

Reference CIPHIKKAM0811

In stock 1 Item

Data sheet

Type

IP security camera

Height

115.4 mm

Connectivity technology

Wired

Weight

820 g

Package depth

170 mm

Package height

160 mm

Package width

170 mm

Package weight

1.2 kg

Power source type

DC, PoE

Storage relative humidity (H-H)

0 - 95%

Manual

Yes

Operating temperature (T-T)

-30 - 60 °C

Operating relative humidity (H-H)

0 - 95%

Storage temperature (T-T)

-30 - 60 °C

Mounting type

Ceiling

Form factor

Turret

Built-in microphone

Yes

Bluetooth

No

Bit rate

32 Kbps to 8 Mbps

Noise reduction

Yes

Sensor type

CMOS

Wi-Fi

No

Compatible memory cards

MicroSDXC

Maximum memory card size

512 GB

Audio formats supported

MP3

Signal-to-Noise Ratio (SNR)

52 dB

Power consumption (max)

15.5 W

Maximum resolution

2688 x 1520 pixels

Built-in speaker(s)

Yes

Placement supported

Indoor & outdoor

Card reader integrated

Yes

Ethernet LAN (RJ-45) ports

1

Housing material

Metal

Ethernet LAN

Yes

Supported graphics resolutions

2688 x 1520

Diameter

13.8 cm

International Protection (IP) code

IP67

Ethernet interface type

Fast Ethernet

Supported video modes

1520p

Video formats supported

H.265

Number of Users

32 user(s)

Reset button

Yes

Frame Rate

30 fps

Product colour

White

Tilt angle range

0 - 75°

Fixed focal length

2.8 mm

Video recording

Yes

Image stabilizer

Yes

LED type

IR/White

Night vision

Yes

Total megapixels

4 MP

Fixed focus

Yes

Optical sensor size

25.4 / 1.8 mm (1 / 1.8")

Minimum illumination

0 lx

Pan range

0 - 360°

Dynamic range

130 dB

Lens viewing angle, diagonal

138.5°

Video compression formats

H.265

Angle of rotation

360°

DC output current

1.29 A

DC output voltage

12

Video motion detection

Yes

Number of cameras

1

Night vision distance

30 m

Number of lenses

1

Day/night mode

Yes

Infrared (IR) cut-off filter

Yes

Built-in HDD

No

Lens viewing angle, vertical

57.6°

Noise reduction technology

3D noise reduction

Smart IR

Yes

Digital Wide Dynamic Range (DWDR)

Yes

Region of Interest (ROI) encoding

Yes

Maximum aperture number

1

Lens viewing angle, horizontal

111.1°

Number of sensors

1

Infra-red wavelength

850 nm

Progressive scan

Yes

Mirror

Yes

Heartbeat

Yes

Anti-flicker

Yes

Back Light Compensation (BLC)

Yes

Video streaming

Yes

Alarm input/output

Yes

Camera shutter speed

1 - 1/100000 s

Bit rate control

Constant Bit Rate (CBR), Variable Bit Rate (VBR)

Highlight Compensation (HLC)

Yes

Live view

Yes

Cloud-managed

Yes

Power consumption (Power over Ethernet (PoE))

17 W

Digest authentication

Yes

Password reset via email

Yes

Number of simultaneous live view channels

6 channels

User access level

Administrator, Operator, User

Built-in light

Yes

Management software

iVMS-4200,Hik-Connect,Hik-Central

Detect distance

61 m

Observe distance

24 m

Recognize distance

12 m

Identify distance

6 m

Pixel counter

Yes

Human and vehicle targets classification

Yes

Bit rate range

8 - 320 Kbit/s

Alarm output channels

1

Alarm input channels

1

Number of Privacy masking areas

4

Sample rates

8 - 48 kHz

Automatic Network Replenishment (ANR)

Yes

Network access storage (NAS)

Yes

Audit log

Yes

Flash log

Yes
