24-prievadų Gigabitinis interneto tinklo šakotuvas Planet GSW-2401
    PLANET TECHNOLOGY CORPORATION

    24-prievadų Gigabitinis interneto tinklo šakotuvas Planet GSW-2401

    144,72 €
    Su mokesčiais
    Kiekis

    Išsaugoti prekę Pridėti į palyginimą
    Trumpas aprašymas:

    • Gigabitinis interneto tinklo šakotuvas 24-prievadų;
    • 24 x 10/100/1000Mbps, metalinis korpusas;
    • Auto-MDI/MDIX visiems portams;
    • Palaiko CSMA / CD protokolus;
    • Atitinka interneto standartus: IEEE 802.3, 10Base-T, IEEE 802.3u, 100Base-TX, IEEE 802.3ab 1000Base-T;
    • MAC adresų atmintis: 8k Bitų;
    • Maitinimas 100-240V AC, 0.6A, 50/60Hz
    • Išmatavimai: 440 x 180 x 44 mm, 1U

    Techninė charakteristika:

    • Hardware Version Version 5
    • 10/100/1000Base-T MDI/MDIX Ports 24
    • Throughput (packet per second) 35.7Mpps
    • Switch fabric 48Gbps / non-blocking
    • Power Consumption / Dissipation 18 watts / 61 BTU
    • Power Requirements 100-240V AC, 0.6A, 50/60Hz
    • Switch Processing Scheme Store-and-Forward
    • Address Table 8K entries
    • Jumbo packet size 9K
    • Flow Control Back pressure for half duplex, IEEE 802.3x pause of frame for full duplex
    • Dimensions (W x D x H) 440 x 180 x 44 mm, 1U height
    • Weight 2kg
    • Standards Conformance
    • Regulation Compliance FCC Part 15 Class A, CE
    • Standards Compliance IEEE 802.3 (Ethernet)
    • IEEE 802.3u (Fast Ethernet)
    • IEEE 802.3ab (Gigabit Ethernet)
    • IEEE 802.3x (Full-Duplex Flow Control)
    • Temperature Operating: 0~50 degrees C
    • Storage: -10~70 degrees C
    • Humidity Operating: 5~95%
    • Storage: 5~95% (Non-condensing)

    Prekė detaliau

    PLANET TECHNOLOGY CORPORATION
    GSW-2401
    5 Prekės

    Greitas palyginimas

    Prekė
    		 Switch|MIKROTIK|1x10Base-T / 100Base-TX / 1000Base-T|4xSFP+|PoE ports 1|CRS305-1G-4S+IN Switch|MIKROTIK|1x10Base-T / 100Base-TX / 1000Base-T|4xSFP+|PoE ports 1|CRS305-1G-4S+IN NET SWITCH 10PORT 6POE+ 2POE++/TL-SG1210PP TP-LINK EDIMAX 26-Port Gigabit Switch 2 SFP port EDIMAX 26-Port Gigabit Switch 2 SFP port Switch|TELTONIKA|TSW202|Type L2|2xSFP|8xRJ45|PoE+ ports 8|240 Watts|TSW202 Switch|TELTONIKA|TSW202|Type L2|2xSFP|8xRJ45|PoE+ ports 8|240 Watts|TSW202
    Prieinamumas
    Kaina
    132,96 €
    133,13 €
    134,26 €
    134,80 €
    Aprašymas
    		 1x10Base-T / 100Base-TX / 1000Base-T|4xSFP+|PoE ports 1|Dimensions 141 x 115 x 28mm|Unit Net Weight 0.38 kg 9x10Base-T / 100Base-TX / 1000Base-T|1x10/100/1000BASE-T/SFP combo|IEEE 802.1p|IEEE 802.3af|IEEE 802.3at|PoE+ ports 6|Switching capacity 20 Gbps|Forwarding rate 14.88 Mpps|Power supply External|Dimensions 209 x 126 x 26 mm|Unit Net Weight 1.2 kg The GS-1026 is 24-port gigabit with 2 SFP slots rack-mount switch, that is designed for medium or large network environment to strengthen its network connection. Including rack-mount brackets, the 19" size switch fits into your rack cabinet. It is a superb choice to boost your network with higher performance and efficiency.
    The GS-1026 is built in with 2 SFP slots to uplink to servers, storage, or other switching. You can make the connection by plugging in standard SFP fiber modules for long distance applications.
    The switch GS-1026 offers environmental efficiency with Gigabit Ethernet speeds critical for next-generation network applications. To comply with the IEEE 802.3az standard, the switch GS-1026 provides power saving functions to reduce energy consumption to help business sa     		Type L2|2xSFP|8xRJ45|PoE+ ports 8|PoE power budget 240 Watts|Switching capacity 20 Gbps|Forwarding rate 14.88 Mpps|Dimensions 132 x 44.2 x 122.2 mm|Unit Net Weight 0.5 kg
    Dimensions (WxDxH)
    		 44.1 cm x 13.1 cm x 4.4 cm
    Weight
    		 1.83 kg
    Device type
    		 Switch - 26 ports
    Power
    		 AC 120/230 V (50/60 Hz)
    Features
    		 Auto-negotiation, auto-uplink (auto MDI/MDI-X), packet filtering, store and forward, half duplex mode, full duplex mode, Link Fault Detection, Jumbo Frames support, fanless, 4.1Mbit packet buffer
    Switch type
    		 L2
    Garantija
    		 12 60 24
    PRODUCT DESCRIPTION
    		 Edimax GS-1026 - v3 - switch - 26 ports - rack-mountable
    Category Code
    		 SWI SWI SWI
    Unit Box Height
    		 0.12 0.24 0.135
    Unit Box Length
    		 0.245 0.32 0.135
    Unit Box Width
    		 0.045 0.07 0.05
    Unit Net Weight
    		 0.38 kg 1.2 kg 0.5 kg
    Vendor Homepage
    		 mikrotik.com/product/crs305_1g_4s_in www.tp-link.com/us/business-networking/unmanaged-switch/tl-sg1210pp/ teltonika-networks.com/products/ethernet-switches/tsw202
    Performance
    		 Switching capacity: 52 Gbps Packet filter/forwarding rate (10 Mbps): 14880 pps Packet filter/forwarding rate (100 Mbps): 148800 pps Packet filter/forwarding rate (1000 Mbps):: 1488000 pps
    Dimensions
    		 141 x 115 x 28mm 209 x 126 x 26 mm 132 x 44.2 x 122.2 mm
    Model name
    		 TL-SG1210PP TSW202
    Compliant Standards
    		 IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.3ab, IEEE 802.3az
    Ports
    		 24 x 10/100/1000 + 2 x SFP
    Enclosure Type
    		 Rack-mountable 1U
    Subtype
    		 Gigabit Ethernet
    MAC Address Table Size
    		 8K entries
    Jumbo Frame Support
    		 10000 bytes
    Ports (RJ45)
    		 8
    Network standard (IEEE 802.3af)
    		 Yes
    Network standard (IEEE 802.3at)
    		 Yes
    Ports (10Base-T / 100Base-TX / 1000Base-T)
    		 1 9
    Ports (SFP+)
    		 4
    Ports (SFP)
    		 2
    Ports (10/100/1000BASE-T/SFP combo)
    		 1
    Switching capacity
    		 20 Gbps 20 Gbps
    Network standard (IEEE 802.1p)
    		 Yes
    Primary port count
    		 8
    PoE ports
    		 1
    Forwarding rate
    		 14.88 Mpps 14.88 Mpps
    PoE power budget
    		 240 Watts
    PoE+ ports
    		 6 8
    Power supply
    		External
