24-Port Gigabit Ethernet Switch
    PLANET TECHNOLOGY CORPORATION

    24-Port Gigabit Ethernet Switch

    €144.72
    Tax included
    Quantity

    Trumpas aprašymas:

    • Gigabitinis interneto tinklo šakotuvas 24-prievadų;
    • 24 x 10/100/1000Mbps, metalinis korpusas;
    • Auto-MDI/MDIX visiems portams;
    • Palaiko CSMA / CD protokolus;
    • Atitinka interneto standartus: IEEE 802.3, 10Base-T, IEEE 802.3u, 100Base-TX, IEEE 802.3ab 1000Base-T;
    • MAC adresų atmintis: 8k Bitų;
    • Maitinimas 100-240V AC, 0.6A, 50/60Hz
    • Išmatavimai: 440 x 180 x 44 mm, 1U

    Techninė charakteristika:

    • Hardware Version Version 5
    • 10/100/1000Base-T MDI/MDIX Ports 24
    • Throughput (packet per second) 35.7Mpps
    • Switch fabric 48Gbps / non-blocking
    • Power Consumption / Dissipation 18 watts / 61 BTU
    • Power Requirements 100-240V AC, 0.6A, 50/60Hz
    • Switch Processing Scheme Store-and-Forward
    • Address Table 8K entries
    • Jumbo packet size 9K
    • Flow Control Back pressure for half duplex, IEEE 802.3x pause of frame for full duplex
    • Dimensions (W x D x H) 440 x 180 x 44 mm, 1U height
    • Weight 2kg
    • Standards Conformance
    • Regulation Compliance FCC Part 15 Class A, CE
    • Standards Compliance IEEE 802.3 (Ethernet)
    • IEEE 802.3u (Fast Ethernet)
    • IEEE 802.3ab (Gigabit Ethernet)
    • IEEE 802.3x (Full-Duplex Flow Control)
    • Temperature Operating: 0~50 degrees C
    • Storage: -10~70 degrees C
    • Humidity Operating: 5~95%
    • Storage: 5~95% (Non-condensing)
