Product Details
Data sheet
- Cable length
- 1.83 m
- Width
- 433 mm
- Height
- 44 mm
- Depth
- 235 mm
- Weight
- 7.8 kg
- Package height
- 155 mm
- Package width
- 530 mm
- Number of batteries supported
- 1
- Cables included
- USB cable
- Storage relative humidity (H-H)
- 0 - 95%
- Operating temperature (T-T)
- 0 - 40 °C
- Operating relative humidity (H-H)
- 0 - 95%
- Storage temperature (T-T)
- -15 - 45 °C
- Form factor
- Rackmount
- USB port
- Yes
- LED indicators
- Operation
- Battery technology
- Sealed Lead Acid (VRLA)
- Battery recharge time
- 8 h
- Output power
- 360 W
- Input frequency
- 50/60 Hz
- Response time
- 4 ms
- Display type
- LCD
- Ethernet LAN (RJ-45) ports
- 1
- Input operation voltage (min)
- 165 V
- Power protection features
- Overload
- AC outlets quantity
- 6 AC outlet(s)
- Output power capacity
- 0.6 kVA
- Output operation voltage (max)
- 230 V
- Waveform
- Sine
- AC outlet types
- C13 coupler
- Input operation voltage (max)
- 271 V
- Audible alarm(s)
- Yes
- Output operation voltage (min)
- 230 V
- UPS topology
- Line-Interactive
- Modem (RJ-11) ports
- 1
- Typical backup time at full load
- 4 min
- Automatic Voltage Regulation (AVR)
- Yes
- Housing material
- Metal
- Typical backup time at half load
- 13 min
- Surge protection
- Yes
- Operating altitude
- 0 - 3000 m
- Output frequency
- 50/60 Hz
- Serial ports quantity
- 1
- Maximum current
- 10 A
- Surge energy rating
- 405 J
- Power plug
- C14 coupler
- Non-operating altitude
- 0 - 15000 m
- Product colour
- Silver
- Harmonized System (HS) code
- 8504408590
- Sustainability certificates
- RoHS
- Hot-swap battery
- Yes
- Audible alarm modes
- Low battery alarm, Overload alarm
- Power factor
- 0.6
- Surge protection features
- Fax
- Rack capacity
- 1U
- EMI/RFI noise filtering
- Yes
