Product Details
Data sheet
- Cable length
- 1.5 m
- Width
- 148 mm
- Height
- 178 mm
- Depth
- 298 mm
- Weight
- 10.8 kg
- Power source type
- AC
- Storage relative humidity (H-H)
- 0 - 90%
- Manual
- Yes
- Operating temperature (T-T)
- 0 - 40 °C
- Operating relative humidity (H-H)
- 0 - 90%
- Storage temperature (T-T)
- -20 - 50 °C
- Form factor
- Tower
- USB port
- Yes
- LED indicators
- Yes
- Battery technology
- Sealed Lead Acid (VRLA)
- Control type
- Buttons
- Battery recharge time
- 8 h
- Cooling type
- Active
- Output power
- 1320 W
- Input frequency
- 50/60 Hz
- Response time
- 4 ms
- Input operation voltage (min)
- 167 V
- Power protection features
- Overload
- AC outlets quantity
- 4 AC outlet(s)
- Output power capacity
- 2.2 kVA
- Output operation voltage (max)
- 230 V
- Waveform
- Pseudo sine
- Input operation voltage (max)
- 295 V
- Audible alarm(s)
- Yes
- UPS topology
- Line-Interactive
- Automatic Voltage Regulation (AVR)
- Yes
- Housing material
- Plastic
- Number of phases
- 1
- Surge protection
- Yes
- Operating altitude
- 0 - 3000 m
- Quick installation guide
- Yes
- Noise Level
- 50 dB
- Maximum current
- 10 A
- Surge energy rating
- 150 J
- Non-operating altitude
- 0 - 3000 m
- Product colour
- Black
- Sustainability certificates
- CE
- Sustainability compliance
- Yes
- Heat dissipation
- 34.1 BTU/h
- Charging voltage
- 5 V
- USB port type
- USB Type A/USB Type-C
- Charging current
- 2.1 A
- Audible alarm modes
- Alarm when on battery, Fault, Low battery alarm, Overload alarm
- Surge protection features
- Network
- EMI/RFI noise filtering
- Yes
- Number of RJ11/RJ45 output ports
- 1
- Number of RJ11/RJ45 input ports
- 1
Quick Compare
Product |
Sale!
Digitus Line-Interactive UPS DN-170076, 2000VA/1200W 12V/9Ah x2 battery, 4x CEE 7/7, USB, RS232, RJ45,LCD, Simulated sine wave,
|
|
|
PowerWalker VI 500 R1U Line-Interactive 0.5 kVA 300 W 4 AC outlet(s)
|
Availability |
|
|
|
|
Price |
€178.31
€170.56
|
€180.66
|
€181.13
|
€183.67
|
Description |
Digitus Line-Interactive UPS DN-170076, 2000VA/1200W 12V/9Ah x2 battery, 4x CEE 7/7, USB, RS232, RJ45,LCD, Simulated sine wave, 198 x 158 x 380 mm, Weight: 10.5 kg | APC Back-UPS BX1200MI-GR 1200VA 650W | Schneider Electric | ||
Warranty |
24 month(s) | 24 month(s) | ||
Producer product name |
Line-Interactive UPS DN-170076, 2000VA/1200W 12V/9Ah x2 battery, 4x CEE 7/7, USB, RS232, RJ45,LCD, Simulated sine wave, 198 x 158 x 380 mm, Weight: 10.5 kg | |||
Net weight |
11.505 kg | 7.6 kg | ||
Gross weight |
12.4 kg | 8.6 kg | ||
WEEE tax |
Yes | Yes | ||
Packing quantity |
1.00 pc(s) | 1.00 pc(s) | ||
Volume (m3) |
0.0305325 m | 0.034548525 m | ||
Tare weight (kg) |
0.90 kg | 1 kg | ||
Gross depth (mm) |
450 mm | 235 mm | ||
Gross width (mm) |
230 mm | 495 mm | ||
Gross height (mm) |
295 mm | 297 mm | ||
WEE classification |
CL109:6:2017-04-01 | CL109:5:2017-04-01 | ||
Paper/Pasteboard |
805.5 g | 900 g | ||
Embeeded battery |
Yes | Yes | ||
TI weight (kg) |
5.83 kg | 2.68 kg | ||
Width |
81 mm | 433 mm | ||
Height |
263 mm | 44 mm | ||
Depth |
235 mm | 216 mm | ||
Other features |
2000 VA Line-Interactive UPS 230 VAC 50-60 Hz nominal output LCD display Noise level: Less than 40 dB Overload, Discharge and Overcharge protection | |||
Plastic (No PET) |
89.50 g | 100 g | ||
Composition of battery |
CL127:KT:2016-12-09 | CL127:KT:2016-12-09 | ||
Classification of battery |
CL126:NE:2016-12-09 | CL126:NE:2016-12-09 | ||
Type of battery |
Accumulator | Accumulator | ||
Weight |
4.1 kg | 7.6 kg | ||
Producer product family |
Line-Interactive UPS | |||
Package height |
150 mm | |||
Package width |
537 mm | |||
Number of batteries supported |
2 | |||
Cables included |
USB cable | |||
Manual |
Yes | |||
Operating temperature (T-T) |
0 - 40 °C | |||
Operating relative humidity (H-H) |
0 - 95% | |||
Form factor |
Wallmount | Tower | Rackmount | |
USB port |
Yes | |||
Mac compatibility |
Yes | |||
LED indicators |
Battery replacement | |||
Battery technology |
Sealed Lead Acid (VRLA) | |||
Battery capacity |
7 Ah | |||
Capacity |
1200 W | |||
Palette Qty |
50 pc(s) | |||
Battery recharge time |
8 h | |||
Output power |
500 W | 300 W | ||
Input frequency |
50/60 Hz | 45/55 Hz | ||
USB 2.0 ports quantity |
1 | |||
Display type |
LCD | |||
Ethernet LAN (RJ-45) ports |
1 | |||
Input operation voltage (min) |
161 V | 165 V | ||
Power protection features |
Overload | |||
Cold start |
Yes | |||
AC outlets quantity |
4 | 4 AC outlet(s) | 4 AC outlet(s) | |
Output power capacity |
0.8 kVA | 0.5 kVA | ||
Output operation voltage (max) |
240 V | 230 V | ||
Waveform |
Simulated Sine Wave | Sine | ||
AC outlet types |
Type F | C13 coupler | ||
Input operation voltage (max) |
284 V | 290 V | ||
Audible alarm(s) |
Yes | |||
Battery voltage |
6 V | |||
Output operation voltage (min) |
220 V | 230 V | ||
UPS topology |
Line-Interactive | Standby (Offline) | Line-Interactive | |
Modem (RJ-11) ports |
1 | |||
Typical backup time at full load |
0.8 min | |||
Automatic battery test |
Yes | |||
Typical backup time at half load |
11 min | 10.3 min | ||
Surge protection |
Yes | |||
Nominal input voltage |
230 V | |||
Nominal output voltage |
220-240 V | |||
Output frequency regulation |
0.5 Hz | |||
Output voltage regulation |
10% | |||
RS-232 ports |
1 | |||
Power plug |
C14 coupler | |||
Product colour |
Black | Black | ||
Harmonized System (HS) code |
85078000 | 85078000 | ||
Safety |
IEC 62040-1, IEC 60950-1, IEC 62040-2, CB Report, CE mark, IEC 61643-1 | |||
Hot-swap battery |
No | |||
Producer |
Schneider Electric | |||
Audible alarm modes |
Battery replacement | |||
Overload protection |
Yes | |||
Surge protection features |
Fax | |||
Emergency Power Off (EPO) |
No | |||
Rack capacity |
2U | 1U | ||
Output power factor |
0.6 | |||
Emergency Power Off (EPO) connector |
Yes | |||
Input connection type |
Schuko | |||
