EnerGenie UPS with AVR 850 VA 220 V

€60.68

€58.75 Save €1.93

Tax included

Product Details

Reference EG-UPS-002

In stock 4 Items

Data sheet

Colour of product: Black
Warranty: 24 month(s)
Producer product name: UPS with AVR
Net weight: 5.5 kg
Gross weight: 6 kg
WEEE tax: Yes
Packing quantity: 3.00 pc(s)
Gross depth master carton: 440 mm
Gross width master carton: 345 mm
Gross height master carton: 250 mm
Net weight master carton: 18 kg
Tare weight master carton: 0.645 kg
Volume (m3): 0.01 m
Tare weight (kg): 0.50 kg
Gross depth (mm): 335.00 mm
Gross width (mm): 145.00 mm
Gross height (mm): 235.00 mm
WEE classification: CL109:5:2017-04-01
Embeeded battery: Yes
TI weight (kg): 3.98 kg
Width: 280 cm
Height: 95 cm
Depth: 185 cm
Certification: -CE
Plastic (No PET): 500.00 g
Composition of battery: CL127:KT:2016-12-09
Classification of battery: CL126:PE:2016-12-09
Type of battery: Accumulator
Weight: 5600 g
Special features: * Uninterruptable 850 VA power supply with modified sine wave output * Automatic AC voltage regulation (AVR) * Intelligent surge-, overload- and short-circuit protection * USB port for PC connection * Audible and visual alarms * LED status indication * In
Number of batteries supported: 1
Operating temperature (T-T): 0 - 40 C
Operating relative humidity (H-H): 20 - 90 %
Form factor: Compact
Battery technology: Sealed Lead Acid (VR
Battery capacity: 8 Ah
Capacity: 850 VA
Palette Qty: 135 pc(s)
Battery recharge time: 12 h
Output power: 510 W
Noise level (max): 45 dB
Response time: 10 ms
Power supply input frequency: 50/60 Hz
AC outlets quantity: 4
Output power capacity: 850 VA
Output operation voltage (max): 220 V
AC outlet types: Type F (Schuko)
Input operation voltage (max): 220 V
Battery voltage: 12 V
Typical backup time at full load: 10 min
Typical backup time at half load: 30 min
Number of phases: 1
