Product Details
Data sheet
- Warranty
- 36 month(s)
- Producer product name
- B760M H DDR4 1.0 M/B
- Net weight
- 0.95 kg
- Gross weight
- 1.23 kg
- WEEE tax
- No
- Packing quantity
- 1.00 pc(s)
- Gross depth master carton
- 570 mm
- Gross width master carton
- 285 mm
- Gross height master carton
- 285 mm
- Net weight master carton
- 8.02 kg
- Tare weight master carton
- 0.787 kg
- Volume (m3)
- 0.00 m
- Tare weight (kg)
- 0.28 kg
- Gross depth (mm)
- 265.00 mm
- Gross width (mm)
- 265.00 mm
- Gross height (mm)
- 54.00 mm
- Paper/Pasteboard
- 200.00 g
- Embeeded battery
- No
- Plastic (No PET)
- 80.00 g
- Palette Qty
- 456 pc(s)
- Memory slots
- 2
- Chipset
- Intel B760 Express
- Supported hard disk drive interfaces
- SATA, M.2
- Compatible processor series
- Supports 13th/12th Gen Intel Core Series Processors
- Processor family
- Intel
- Motherboard form factor
- Micro ATX
- Supported memory types
- DDR4 DIMM
- Processor socket
- LGA1700
- Number of SATA connectors
- 4
